Alternator replacement parts for 1995 Suzuki RF900R

OEM Parts Suzuki 1995 Suzuki RF900R Alternator

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1-1	ALTERNATOR ASSEMBLY Part #: 31400-17E02 Required per assembly: 1 Note: MODEL R Not Available
1-2	ALTERNATOR ASSEMBLY Part #: 31400-17E30 Required per assembly: 1 Not Available
3	BEARING Part #: 31612-06B00 Required per assembly: 1 Not Available
4	COVER, BEARING Part #: 31613-48B00 Required per assembly: 1 Not Available
5	RETAINER, BEARING Part #: 31585-85251 Required per assembly: 1 Not Available
7-1	ROTOR ASSEMBLY Part #: 31710-17E02 Required per assembly: 1 Note: MODEL R Not Available
7-2	ROTOR ASSEMBLY Part #: 31710-17E30 Required per assembly: 1 Not Available
8	COVER (1) Part #: 31613-82610 Required per assembly: 1 Note: COVER, BEARING; Not Available
9	BEARING Part #: 31612-48B00 Required per assembly: 1 $50.85 $43.46 - + Add to cart
10	COVER (2) Part #: 31613-27A10 Required per assembly: 1 Note: COVER, NO.2; Not Available
11	FRAME, END Part #: 31611-17E00 Required per assembly: 1 Not Available
13	HOLDER, RECTIFIER Part #: 31621-27A00 Required per assembly: 1 Not Available
14	REGULATOR Part #: 32500-27A00 Required per assembly: 1 Not Available
15	HOLDER, BRUSH Part #: 31656-48B00 Required per assembly: 1 Not Available
16	BUSH Part #: 31687-17E00 Required per assembly: 1 $7.44 $6.70 - + Add to cart
17	LEAD WIRE Part #: 31480-17E00 Required per assembly: 1 Not Available
18	SCREW Part #: 02112-0406B Required per assembly: 2 $1.94 $1.75 - + Add to cart
20	COVER Part #: 31614-17E00 Required per assembly: 1 Not Available
21	NUT Part #: 08310-0005A Required per assembly: 2 Note: MODEL K4/K5/K6/K7 $2.22 $2.00 - + Add to cart
22-1	OIL SEAL SET Part #: 31780-27X50 Required per assembly: 1 Note: SERVICE KIT, A; FOR O RING $58.14 $49.70 - + Add to cart
22-2	OIL SEAL SET Part #: 31780-27X50 Required per assembly: 1 Note: SERVICE KIT, A; FOR O RING $58.14 $49.70 - + Add to cart
23	SCREW Part #: 02112-0508A Required per assembly: 3 $1.78 $1.60 - + Add to cart
24	LOCK WASHER Part #: 08321-0105A Required per assembly: 3 $2.29 $2.06 - + Add to cart
25	WASHER Part #: 08322-0105A Required per assembly: 3 $2.22 $2.00 - + Add to cart
26	O RING Part #: 31156-17E00 Required per assembly: 1 $5.94 $5.35 - + Add to cart
27	BOLT Part #: 07120-0865B Required per assembly: 3 $4.93 $4.44 - + Add to cart
28	GEAR, GENERATOR, DRIVEN, (NT:30 Part #: 22730-21E00 Required per assembly: 1 Not Available
29	HOUSING, DAMPER Part #: 22734-21E01 Required per assembly: 1 Not Available
30	DAMPER Part #: 21231-17E10 Required per assembly: 8 Not Available
32	WASHER Part #: 08211-12243 Required per assembly: 1 Not Available
33	NUT Part #: 09159-12010 Required per assembly: 1 Not Available
34	SHAFT, GENERATOR, DRIVE Part #: 22732-21E00 Required per assembly: 1 Note: MODEL R/S Not Available
35	BEARING Part #: 09262-25110 Required per assembly: 1 Note: MODEL R/S Not Available
36	CIRCLIP, SUB, T/M, GEAR Part #: 08331-31259 Required per assembly: 1 Note: CIRCLIP, RR FINAL DRIVE; $2.62 $2.36 - + Add to cart
37	C RING Part #: 09390-52003 Required per assembly: 1 Note: C RING, GENERATOR DRIVE; $2.68 $2.41 - + Add to cart
38	SHAFT, GENERATOR, DRIVE Part #: 22732-46E00 Required per assembly: 1 Not Available
39	HUB, GENERATOR, DRIVE Part #: 22736-46E01 Required per assembly: 1 Not Available
40	COUPLING, GENERATOR Part #: 22740-46E02 Required per assembly: 1 $65.11 $55.66 - + Add to cart
41	BEARING (25X52X13) Part #: 09262-25116 Required per assembly: 1 Not Available
