Brake Pedal replacement parts for 2000 Honda XR600R

OEM Parts Honda 2000 Honda XR600R Brake Pedal

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	PEDAL, ASSEMBLY, CHANGE Part #: 24700-MN1-000 Required per assembly: 1 Not Available
002	JOINT, KICK, ARM Part #: 28241-MN1-671 Required per assembly: 1 Not Available
003	ARM, KICK, STARTER Part #: 28300-MN1-671 Required per assembly: 1 $168.74 $153.40 - + Add to cart
004	SPRING Part #: 28333-124-000 Required per assembly: 1 $3.22 $3.00 - + Add to cart
005	PEDAL, BRAKE Part #: 46500-MN1-710 Required per assembly: 1 Not Available
006	SPRING, BRAKE, PEDAL Part #: 46515-MN1-680 Required per assembly: 1 $10.35 $8.88 - + Add to cart
007	BAR, SIDE, STAND Part #: 50530-MN1-670 Required per assembly: 1 Not Available
008	SPRING, SIDE, STAND Part #: 50535-KN5-670 Required per assembly: 1 $7.86 $6.85 - + Add to cart
009	WASHER, BUSH Part #: 53312-657-000 Required per assembly: 1 $8.05 $6.86 - + Add to cart
010	BOLT, KICK, ARM Part #: 90101-KN5-670 Required per assembly: 1 Not Available
011	BOLT, FLANGE, (6X20) Part #: 90102-MN1-670 Required per assembly: 1 $4.18 $3.80 - + Add to cart
012	SCREW Part #: 90108-KG0-000 Required per assembly: 1 $8.24 - + Add to cart
013	NUT, U, (10MM) Part #: 90304-GE8-003 Required per assembly: 1 Note: Sold in multiples of 5 only $4.58 - + Add to cart
014	DUST SEAL (15X20X3) Part #: 91251-MT4-003 Required per assembly: 2 $5.17 $4.70 - + Add to cart
015	DUST (19X25X4.1) Part #: 91303-KA3-732 Required per assembly: 1 $6.66 $5.88 - + Add to cart
016	PIN, SPLIT, (2.5X30) Part #: 94201-25300 Required per assembly: 1 $2.07 $1.91 - + Add to cart
018	BALL (#8) (1/4) Part #: 96211-08000 Required per assembly: 2 $2.30 $2.13 - + Add to cart
019	BOLT, FLANGE, (8X28) Part #: 96300-08028-00 Required per assembly: 1 $2.78 $2.58 - + Add to cart
