1990 Honda NS50F - Frame

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
001

GROMMET A

Part #: 19902-865-780 Required per assembly: 6
$4.78
002

FRAME

Part #: 50100-GE2-670 Required per assembly: 1
Not Available
003

COLLAR

Part #: 50318-GE2-000 Required per assembly: 2
$6.75
$5.97
004

HOLDER, ASSEMBLY, HELMET

Part #: 50710-086-007 Required per assembly: 1
$76.88
$62.22
005

BOLT

Part #: 90107-449-000 Required per assembly: 2
$4.68
$4.25
006

BOLT, FLANGE, (8X75)

Part #: 90110-GE2-000 Required per assembly: 1
$6.07
$4.97
007

BOLT, FLANGE, (8X145)

Part #: 90112-GE2-000 Required per assembly: 1
Not Available
008

NUT, FLANGE, (8MM)

Part #: 94050-08070 Required per assembly: 2
$2.50
$2.32
009

NUT, FLANGE, (10MM)

Part #: 90303-428-900 Required per assembly: 7
$4.68
$4.25
010

BOLT, FLG, (10X110)

Part #: 95801-10110-07 Required per assembly: 1
Not Available
