OEM Parts Kawasaki 1985 Kawasaki Voyager (ZN1300 A3) Engine Covers

1985 Kawasaki Voyager (ZN1300-A3) - Engine Covers

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
120

BOLT-SOCKET

Part #: 120Z0614 Required per assembly: 2
Not Available
120A

BOLT-SOCKET

Part #: 120CD0616 Required per assembly: 1 Note: Sold in multiples of 5 only
$4.04
$3.20
-
+
Add to cart
120B

BOLT-SOCKET

Part #: 120CD0635 Required per assembly: 9
Not Available
120C

BOLT-SOCKET

Part #: 120Z0645 Required per assembly: 4
Not Available
222

SCREW OVL CNTSNK 5X10

Part #: 222E0510 Required per assembly: 2
Not Available
223

SCREW-PAN-WS-CROS

Part #: 223AA0612 Required per assembly: 3
Not Available
670

"O", RING, 45M/M

Part #: 670B3045 Required per assembly: 1
Not Available
11009

GASKET, L.H, ENGINE, COV

Part #: 11060-1417 Required per assembly: 1
Not Available
11009A

GASKET, MISSON, COVER

Part #: 11060-1418 Required per assembly: 1
Not Available
11009B

GASKET, CLUTCH, COVER

Part #: 11060-1419 Required per assembly: 1
Not Available
11009C

GASKET, BEARING, CAP

Part #: 11009-1159 Required per assembly: 1
Not Available
11009D

GASKET, GENERATOR, COVE

Part #: 11060-1602 Required per assembly: 1
Not Available
11009E

GASKET, OIL, INSPECTION

Part #: 11060-1614 Required per assembly: 1
Not Available
11012

CAP, TIMING, SPROCKET

Part #: 11012-1060 Required per assembly: 1
Not Available
13151

SWITCH-COMP

Part #: 13151-1013 Required per assembly: 1
Not Available
13169

PLATE, BAFFLE, BREATHER

Part #: 13169-1131 Required per assembly: 1
Not Available
14022

CAP, BEARING, OUT, SHAFT

Part #: 14022-1005 Required per assembly: 1
Not Available
14024

COVER, OIL, INSPECTION

Part #: 14025-1467 Required per assembly: 1 Note: (KZT30AE021064)
Not Available
14024B

COVER, TRANSMISSION, SI

Part #: 14025-1617 Required per assembly: 1
Not Available
14024C

COVER, RELEASE

Part #: 14025-1618 Required per assembly: 1
Not Available
14024G

COVER, OIL, INSPECTION

Part #: 14025-1704 Required per assembly: 1
Not Available
14024H

COVER, CLUTCH, COVER

Part #: 14025-1814 Required per assembly: 1
Not Available
14032

COVER-CLUTCH

Part #: 14032-1111 Required per assembly: 1
Not Available
14041

COVER, COMP, GENERATOR

Part #: 14041-1024 Required per assembly: 1
Not Available
14041B

COVER, COMP, GENERATOR

Part #: 14041-1024 Required per assembly: 1
Not Available
16115

CAP-OIL FILLER

Part #: 16115-1009 Required per assembly: 1
$14.65
$12.33
-
+
Add to cart
52005

GAUGE, OIL, LEVEL

Part #: 52005-0069 Required per assembly: 1
Not Available
92001

BOLT

Part #: 92003-202 Required per assembly: 4
Not Available
92002

BOLT, 6X35

Part #: 92002-1282 Required per assembly: 24
Not Available
92002A

BOLT, 6X50

Part #: 92002-1283 Required per assembly: 4
Not Available
92015

NUT, LOCK, 5MM

Part #: 92018-004 Required per assembly: 1
$4.52
$3.56
-
+
Add to cart
92022

WASHER, 5.5X20X1.2

Part #: 92022-1405 Required per assembly: 1
$4.43
$3.49
-
+
Add to cart
92037

CLAMP, CABLE

Part #: 92037-1152 Required per assembly: 1
Not Available
92046

BEARING-NEEDLE, 7E-HK1412

Part #: 92046-037 Required per assembly: 1
$22.07
$18.45
-
+
Add to cart
92049

OIL, SEAL, TC14244.8

Part #: 92049-1037 Required per assembly: 1
Not Available
92049A

OIL, SEAL, TC35527

Part #: 92049-1038 Required per assembly: 1
$19.11
$15.91
-
+
Add to cart
92049B

SEAL-OIL, TB13225.5

Part #: 92051-005 Required per assembly: 1
$7.97
$6.91
-
+
Add to cart
92055

RING-O, 31.7X2.4

Part #: 92055-049 Required per assembly: 1
$4.43
$3.49
-
+
Add to cart
92071

GROMMET

Part #: 92071-1051 Required per assembly: 1
Not Available
92071A

GROMMET, CLUTCH, COVER

Part #: 92071-1108 Required per assembly: 1
$6.25
$4.83
-
+
Add to cart
92075

DAMPER, CLUTCH, COVER

Part #: 92075-1594 Required per assembly: 1
Not Available
