Front Fork Except I replacement parts for 1990 Honda GOLD WING (GL1500)

OEM Parts Honda 1990 Honda GOLD WING (GL1500) Front Fork Except I

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	GUIDE, METER, CABLE Part #: 44832-MT8-000 Required per assembly: 1 $4.80 - + Add to cart
002	FORK, ASSEMBLY, R., FR. Part #: 51400-MT8-003 Required per assembly: 1 Not Available
003	SPRING, FR., FORK Part #: 51401-MN5-003 Required per assembly: 2 Not Available
004	SPRING, OIL, LOCK Part #: 51402-MB7-611 Required per assembly: 1 $6.05 $5.40 - + Add to cart
005	SPRING, B, FR., FORK Part #: 51402-MN5-003 Required per assembly: 2 Not Available
006	VALVE, OIL, LOCK Part #: 51403-MB7-611 Required per assembly: 1 $11.85 $10.10 - + Add to cart
007	PLATE, SPRING, JOINT Part #: 51404-MB4-003 Required per assembly: 2 $5.92 $5.30 - + Add to cart
008	SEAT, SPRING Part #: 51404-MB7-611 Required per assembly: 1 $5.74 $5.15 - + Add to cart
009	RING, STOPPER Part #: 51405-MB7-611 Required per assembly: 2 $3.94 $3.58 - + Add to cart
010	PIPE, FR., FORK Part #: 51410-MT8-003 Required per assembly: 2 Not Available
011	SPRING, REBOUND Part #: 51411-MN5-003 Required per assembly: 2 Not Available
012	RING, BACK-UP Part #: 51412-MB4-003 Required per assembly: 2 $11.18 $9.55 - + Add to cart
013	BUSH, GUIDE Part #: 51414-KCR-003 Required per assembly: 2 $16.26 $13.54 - + Add to cart
014	BUSH, SLIDER Part #: 51415-KCR-003 Required per assembly: 2 $14.21 $11.86 - + Add to cart
015	GASKET Part #: 51417-MJ6-013 Required per assembly: 2 $9.52 $8.21 - + Add to cart
016	SPRING, PISTON Part #: 51418-MN5-003 Required per assembly: 2 Not Available
017	CASE, R., (LOWER) Part #: 51421-MN5-003 Required per assembly: 1 Not Available
018	COLLAR, PISTON Part #: 51423-MJ0-003 Required per assembly: 1 $13.64 $11.37 - + Add to cart
019	CASE, PISTON Part #: 51430-MT8-003 Required per assembly: 1 Not Available
020	PIECE, OIL, LOCK Part #: 51432-MN5-003 Required per assembly: 1 Not Available
021	PISTON Part #: 51436-MT8-003 Required per assembly: 2 Not Available
022	RING, PISTON Part #: 51437-MN5-003 Required per assembly: 2 $9.89 $8.50 - + Add to cart
023	PIPE, SEAT Part #: 51440-MN5-003 Required per assembly: 2 Not Available
024	RUBBER, STOPPER Part #: 51441-MT8-003 Required per assembly: 2 Not Available
025	BOOT, PISTON, CASE Part #: 51442-MJ0-003 Required per assembly: 1 $11.28 $9.62 - + Add to cart
026	RING, STOPPER Part #: 51445-MJ0-003 Required per assembly: 1 $3.62 $3.29 - + Add to cart
027	RING Part #: 51447-KA4-711 Required per assembly: 2 $5.44 $4.89 - + Add to cart
028	CAP, FORK, PIPE Part #: 51449-MN5-003 Required per assembly: 2 $9.89 $8.50 - + Add to cart
029	BOLT, ASSEMBLY, FR., FORK Part #: 51450-MN5-505 Required per assembly: 1 Not Available
030	BOLT, FR., FORK Part #: 51455-MN5-003 Required per assembly: 2 Not Available
031	CAP, AIR, VALVE Part #: 51456-MB2-003 Required per assembly: 2 Not Available
032	VALVE, AIR Part #: 51456-469-013 Required per assembly: 2 $39.05 $32.57 - + Add to cart
033	SEAL, SET, FR., FORK Part #: 51490-MN8-305 Required per assembly: 2 $40.80 $34.03 - + Add to cart
034	FORK, ASSEMBLY, L., FR. Part #: 51500-MT8-003 Required per assembly: 1 Not Available
035	CASE, L., (LOWER) Part #: 51521-MN5-003 Required per assembly: 1 Not Available
036	CASE, L., PISTON Part #: 51530-MT8-003 Required per assembly: 1 Not Available
037	COLLAR, L., FR. Part #: 51536-ML7-000 Required per assembly: 1 $13.60 $11.01 - + Add to cart
038	BUSH, RUBBER Part #: 51545-MJ0-003 Required per assembly: 1 $10.87 $9.30 - + Add to cart
039	COVER, FR., R114CU, (CANDY, WINE, BERRY, RED-U) Part #: 61050-MN5-000ZE Required per assembly: 1 Not Available
039	COVER, FR., FORK, PB224M, (CARMEL, BLUE) Part #: 61050-MN5-000ZF Required per assembly: 1 Not Available
040	COLLAR Part #: 64630-GE3-610 Required per assembly: 2 Not Available
041	LABEL, FR. Part #: 87517-KM9-640 Not Available
042	BOLT, SOCKET, (8MM) Part #: 90116-KV3-701 Required per assembly: 1 $5.26 $4.78 - + Add to cart
043	SCREW-WASHER (5X12) Part #: 90132-MN5-000 Required per assembly: 1 Not Available
044	GASKET, FR. Part #: 90543-273-000 Required per assembly: 1 $3.50 $3.18 - + Add to cart
045	WASHER (8MM) Part #: 90544-283-000 Required per assembly: 2 $3.89 $3.54 - + Add to cart
046	BEARING (1422) Part #: 91071-ML7-003 Required per assembly: 1 $47.08 $38.11 - + Add to cart
047	DUST SEAL Part #: 91254-MM8-003 Required per assembly: 2 $20.72 $17.28 - + Add to cart
048	O-RING (5.8X1.9) Part #: 91305-323-000 Required per assembly: 2 $4.08 $3.71 - + Add to cart
049	O-RING (16MM) Part #: 91303-800-000 Required per assembly: 1 $3.19 $2.97 - + Add to cart
050	O-RING Part #: 91308-MJ0-003 Required per assembly: 2 $4.93 $4.48 - + Add to cart
051	O-RING (33.2X2.4) Part #: 91356-KF0-003 Required per assembly: 2 $5.12 $4.65 - + Add to cart
052	O-RING (33.2X2.4) Part #: 91356-KF0-003 Required per assembly: 2 $5.12 $4.65 - + Add to cart
053	CAP (6MM) Part #: 91455-MG8-000 Required per assembly: 2 Not Available
054	BOLT, HEX., (6X8) Part #: 92101-06008-0A Required per assembly: 1 $2.26 $2.05 - + Add to cart
055	BOLT, FLANGE, (8X45) Part #: 96400-08045-08 Required per assembly: 4 $3.22 - + Add to cart
056	BOLT, SOCKET, (6X10) Part #: 96700-06010-08 Required per assembly: 4 $2.04 $1.88 - + Add to cart
057	BOLT, SOCKET, (6X16) Part #: 96600-06016-00 Required per assembly: 2 $2.73 $2.54 - + Add to cart
057	BOLT, SOCKET, (6X16) Part #: 96600-06016-00 Required per assembly: 8 $2.73 $2.54 - + Add to cart
