Rear Cylinder replacement parts for 1985 Honda VF1000R

OEM Parts Honda 1985 Honda VF1000R Rear Cylinder

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	CYLINDER, HEAD, RR. Part #: 12020-MJ4-701 Required per assembly: 1 Not Available
002	GUIDE, VALVE, (OS) Part #: 12204-MS2-305 Required per assembly: 16 Not Available
002	GUIDE, VALVE, (OS) Part #: 12204-MS2-305 Required per assembly: 8 Not Available
004	GASKET, CYL, HD Part #: 12251-MB6-306 Required per assembly: 1 Not Available
005	INSULATOR, CARB Part #: 16212-MB6-010 Required per assembly: 2 $16.26 $13.15 - + Add to cart
006	JOINT, BOOST Part #: 16214-MB0-000 Required per assembly: 1 $5.72 $5.14 - + Add to cart
007	BAND, INSULATOR Part #: 16223-KS5-000 Required per assembly: 1 $16.46 $13.72 - + Add to cart
008	BOLT, FLANGE, (6X52) Part #: 90009-HA0-000 Required per assembly: 4 $5.63 $5.12 - + Add to cart
009	BOLT, FLANGE, (6X62) Part #: 90003-MB6-680 Required per assembly: 4 Not Available
010	BOLT, STUD, (9X99) Part #: 90005-MB6-680 Required per assembly: 4 Not Available
012	BOLT, FLANGE, (6X40) Part #: 90008-GE0-710 Required per assembly: 2 Not Available
013	BOLT, UBS, (9X175) Part #: 90012-MB6-003 Required per assembly: 4 Not Available
014	BOLT, STUD, (7-6X47) Part #: 90035-MB6-000 Required per assembly: 4 Not Available
015	NUT, CAP, (9MM) Part #: 90232-MB6-680 Required per assembly: 4 $5.26 $4.78 - + Add to cart
016	WASHER (10.2MM) Part #: 90401-MJ4-000 Required per assembly: 4 Not Available
017	WASHER (5MM) Part #: 90452-323-000 Required per assembly: 1 $2.67 $2.48 - + Add to cart
019	SCREW, PAN, (5X8) Part #: 93500-05008-0G Required per assembly: 1 $1.95 $1.80 - + Add to cart
020	SCREW, PAN, (5X28) Part #: 93500-05028-0G Required per assembly: 3 $1.75 $1.61 - + Add to cart
021	PIN, DOWEL, (8X14) Part #: 94301-08140 Required per assembly: 2 $3.21 $2.99 - + Add to cart
022	PIN, DOWEL, (12X20) Part #: 94301-12200 Required per assembly: 1 $3.50 $3.18 - + Add to cart
023	S/PLG (X24EPR-U9) Part #: 98069-58926 Required per assembly: 1 Note: Denso $3.25 - + Add to cart
023	S/PLG (DPR9EA-9) Part #: 98069-59916 $3.32 - + Add to cart
023	S/PLG (X27EPR-U9) Part #: 98069-59926 $3.25 - + Add to cart
023	S/PLG (DPR8EA-9) Part #: 98069-58916 Required per assembly: 1 $3.62 - + Add to cart
