Air Cleaner (Ac) replacement parts for 2000 Honda XR250R

OEM Parts Honda 2000 Honda XR250R Air Cleaner (Ac)

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	CLIP, OIL, DRAIN, TUBE Part #: 15707-634-000 Required per assembly: 1 $6.17 $5.26 - + Add to cart
002	ELEMENT, AIR, CLEANER Part #: 17213-MN1-670 Required per assembly: 1 $34.12 $27.22 - + Add to cart
003	HOLDER, ELEMENT Part #: 17214-MN1-670 Required per assembly: 1 $76.60 $63.86 - + Add to cart
004	SPRING Part #: 17216-KCZ-000 Required per assembly: 1 Not Available
005	PLATE, HOLDER Part #: 17217-KCZ-000 Required per assembly: 1 $8.16 $7.00 - + Add to cart
006	SEAL Part #: 17219-KCZ-000 Required per assembly: 1 $8.57 $7.33 - + Add to cart
007	LID NH1 (BLACK) Part #: 17220-KCZ-010ZB Required per assembly: 1 Not Available
008	TUBE Part #: 17222-KCE-770 Required per assembly: 1 Not Available
009	WASHER Part #: 17224-KN5-670 Required per assembly: 1 $2.37 $2.19 - + Add to cart
010	STUD (6X21) Part #: 17225-KN5-671 Required per assembly: 1 $8.40 $7.30 - + Add to cart
011	HOUSING NH1 (BLACK) Part #: 17230-KCZ-020ZB Required per assembly: 1 Not Available
012	DUCT Part #: 17240-KCY-670 Required per assembly: 1 Not Available
013	CAP, IN., DUCT Part #: 17241-KCE-671 Required per assembly: 1 Not Available
014	SPLASH, GUARD, A/CLNR Part #: 17245-KCZ-000 Required per assembly: 1 $28.37 $22.63 - + Add to cart
015	CLIP A Part #: 17316-MN1-670 Required per assembly: 3 $3.48 $3.16 - + Add to cart
016	CLIP, BREATHER, TUBE Part #: 17316-611-000 Required per assembly: 1 $10.71 $9.95 - + Add to cart
017	TUBE, DRAIN Part #: 17359-KK0-000 Required per assembly: 1 $7.97 $6.95 - + Add to cart
018	JOINT, BREATHER, TUBE Part #: 17359-428-000 Required per assembly: 1 $6.57 $5.81 - + Add to cart
019	TUBE, A, BREATHER Part #: 17361-KCZ-000 Required per assembly: 1 Not Available
020	TUBE, B, BREATHER Part #: 17362-KCZ-000 Required per assembly: 1 Not Available
021	TUBE, BREATHER, DRAIN Part #: 17363-KCZ-950 Required per assembly: 1 Not Available
022	PLUG, BREATHER, TUBE Part #: 17370-419-700 Required per assembly: 1 $5.10 $4.64 - + Add to cart
023	TANK, STORAGE Part #: 17551-KCZ-000 Required per assembly: 1 $27.05 $21.90 - + Add to cart
024	CLIP, SUB-TANK, HOSE Part #: 17724-MN1-670 Required per assembly: 5 $4.47 $4.06 - + Add to cart
025	WASHER Part #: 33745-GB6-970 Required per assembly: 2 $5.33 $5.31 - + Add to cart
026	CLAMP Part #: 43514-KS6-701 Required per assembly: 1 $15.21 $12.67 - + Add to cart
027	PIN, VISOR, HINGE Part #: 64308-GG2-000 Required per assembly: 1 $8.82 $7.63 - + Add to cart
028	BOLT (6X12) Part #: 90009-MF5-000 Required per assembly: 1 $4.25 - + Add to cart
029	BOLT, FLANGE, (6MM) Part #: 90116-ME9-000 Required per assembly: 2 $4.68 $4.25 - + Add to cart
030	NUT, CLIP, (6MM) Part #: 90311-MT3-000 Required per assembly: 5 $6.94 $6.13 - + Add to cart
031	SCREW, TAP, (5X16) Part #: 93903-25310 Required per assembly: 2 $1.72 $1.58 - + Add to cart
032	SCREW, TAP, (5X10) Part #: 93913-25180 Required per assembly: 6 $2.04 $1.88 - + Add to cart
033	E-RING (3MM) Part #: 94540-03010 Required per assembly: 2 $2.13 $1.97 - + Add to cart
034	BAND (52) Part #: 95018-52250 Required per assembly: 1 $6.18 $5.50 - + Add to cart
035	BOLT, FLANGE, (6X12) Part #: 96300-06012-00 Required per assembly: 1 $1.98 $1.83 - + Add to cart
036	BOLT, FLANGE, (6X16) Part #: 96300-06016-00 Required per assembly: 1 $1.98 $1.83 - + Add to cart
037	CLIP, OIL, DRAIN, TUBE Part #: 15771-KV6-000 Required per assembly: 2 $5.09 $4.63 - + Add to cart
