Front Brake Master Cylinder 87 replacement parts for 1987 Honda INTERCEPTOR (VFR700F2)

OEM Parts Honda 1987 Honda INTERCEPTOR (VFR700F2) Front Brake Master Cylinder 87

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	SWITCH, FR., STOP Part #: 35340-MM5-600 Required per assembly: 1 $26.04 $20.76 - + Add to cart
005	JOINT Part #: 45127-ML7-691 Required per assembly: 1 Not Available
007	BOOT Part #: 45504-410-003 Required per assembly: 1 $14.10 $11.76 - + Add to cart
008	PROTECTOR Part #: 45512-MA6-006 Required per assembly: 1 $5.68 $5.16 - + Add to cart
009	CAP Part #: 45513-ML7-601 Required per assembly: 1 Not Available
010	HOLDER Part #: 45517-KR3-901 Required per assembly: 1 $22.85 $19.05 - + Add to cart
011	PLATE, DIAPHRAGM Part #: 45518-MB4-671 Required per assembly: 1 $14.06 $11.72 - + Add to cart
012	DIAPHRAGM Part #: 45520-MA5-672 Required per assembly: 1 $21.02 $17.52 - + Add to cart
013	MASTER CYLINDER SET Part #: 45530-MA5-671 Required per assembly: 1 $83.08 $69.30 - + Add to cart
014	GASKET, OIL, BOLT Part #: 46472-568-000 Required per assembly: 4 $8.61 $7.83 - + Add to cart
015	LEVER, R., HANDLE Part #: 53170-MW0-006 Required per assembly: 1 $49.14 $40.98 - + Add to cart
016	KNOCKER Part #: 53171-MJ4-701 Required per assembly: 1 Not Available
017	ADJUSTER, R. Part #: 53172-KV0-006 Required per assembly: 1 Not Available
018	BOLT (5X5) Part #: 53177-KV0-006 Required per assembly: 1 Not Available
019	JOINT, LEVER Part #: 53179-KV0-006 Required per assembly: 1 Not Available
020	BOLT, ADJUSTING Part #: 53180-KV0-006 Required per assembly: 1 Not Available
021	SPRING, HANDLE, LEVER Part #: 53181-KV0-006 Required per assembly: 1 $4.99 $4.54 - + Add to cart
022	LEVER, SET, R., HANDLE Part #: 53185-KV0-006 Required per assembly: 1 Not Available
023	BOLT Part #: 90114-MA5-671 Required per assembly: 1 $10.93 $9.35 - + Add to cart
024	BOLT, OIL, (10X22) Part #: 90145-KM3-751 Required per assembly: 1 $12.77 $10.64 - + Add to cart
025	BOLT, OIL, (10X34) Part #: 90145-MB0-010 Required per assembly: 1 Not Available
026	NUT, CAP, (6MM) Part #: 90201-415-000 Required per assembly: 1 $3.11 $2.90 - + Add to cart
027	CIRCLIP Part #: 90651-MA5-671 Required per assembly: 1 $3.19 $2.51 - + Add to cart
029	SCREW, FLAT, (4X12) Part #: 93600-04012-0G Required per assembly: 2 $1.87 $1.70 - + Add to cart
030	SCREW-WASHER (4X12) Part #: 93893-04012-08 Required per assembly: 3 $2.37 $2.19 - + Add to cart
031	BOLT, FLANGE, (6X25) Part #: 95701-06025-07 Required per assembly: 2 $2.79 $2.60 - + Add to cart
032	BOLT, FLANGE, (6X22) Part #: 96001-06022-07 Required per assembly: 3 $2.84 $2.64 - + Add to cart
