Left Crankcase Cover replacement parts for 1998 Honda XR250R

OEM Parts Honda 1998 Honda XR250R Left Crankcase Cover

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	COVER, L., CRANKCASE Part #: 11341-KCE-670 Required per assembly: 1 Not Available
002	COVER, DRIVE, SPROCKET Part #: 11351-KCE-670 Required per assembly: 1 ~~$28.51~~ $24.95 - + Add to cart
003	GUIDE, DRIVE, CHAIN Part #: 11352-KK0-000 Required per assembly: 1 Not Available
004	GASKET, L. Part #: 11395-KW3-882 Required per assembly: 1 ~~$18.44~~ $18.16 - + Add to cart
005	BOLT, FLANGE, (6X32) Part #: 90004-GHB-690 Required per assembly: 4 $5.65 - + Add to cart
006	BOLT, FLANGE, (6X50) Part #: 90004-GHB-730 Required per assembly: 4 $6.71 - + Add to cart
007	CAP (14MM) Part #: 90084-MN8-010 Required per assembly: 1 $15.90 - + Add to cart
008	CAP (30MM) Part #: 90087-HB5-000 Required per assembly: 1 $19.43 - + Add to cart
009	O-RING (13.8X2.5) Part #: 91303-377-000 Required per assembly: 1 $5.04 - + Add to cart
010	O-RING (27X2) Part #: 91305-KF0-003 Required per assembly: 1 $4.16 - + Add to cart
011	PIN, DOWEL, (8X14) Part #: 94301-08140 Required per assembly: 2 $4.05 - + Add to cart
012	BOLT, FLANGE, (6X16) Part #: 96001-06016-00 Required per assembly: 4 ~~$2.09~~ $1.46 - + Add to cart
013	BOLT, FLANGE, (6X22) Part #: 96001-06022-00 Required per assembly: 2 ~~$2.27~~ $1.72 - + Add to cart
