Carburetor replacement parts for 1990 Suzuki DR250

OEM Parts Suzuki 1990 Suzuki DR250 Carburetor

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

0	CARBURETOR ASSEMBLY Part #: 13200-15D01 Required per assembly: 1 Not Available
1	CAP, TOP Part #: 13261-27A00 Required per assembly: 1 Not Available
2	GASKET Part #: 13266-27A00 Required per assembly: 1 $7.08 $6.37 - + Add to cart
3	LOCK WASHER Part #: 08321-0105A Required per assembly: 1 $2.29 $2.06 - + Add to cart
4	BOLT Part #: 01500-0516B Required per assembly: 1 $2.27 $2.04 - + Add to cart
5	LEVER, SET, THROTTLE Part #: 13541-13E00 Required per assembly: 1 Not Available
6	WASHER Part #: 13575-38200 Required per assembly: 1 Not Available
7	PLATE Part #: 13447-14A00 Required per assembly: 1 Not Available
8	SCREW Part #: 02112-3410A Required per assembly: 2 $2.39 $2.15 - + Add to cart
9	SPRING Part #: 13446-14A00 Required per assembly: 1 Not Available
10	CONNECTOR Part #: 13398-27A02 Required per assembly: 1 Not Available
11	SCREW Part #: 02112-0312B Required per assembly: 2 Not Available
12	WASHER Part #: 13445-14A00 Required per assembly: 2 Note: GASKET; $3.57 $3.21 - + Add to cart
13	WASHER (4.5X8X0.5) Part #: 09160-04024 Required per assembly: 1 Not Available
14	E RING Part #: 13415-38300 Required per assembly: 1 $2.36 $2.12 - + Add to cart
15	VALVE, PISTON, (CA:1.5) Part #: 13551-14D00 Required per assembly: 1 Not Available
16	GASKET Part #: 13382-47010 Required per assembly: 1 Note: WASHER; $25.49 $21.79 - + Add to cart
17	NEEDLE CLIP Part #: 13394-10010 Required per assembly: 1 Note: E RING $5.90 $5.31 - + Add to cart
18	NEEDLE, JET, (6FN83-3) Part #: 13383-15D00 Required per assembly: 1 $21.62 $18.48 - + Add to cart
19	JET, NEEDLE, (P-9) Part #: 09494-00683 Required per assembly: 1 Not Available
21	SPRING Part #: 13494-14D00 Required per assembly: 1 $9.54 $8.59 - + Add to cart
22	PLUNGER ASSEMBLY Part #: 13411-14D00 Required per assembly: 1 Not Available
23	O RING Part #: 13278-47091 Required per assembly: 1 $2.39 $2.15 - + Add to cart
24	SCREW, PILOT, (2, 7/8) Part #: 13279-47070 Required per assembly: 1 Note: SCREW, PILOT (1 1/2); $17.25 $14.75 - + Add to cart
25	SPRING Part #: 13268-47070 Required per assembly: 1 $5.60 $5.04 - + Add to cart
26	GASKET Part #: 13291-29900 Required per assembly: 1 Note: WASHER; $2.19 $1.97 - + Add to cart
27	O RING Part #: 13295-29901 Required per assembly: 1 $5.60 $5.04 - + Add to cart
28-2	JET, PILOT, (42.5) Part #: 09492-42017 Required per assembly: 1 Note: FOR 13200-15D01,13200-15E80 Not Available
29	RING Part #: 13331-13A00 Required per assembly: 1 $6.66 $5.99 - + Add to cart
30-1	JET, MAIN, (132.5) Part #: 09491-26011 Required per assembly: 1 Note: JET, MAIN (130.0); $11.97 $10.77 - + Add to cart
30-2	JET, MAIN, (127.5) Part #: 09491-25011 Required per assembly: 1 $11.97 $10.77 - + Add to cart
30-3	JET, MAIN, (125) Part #: 09491-25010 Required per assembly: 1 $11.58 $10.42 - + Add to cart
31	VALVE, ASSEMBLY, NEEDLE Part #: 13370-05530 Required per assembly: 1 $80.59 $68.90 - + Add to cart
32	O RING Part #: 13374-35C00 Required per assembly: 1 $7.73 $6.96 - + Add to cart
33	FILTER Part #: 13376-19F00 Required per assembly: 1 $13.28 $11.95 - + Add to cart
34	SCREW Part #: 13602-43410 Required per assembly: 1 $3.67 $3.30 - + Add to cart
35	FLOAT Part #: 13250-28A00 Required per assembly: 1 $41.00 $35.04 - + Add to cart
36	PIN, FLOAT Part #: 13254-92311 Required per assembly: 1 $7.40 $6.66 - + Add to cart
37	O RING Part #: 13251-27A00 Required per assembly: 1 $9.50 $8.55 - + Add to cart
38	HOSE Part #: 09355-30001-600 Required per assembly: 1 Note: HOSE (3X7X600); L:600->250 $10.94 $9.85 - + Add to cart
39	ADJUSTER Part #: 13267-14D00 Required per assembly: 1 Not Available
40	RING Part #: 13331-13E00 Required per assembly: 1 $7.18 $6.46 - + Add to cart
41	SPRING Part #: 13268-14D00 Required per assembly: 1 Not Available
43	SCREW, DRAIN Part #: 13247-02340 Required per assembly: 1 $6.44 $5.80 - + Add to cart
44	CAP Part #: 13499-44500 Required per assembly: 1 Note: BOOT; $14.20 $12.78 - + Add to cart
45	ROD Part #: 13487-14A00 Required per assembly: 1 $11.76 $10.58 - + Add to cart
46	PLUNGER Part #: 13493-27A00 Required per assembly: 1 $11.37 $10.23 - + Add to cart
47	SPRING Part #: 13271-09400 Required per assembly: 1 $5.80 $5.22 - + Add to cart
48	BOLT Part #: 13613-14A00 Required per assembly: 1 $9.54 $8.59 - + Add to cart
49	LEVER Part #: 13490-14A00 Required per assembly: 1 $11.65 $10.49 - + Add to cart
51-1	HOSE, 5X8.2X600 Part #: 44420-44AR0 Required per assembly: 2 Note: L:600->290 $11.28 $10.15 - + Add to cart
51-2	HOSE, 5X8.2X600 Part #: 44420-44AR0 Required per assembly: 2 Note: L:600->290 $11.28 $10.15 - + Add to cart
52	JOINT, 3, WAY Part #: 09367-06002 Required per assembly: 1 Note: 3 WAY; $2.94 $2.65 - + Add to cart
53-1	HOSE, 5X8.2X600 Part #: 44420-44AR0 Required per assembly: 1 Note: L:600->290 $11.28 $10.15 - + Add to cart
53-2	HOSE, 5X8.2X600 Part #: 44420-44AR0 Required per assembly: 1 Note: L:600->290 $11.28 $10.15 - + Add to cart
54	CLIP Part #: 13692-19C00 Required per assembly: 1 Not Available
55	JET, AIR, (0.6) Part #: 09493-60004 Required per assembly: 1 Note: JET, MAIN AIR (0.6); $17.72 $15.95 - + Add to cart
56	JET, AIR, (1.3) Part #: 09493-26004 Required per assembly: 1 Note: JET, PILOT AIR (1.3); $17.88 $15.29 - + Add to cart
57	CLAMP (L:65) Part #: 09404-06039 Required per assembly: 1 Note: CLAMP (L:45); $10.57 $9.51 - + Add to cart
