Shroud replacement parts for 1995 Yamaha VT 480

OEM Parts Yamaha 1995 Yamaha VT 480 Shroud

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

2	LINING SET Part #: 8BK-W7726-00-00 Required per assembly: 1 Not Available
3	LINING SHROUD 1 Part #: 88T-77261-00-00 Required per assembly: 1 Not Available
4	LINING SHROUD 2 Part #: 88T-77262-00-00 Required per assembly: 1 Not Available
5	LINING SHROUD 3 Part #: 88T-77263-00-00 Required per assembly: 1 Not Available
6	LINING SHROUD 4 Part #: 88T-77264-00-00 Required per assembly: 1 Not Available
7	LINING SHROUD 7 Part #: 88T-77267-00-00 Required per assembly: 2 Not Available
8	DAMPER, NOISE, 18 Part #: 8V0-77278-01-00 Required per assembly: 1 Not Available
9	DAMPER, NOISE, 19 Part #: 8V0-77279-00-00 Required per assembly: 1 Not Available
10	LINING SHROUD 4 Part #: 8H7-77264-00-00 Required per assembly: 1 Not Available
11	DAMPER, NOISE Part #: 88T-77277-00-00 Required per assembly: 1 Not Available
12	BODY, LATCH, 1 Part #: 8V0-77171-00-00 Required per assembly: 2 ~~$23.98~~ $20.93 - + Add to cart
13	COLLAR Part #: 90387-06241-00 Required per assembly: 2 ~~$9.49~~ $8.33 - + Add to cart
14	WASHER, PLATE, 8221447500 Part #: 90201-06057-00 Required per assembly: 4 ~~$6.49~~ $5.24 - + Add to cart
15	BOLT, SOCKET Part #: 98907-06030-00 Required per assembly: 2 ~~$9.49~~ $8.02 - + Add to cart
16	SCREW, BINDING Part #: 98907-06016-00 Required per assembly: 2 ~~$10.49~~ $9.50 - + Add to cart
17	STOPPER, SHROUD Part #: 88T-77118-01-00 Required per assembly: 1 Not Available
18	CLAMP, ROD Part #: 80L-77159-00-00 Required per assembly: 1 Note: (USA) Not Available
19	DAMPER, NOISE, 15 Part #: 8V0-77275-00-00 Required per assembly: 1 Not Available
20	WASHER, PLAIN Part #: 92907-05200-00 Required per assembly: 2 $5.67 - + Add to cart
21	CLAMP Part #: 90465-20145-00 Required per assembly: 2 Note: (USA) Not Available
22	SCREW, TRUSS, HEAD, TAPPING Part #: 97707-50016-00 Required per assembly: 2 ~~$1.85~~ $1.41 - + Add to cart
23	DAMPER 1 Part #: 88T-77198-00-00 Required per assembly: 2 Not Available
24	HINGE ASSEMBLY Part #: 88T-77140-00-00 Required per assembly: 1 ~~$41.99~~ $36.68 - + Add to cart
25	HINGE ASY 2 Part #: 88T-7714A-00-00 Required per assembly: 1 ~~$41.99~~ $36.68 - + Add to cart
26	NUT, FLANGE, (4MV) Part #: 95707-06500-00 Required per assembly: 4 $1.13 - + Add to cart
27	SCREW, WITH, WASHER Part #: 90159-06060-00 Required per assembly: 4 ~~$9.49~~ $8.31 - + Add to cart
28	STOPPER Part #: 8V0-77188-00-00 Required per assembly: 2 ~~$7.99~~ $5.64 - + Add to cart
29	WASHER, SPECIAL Part #: 8V0-77116-01-00 Required per assembly: 2 $9.27 - + Add to cart
30	RIVET, BLIND Part #: 90267-40077-00 Required per assembly: 4 Not Available
32	HOOD 2 Part #: 8BK-21983-00-00 Required per assembly: 1 Not Available
33	BOLT, WITH, WASHER Part #: 90119-06226-00 Required per assembly: 10 $3.03 - + Add to cart
34	NUT, SPRING Part #: 90183-06023-00 Required per assembly: 10 ~~$10.49~~ $9.87 - + Add to cart
35	RIVET, SPEC'L, SHAPE Part #: 90269-05055-00 Required per assembly: 2 Note: Sold in multiples of 5 only ~~$9.49~~ $9.35 - + Add to cart
37	BOLT, WITH, WASHER, (55K) Part #: 90119-06117-00 Required per assembly: 2 ~~$5.49~~ $5.20 - + Add to cart
38	WASHER, PLATE Part #: 90201-06020-00 Required per assembly: 2 ~~$10.49~~ $8.46 - + Add to cart
