Carburetor replacement parts for 1987 Honda ALL TERRAIN CYCLE (ATC200X)

OEM Parts Honda 1987 Honda ALL TERRAIN CYCLE (ATC200X) Carburetor

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	GASKET SET Part #: 16010-HB5-305 Required per assembly: 1 $31.80 $26.51 - + Add to cart
002	NEEDLE, SET, JET Part #: 16012-HB5-014 Required per assembly: 1 Not Available
003	FLOAT SET Part #: 16013-439-921 Required per assembly: 1 $76.09 $73.79 - + Add to cart
004	CHAMBER, SET, FLOAT Part #: 16015-KCE-671 Required per assembly: 1 Not Available
005	SCREW SET A Part #: 16016-HB5-671 Required per assembly: 1 Not Available
006	VALVE, SET, THROTTLE Part #: 16022-HB7-004 Required per assembly: 1 Not Available
007	SCREW SET B Part #: 16028-KB1-D11 Required per assembly: 1 $6.94 $6.31 - + Add to cart
008	CARBURETOR ASSEMBLY Part #: 16100-HB5-306 Required per assembly: 1 Not Available
009	GASKET, TOP Part #: 16110-HB5-004 Required per assembly: 1 Not Available
010	PLATE, STAY Part #: 16119-440-004 Required per assembly: 1 $10.65 $9.13 - + Add to cart
011	LEVER, CHOKE Part #: 16135-KA8-671 Required per assembly: 1 Not Available
013	VALVE, FLOAT Part #: 16155-397-971 Required per assembly: 1 $48.04 $40.05 - + Add to cart
014	HOLDER, NEEDLE, JET Part #: 16165-HB5-014 Required per assembly: 1 Not Available
015	HOLDER, JET Part #: 16168-382-014 Required per assembly: 1 $11.37 $8.45 - + Add to cart
017	TUBE Part #: 16199-437-405 Required per assembly: 1 Not Available
018	SCREW-WASHER (4X16) Part #: 93892-04016-08 Required per assembly: 4 $1.79 $1.65 - + Add to cart
019	SCREW-WASHER (5X12) Part #: 93892-05012-08 Required per assembly: 2 $2.18 $2.02 - + Add to cart
020	NUT, HEX., (6MM) Part #: 94001-06200-0S Required per assembly: 2 $2.33 $2.12 - + Add to cart
021	CLIP, TUBE, (B6.5) Part #: 95002-02650 Required per assembly: 1 $2.49 $2.31 - + Add to cart
022	JET, MAIN, (#108) Part #: 99113-GHB-1080 $10.80 $9.24 - + Add to cart
022	JET, MAIN, (#112) Part #: 99113-GHB-1120 $10.80 $9.24 - + Add to cart
023	JET, SLOW, (#35) Part #: 99103-440-0350 $13.13 $12.73 - + Add to cart
