Cylinder Head replacement parts for 1985 Honda NIGHTHAWK S (CB700SC)

OEM Parts Honda 1985 Honda NIGHTHAWK S (CB700SC) Cylinder Head

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	CYLINDER HEAD ASSEMBLY Part #: 12010-MJ0-020 Required per assembly: 1 Not Available
002	GUIDE, VALVE Part #: 12205-MJ0-315 Required per assembly: 8 $22.48 $18.20 - + Add to cart
003	GUIDE, EX., VALVE Part #: 12206-MJ0-325 Required per assembly: 8 Not Available
004	PLATE, OIL, CHAMBER Part #: 12221-MCN-721 Required per assembly: 4 Not Available
005	PIPE, CAM, HOLDER Part #: 12230-MCN-640 Required per assembly: 2 $34.79 $28.16 - + Add to cart
006	GASKET, CYL, HD Part #: 12251-MJ0-003 Required per assembly: 1 Not Available
009	PIPE, C, OIL, FEED Part #: 15527-MJ1-770 Required per assembly: 1 Not Available
010	BOLT B (8X28) Part #: 15532-ME5-015 Required per assembly: 2 $12.00 $10.01 - + Add to cart
011	INSULATOR (NO.1) Part #: 16213-MJ0-010 Required per assembly: 1 $59.83 $48.43 - + Add to cart
012	INSULATOR, CARB Part #: 16214-MJ0-010 Required per assembly: 1 $59.83 $49.88 - + Add to cart
013	INSULATOR (NO.3) Part #: 16215-MJ0-010 Required per assembly: 1 $59.83 $49.88 - + Add to cart
014	INSULATOR (NO.4) Part #: 16216-MJ0-010 Required per assembly: 1 $59.83 $48.43 - + Add to cart
015	JOINT, PB Part #: 16221-MA6-000 Required per assembly: 1 $15.50 $12.93 - + Add to cart
016	PLATE, R., INSULATOR Part #: 16221-MJ0-000 Required per assembly: 2 $14.45 $12.05 - + Add to cart
017	PLATE, L., INSULATOR Part #: 16222-MJ0-000 Required per assembly: 2 $12.25 $10.22 - + Add to cart
018	BAND, INSULATOR Part #: 16223-KS5-000 Required per assembly: 4 $16.46 $13.72 - + Add to cart
019	BOLT, FLANGE, (6X52) Part #: 90009-HA0-000 Required per assembly: 4 $5.63 $5.12 - + Add to cart
020	BOLT, FLANGE, (6X28) Part #: 90003-MJ0-000 Required per assembly: 4 Not Available
022	BOLT, FLANGE, (6X48) Part #: 90018-425-000 Required per assembly: 8 $4.68 $4.25 - + Add to cart
023	BOLT, OIL, CONTROL Part #: 90027-MJ1-770 Required per assembly: 1 $11.77 $10.70 - + Add to cart
024	BOLT, STUD, (8-6X57) Part #: 90035-MA6-010 Required per assembly: 8 Not Available
025	BOLT (6X25) Part #: 90091-KF0-000 Required per assembly: 8 $5.07 $4.61 - + Add to cart
026	NUT B (9MM) Part #: 90232-MJ0-000 Required per assembly: 8 $4.61 - + Add to cart
027	NUT, CAP, (9MM) Part #: 90233-MJ0-000 Required per assembly: 4 $5.96 $5.33 - + Add to cart
028	WASHER (9MM) Part #: 90413-MJ0-000 Required per assembly: 8 $5.91 $5.29 - + Add to cart
029	WASHER (7MM) Part #: 90441-MJ0-000 Required per assembly: 4 $6.26 $5.56 - + Add to cart
030	WASHER (8MM) Part #: 90442-MJ0-000 Required per assembly: 4 $3.43 $3.12 - + Add to cart
031	WASHER (5MM) Part #: 90452-323-000 Required per assembly: 1 $2.67 $2.48 - + Add to cart
032	WASHER, OIL, BOLT Part #: 90545-MJ1-770 Required per assembly: 4 $3.87 - + Add to cart
033	O-RING (10X1.6) Part #: 91301-200-000 Required per assembly: 4 $4.32 $3.93 - + Add to cart
034	O-RING (36.5X2.7) Part #: 91305-MJ0-003 Required per assembly: 8 $6.00 $5.36 - + Add to cart
035	O-RING (5.6X1.9) Part #: 91318-ME5-003 Required per assembly: 1 $5.04 $4.58 - + Add to cart
036	SCREW, PAN, (5X8) Part #: 93500-05008-0G Required per assembly: 1 $1.95 $1.80 - + Add to cart
037	SCREW, PAN, (5X25) Part #: 93500-05025-0G Required per assembly: 2 $1.80 $1.67 - + Add to cart
038	PIN, DOWEL, (6X10) Part #: 94301-06100 Required per assembly: 1 $3.21 $2.99 - + Add to cart
039	PIN, DOWEL, (8X14) Part #: 94301-08140 Required per assembly: 2 $3.21 $2.99 - + Add to cart
040	PIN, DOWEL, (10X16) Part #: 94301-10160 Required per assembly: 4 $3.50 $3.18 - + Add to cart
042	BOLT, FLANGE, (6X14) Part #: 95701-06014-07 Required per assembly: 4 $2.50 $2.32 - + Add to cart
043	S/PLG (X24EPR-U9) Part #: 98069-58926 Required per assembly: 1 Note: Denso $3.25 - + Add to cart
043	S/PLG (DPR9EA-9) Part #: 98069-59916 $3.32 - + Add to cart
043	S/PLG (X22EPR-U9) Part #: 98069-57926 $3.25 - + Add to cart
043	S/PLG (X27EPR-U9) Part #: 98069-59926 $3.25 - + Add to cart
043	S/PLG (DPR7EA-9) Part #: 98069-57916 $3.32 - + Add to cart
043	S/PLG (DPR8EA-9) Part #: 98069-58916 Required per assembly: 1 $3.62 - + Add to cart