39	WASHER, PLATE Part #: 90202-06008-00 Required per assembly: 2 ~~$5.49~~ $5.43 - + Add to cart
40	BOLT, WING Part #: 90122-06020-00 Required per assembly: 2 ~~$8.49~~ $6.83 - + Add to cart
41	BUSH, RUBBER, 1 Part #: 87F-77515-00-00 Required per assembly: 2 Not Available
42	RIVET, SPEC'L, SHAPE Part #: 90269-05055-00 Required per assembly: 10 Note: Sold in multiples of 5 only ~~$9.49~~ $9.35 - + Add to cart
43	TRIM 1 Part #: 8V0-2196T-00-00 Required per assembly: 2 Not Available
44	RIVET, BLIND Part #: 90267-40029-00 Required per assembly: 8 ~~$9.49~~ $8.93 - + Add to cart
45	WASHER, PLATE, (26H) Part #: 90201-044H9-00 Required per assembly: 8 ~~$9.49~~ $8.93 - + Add to cart
46	WASHER, PLATE Part #: 90201-047A2-00 Required per assembly: 8 ~~$4.00~~ $3.92 - + Add to cart
47	HOOD 3 Part #: 8BK-2197H-00-00 Required per assembly: 1 Not Available
48	HOOD 4 Part #: 8BK-2198H-00-00 Required per assembly: 1 Not Available
49	BRACKET, 1 Part #: 88F-2194X-00-00 Required per assembly: 4 Not Available
50	BRACKET 2 Part #: 88R-2195X-00-00 Required per assembly: 2 Not Available
51	BRACKET 3 Part #: 88F-2196F-00-00 Required per assembly: 2 $14.65 - + Add to cart
52	RIVET, BLIND, (48X123) Part #: 90267-48059-00 Required per assembly: 8 Note: (4.8X12.3) (4.8X12.3) ~~$3.54~~ $3.48 - + Add to cart
53	RIVET, BLIND Part #: 90267-48057-00 Required per assembly: 8 Note: UN Not Available
54	WASHER, PLATE, (90201-04325-00, ) Part #: 90201-044R6-00 Required per assembly: 4 Not Available
55	PROTECTOR 3 Part #: 87F-77553-01-00 Required per assembly: 1 Note: (LH) Not Available
56	PROTECTOR 4 Part #: 87F-77554-01-00 Required per assembly: 1 Note: (RH) $8.14 - + Add to cart
57	RIVET, BLIND Part #: 90267-48088-00 Required per assembly: 4 $4.36 - + Add to cart
58	WASHER, PLAIN Part #: 92907-05200-00 Required per assembly: 2 $5.67 - + Add to cart
59	PROTECTOR 1 Part #: 85L-77551-00-00 Required per assembly: 1 Not Available
60	PROTECTOR 2 Part #: 85L-77552-00-00 Required per assembly: 1 Not Available
61	WASHER, PLATE Part #: 90201-05029-00 Required per assembly: 4 ~~$8.49~~ $5.17 - + Add to cart
62	NUT, FLANGE, (4GB) Part #: 95707-05300-00 Required per assembly: 4 ~~$4.54~~ $3.86 - + Add to cart
63	BUSH, RUBBER, 2 Part #: 8V0-77516-01-00 Required per assembly: 2 Not Available
64	RIVET, SPEC'L, SHAPE Part #: 90269-05055-00 Required per assembly: 8 Note: Sold in multiples of 5 only ~~$9.49~~ $9.35 - + Add to cart
65	HOLDER, LATCH Part #: 8V0-77175-00-00 Required per assembly: 2 ~~$19.48~~ $18.54 - + Add to cart
66	PLATE Part #: 4U5-2176E-00-00 Required per assembly: 2 $8.63 - + Add to cart
76	LINING, SHROUD, 5 Part #: 87F-77265-01-00 Required per assembly: 1 Not Available
77	LINING, SHROUD, 6 Part #: 87F-77266-01-00 Required per assembly: 1 Not Available
78	DAMPER, NOISE, 16 Part #: 87F-77276-01-00 Required per assembly: 1 Not Available
79	TAPE 1 Part #: 8V0-7717E-01-00 Required per assembly: 1 $4.13 - + Add to cart
80	TAPE 1 Part #: 8V0-7717F-01-00 Required per assembly: 1 Not Available
81	TAPE 3 Part #: 82M-7717G-01-00 Required per assembly: 1 Not Available
82	DAMPER, NOISE, 12 Part #: 87F-77272-00-00 Required per assembly: 1 Not Available
83	DAMPER, NOISE, 13 Part #: 87F-77273-00-00 Required per assembly: 1 $16.19 - + Add to cart
85	LINING, SHROUD, 6 Part #: 8V0-77266-01-00 Required per assembly: 1 Not Available
