Front Bevel Gear replacement parts for 2000 Kawasaki Prairie 400 (KVF400-D2)

OEM Parts Kawasaki 2000 Kawasaki Prairie 400 (KVF400 D2) Front Bevel Gear

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

172	BOLT-STUD, 8X30 Part #: 172BA0830 Required per assembly: 4 $2.65 $1.92 - + Add to cart
601	BEARING-BALL Part #: 601A6209 Required per assembly: 1 Not Available
11060	GASKET, GEAR, CASE Part #: 11060-1728 Required per assembly: 1 $10.85 $9.19 - + Add to cart
13048	CAM-DAMPER Part #: 13048-1080 Required per assembly: 1 Not Available
13091	HOLDER Part #: 13091-1950 Required per assembly: 1 Not Available
13107	SHAFT Part #: 13107-1364 Required per assembly: 1 Not Available
14055	CASE-GEAR Part #: 14055-1127 Required per assembly: 1 Not Available
16115	CAP-OIL FILLER Part #: 16115-1065 Required per assembly: 1 $17.94 $14.96 - + Add to cart
41046	HOUSING-BEARING Part #: 41046-1094 Required per assembly: 1 Not Available
49022	GEAR-BEVEL, 14T Part #: 49022-1151 Required per assembly: 1 Not Available
49022A	GEAR-BEVEL, 20T Part #: 49022-1180 Required per assembly: 1 Not Available
92009	SCREW, SET, 75X10 Part #: 92172-0341 Required per assembly: 1 $90.09 $82.58 - + Add to cart
92015	NUT, 8MM Part #: 92015-1402 Required per assembly: 4 $4.82 $3.79 - + Add to cart
92015A	NUT, 16MM Part #: 92015-1581 Required per assembly: 1 $19.99 $16.65 - + Add to cart
92015B	NUT, 30MM Part #: 92015-1858 Required per assembly: 1 $33.58 $31.12 - + Add to cart
92015C	NUT, 26MM Part #: 92015-1990 Required per assembly: 1 Not Available
92025	SHIM, 25.3X36X0.15 Part #: 92025-1688 Note: Sold in multiples of 2 only $8.83 $7.60 - + Add to cart
92025A	SHIM, 25.3X36X0.50 Part #: 92025-1689 $8.83 $7.60 - + Add to cart
92025B	SHIM, 25.3X36X0.60 Part #: 92025-1690 Note: Sold in multiples of 2 only $8.83 $7.60 - + Add to cart
92025C	SHIM, 25.3X36X0.70 Part #: 92025-1691 $8.83 $7.60 - + Add to cart
92025D	SHIM, 25.3X36X0.80 Part #: 92025-1692 Note: Sold in multiples of 2 only $8.83 $7.60 - + Add to cart
92025E	SHIM, 25.3X36X0.90 Part #: 92025-1693 $8.83 $7.60 - + Add to cart
92025F	SHIM, 25.3X36X1.00 Part #: 92025-1694 $8.83 $7.60 - + Add to cart
92025G	SHIM, 25.3X36X1.10 Part #: 92025-1695 $8.83 $7.60 - + Add to cart
92025H	SHIM, 25.3X36X1.20 Part #: 92025-1696 $8.83 $7.60 - + Add to cart
92027	COLLAR, 25.3X36X10 Part #: 92027-1968 Required per assembly: 1 Not Available
92043	PIN, DOWEL, 10X14 Part #: 92043-1037 Required per assembly: 1 Note: Sold in multiples of 5 only $0.79 $0.69 - + Add to cart
92045	BEARING-BALL, 6306SH2 Part #: 92045-1190 Required per assembly: 1 $41.58 $38.21 - + Add to cart
92049	SEAL-OIL, AE1252E0 Part #: 92049-1395 Required per assembly: 1 $11.88 $10.07 - + Add to cart
92049A	SEAL-OIL, AE1265E0 Part #: 92049-1400 Required per assembly: 1 $11.88 $10.07 - + Add to cart
92055	RING-O Part #: 92055-081 Required per assembly: 1 $18.23 $15.24 - + Add to cart
92055A	RING-O, 79.5MM Part #: 92055-1230 Required per assembly: 1 $8.35 $7.22 - + Add to cart
92055B	RING-O, 20MM Part #: 92055-2185 Required per assembly: 1 $1.09 $0.88 - + Add to cart
92143	COLLAR Part #: 92143-1900 Required per assembly: 1 Not Available
92145	SPRING, BEVEL Part #: 92145-1209 Required per assembly: 1 Not Available
92151	BOLT, 8X100 Part #: 92151-1431 Required per assembly: 2 Not Available
92151A	BOLT, 8X35 Part #: 92151-1432 Required per assembly: 3 Not Available
92151B	BOLT, 8X32 Part #: 92151-1446 Required per assembly: 1 $3.59 $2.54 - + Add to cart
92180	SHIM, T=1.00 Part #: 92180-1126 Not Available
92180A	SHIM, T=0.10 Part #: 92180-1127 Not Available
92180B	SHIM, T=0.15 Part #: 92180-1128 Not Available
92180C	SHIM, T=0.50 Part #: 92180-1129 Not Available
92180D	SHIM, T=0.80 Part #: 92180-1130 Not Available
92180E	SHIM, T=1.20 Part #: 92180-1131 Not Available
92200	WASHER, 16.3X31X3.2 Part #: 92200-1104 Required per assembly: 1 Not Available
