Water Pump 90-91 replacement parts for 1990 Honda CR250R

OEM Parts Honda 1990 Honda CR250R Water Pump 90-91

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	IMPELLER, WATER, PUMP Part #: 19215-KA3-740 Required per assembly: 1 $73.25 $61.07 - + Add to cart
003	SEPARATOR Part #: 19222-KA4-770 Required per assembly: 1 Not Available
004	GASKET Part #: 19229-KA4-309 Required per assembly: 2 $5.20 $4.73 - + Add to cart
005	SHAFT, WATER, PUMP Part #: 19240-KA4-770 Required per assembly: 1 Not Available
008	BOLT, FLANGE, (6X75) Part #: 90015-KS6-700 Required per assembly: 1 Not Available
009	BOLT, FLANGE, (6X30) Part #: 90016-ML3-680 Required per assembly: 2 Not Available
010	BOLT, OIL, CHECK Part #: 90037-360-000 Required per assembly: 1 $4.92 $4.55 - + Add to cart
011	WASHER (7MM) Part #: 90447-KE1-000 Required per assembly: 1 $3.69 $3.35 - + Add to cart
012	GASKET, FR. Part #: 90543-273-000 Required per assembly: 1 $3.50 $3.18 - + Add to cart
013	PIN, DOWEL, (8X10) Part #: 94301-08100 Required per assembly: 2 $3.21 $2.99 - + Add to cart
014	BEARING (12X28X7) Part #: 91001-KA4-003 Required per assembly: 1 $17.02 $16.50 - + Add to cart
015	OIL SEAL (12X22X5) Part #: 91201-965-000 Required per assembly: 1 $5.43 $4.94 - + Add to cart
016	SEAL, WATER, PUMP Part #: 91211-KA3-761 Required per assembly: 1 $8.03 $7.01 - + Add to cart
017	BALL (#13) (13/32) Part #: 96211-13000 Required per assembly: 4 $1.57 $1.45 - + Add to cart
