Carburetor Optional Kit 97-98 replacement parts for 1997 Honda CR250R

OEM Parts Honda 1997 Honda CR250R Carburetor Optional Kit 97-98

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	PARTS KIT Part #: 16020-KZ3-B11 Not Available
002	SPRING Part #: 16051-KA3-761 Not Available
003	COLR, SPRING, SETTING Part #: 16066-KA3-761 Not Available
004	CLIP, BAR Part #: 16115-GHB-610 $4.00 $3.64 - + Add to cart
005	GASKET, FLOAT, CHAMBER Part #: 16163-KZ3-B10 Not Available
006	NDL, JET, (R1368MS) Part #: 16012-KZ3-690 Not Available
006	NDL, JET, (R1370MS) Part #: 16204-KZ3-690 Not Available
006	NDL, JET, (R1366MS) Part #: 16201-KZ3-690 Not Available
006	NDL, JET, (R1367MS) Part #: 16202-KZ3-690 Not Available
006	NDL, JET, (R1372MS) Part #: 16204-KZ3-B10 Not Available
006	NDL, JET, (R1371MS) Part #: 16205-KZ3-880 Not Available
007	SCREW-WASHER (4X16) Part #: 93892-04016-08 Required per assembly: 4 $1.79 $1.65 - + Add to cart
008	JET, SLOW, (#58) Part #: 99103-KA3-0580 Not Available
008	JET, SLOW, (#60) Part #: 99103-KA3-0600 Not Available
008	JET, SLOW, (#52) Part #: 99103-440-0520 Not Available
008	JET, SLOW, (#50) Part #: 99103-440-0500 $14.54 $13.69 - + Add to cart
009	JET, POWER, (#38) Part #: 99105-KZ3-0380 $7.02 $6.60 - + Add to cart
009	JET, POWER, (#48) Part #: 99105-KZ3-0480 Not Available
010	JET, MAIN, (#172) Part #: 99101-357-1720 $10.91 $9.33 - + Add to cart
010	JET, MAIN, (#170) Part #: 99101-357-1700 Required per assembly: 1 $10.91 $9.33 - + Add to cart
010	JET, MAIN, (#168) Part #: 99113-GHB-1680 $10.91 $9.33 - + Add to cart
010	JET, MAIN, (#165) Part #: 99113-GHB-1650 $10.91 $9.33 - + Add to cart
010	JET, MAIN, (#178) Part #: 99113-GHB-1780 $10.91 $9.33 - + Add to cart
010	JET, MAIN, (#180) Part #: 99113-GHB-1800 $10.91 $9.33 - + Add to cart
010	JET, MAIN, (#182) Part #: 99113-GHB-1820 Not Available
010	JET, MAIN, (#185) Part #: 99113-GHB-1850 Required per assembly: 1 $10.03 $9.12 - + Add to cart
