Carburetor replacement parts for 2001 Kawasaki Mule 520 (KAF300-D2)

OEM Parts Kawasaki 2001 Kawasaki Mule 520 (KAF300 D2) Carburetor

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

214	SCREW-PAN+-, 4X14 Part #: 214AA0414 Required per assembly: 1 $0.77 $0.68 - + Add to cart
11009	GASKET, FLOAT, CHAMBER Part #: 11009-2024 Required per assembly: 1 $4.25 $3.23 - + Add to cart
11009A	GASKET Part #: 11009-2025 Required per assembly: 1 $2.06 $1.49 - + Add to cart
11009B	GASKET, CARBURETOR Part #: 11009-2827 Required per assembly: 1 $3.66 $2.52 - + Add to cart
11009C	GASKET, INSULATOR Part #: 11009-2939 Required per assembly: 1 Note: Sold in multiples of 5 only $1.73 $1.28 - + Add to cart
13183	PLATE Part #: 13183-2252 Required per assembly: 1 Not Available
15003	CARBURETOR ASSEMBLY Part #: 15003-2589 Required per assembly: 1 Not Available
16014	SCREW-PILOT AIR Part #: 16014-2076 Required per assembly: 1 $14.83 $12.27 - + Add to cart
16020	CHAMBER-FLOAT Part #: 16020-2005 Required per assembly: 1 Not Available
16025	VALVE-THROTTLE, #165 Part #: 16025-2165 Required per assembly: 1 Not Available
16030	VALVE-FLOAT Part #: 16030-2073 Required per assembly: 1 $23.57 $19.24 - + Add to cart
16031	FLOAT Part #: 16031-2066 Required per assembly: 1 $27.35 $24.29 - + Add to cart
16035	JET-AIR, #1.8 Part #: 16035-2056 Required per assembly: 1 $8.10 $6.69 - + Add to cart
16035A	JET-AIR, #1.3 Part #: 16035-2062 Required per assembly: 1 $8.66 $7.13 - + Add to cart
16038	GASKET, PILOT, JET Part #: 16038-024 Required per assembly: 1 Note: Sold in multiples of 5 only $1.62 $1.23 - + Add to cart
16041	SHAFT-CARBURETOR, THROTTLE Part #: 16041-2203 Required per assembly: 1 $26.27 $21.41 - + Add to cart
16041A	SHAFT-CARBURETOR, CHOKE Part #: 16041-2209 Required per assembly: 1 $21.82 $17.90 - + Add to cart
16073	INSULATOR Part #: 16073-2154 Required per assembly: 1 $5.17 $3.88 - + Add to cart
16126	VALVE, CHOKE Part #: 16126-2207 Required per assembly: 1 Not Available
39076	LIMITER Part #: 39076-2053 Required per assembly: 1 Not Available
49121	NOZZLE-MAIN Part #: 49121-2214 Required per assembly: 1 $20.87 $17.25 - + Add to cart
49123	HOLDER-MAIN JET Part #: 49123-2079 Required per assembly: 1 $19.85 $16.36 - + Add to cart
92002	BOLT Part #: 92002-2008 Required per assembly: 1 Not Available
92004	STUD, 6X80 Part #: 92004-2125 Required per assembly: 2 $3.61 $2.75 - + Add to cart
92009	SCREW, DRAIN Part #: 92009-2015 Required per assembly: 1 $5.05 $3.80 - + Add to cart
92009A	SCREW-PAN-WS-CROS, 3X6 Part #: 223B0306 Required per assembly: 2 Not Available
92009B	SCREW, CHOKE, VALVE Part #: 92009-2081 Required per assembly: 2 Not Available
92009C	SCREW Part #: 92009-2244 Required per assembly: 1 Note: Sold in multiples of 5 only Not Available
92033	RING-SNAP Part #: 92033-2067 Required per assembly: 1 $3.72 $2.57 - + Add to cart
92037	CLAMP Part #: 92037-2081 Required per assembly: 1 $2.51 $1.79 - + Add to cart
92043	PIN, FLOAT Part #: 92043-2006 Required per assembly: 1 $3.14 $2.20 - + Add to cart
92063	JET-MAIN, #102.5 Part #: 92063-2316 Required per assembly: 1 Note: (OPTION) $15.33 $12.60 - + Add to cart
92063A	JET-MAIN, #100 Part #: 92063-2317 Required per assembly: 1 Note: (OPTION) Not Available
92063B	JET-MAIN, #97.5 Part #: 92063-2318 Required per assembly: 1 Note: (OPTION) $15.33 $12.60 - + Add to cart
92063C	JET-MAIN, #105 Part #: 92063-2330 Required per assembly: 1 Note: (OPTION) $15.33 $12.60 - + Add to cart
92063D	JET-MAIN, #107.5 Part #: 92063-2331 Required per assembly: 1 $10.81 $9.13 - + Add to cart
92064	JET-PILOT, #40 Part #: 92064-2118 Required per assembly: 1 $13.22 $10.99 - + Add to cart
92081	SPRING Part #: 92081-2009 Required per assembly: 3 $2.86 $2.02 - + Add to cart
92093	SEAL Part #: 92093-2081 Required per assembly: 1 $2.40 $1.72 - + Add to cart
92093A	SEAL Part #: 92093-2082 Required per assembly: 1 $1.97 $1.43 - + Add to cart
92093B	SEAL Part #: 92093-2083 Required per assembly: 1 Note: Sold in multiples of 5 only $1.79 $1.32 - + Add to cart
92143	COLLAR Part #: 92143-2132 Required per assembly: 1 Not Available
92143A	COLLAR Part #: 92143-2133 Required per assembly: 1 Not Available
92143B	COLLAR Part #: 92143-2134 Required per assembly: 1 Not Available
92144	SPRING Part #: 92144-2269 Required per assembly: 1 $7.91 $6.56 - + Add to cart
92150	BOLT Part #: 92150-2146 Required per assembly: 1 Not Available
92190	TUBE, 6X10X175 Part #: 92190-2051 Required per assembly: 1 $3.74 $2.60 - + Add to cart
