Drive Pulley - A01ea09ca replacement parts for 2001 Polaris Scrambler 90 (A01EA09CA)

OEM Parts Polaris 2001 Polaris Scrambler 90 (A01EA09CA) Drive Pulley - A01ea09ca

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	N/A, USE, COMPONENTS Part #: 9990000 Required per assembly: 1 Currently Not Available
2	SEAL, OIL Part #: 0450211 Required per assembly: 2 Currently Not Available
3	SEAT, SPRING, SECONDARY Part #: 0450219 Required per assembly: 1 Currently Not Available
4	SPRING, COMPRESSION Part #: 0450217 Required per assembly: 1 Currently Not Available
5	SPRING, WEIGHT, CLUTCH Part #: 0450206 Required per assembly: 3 Note: Sold in multiples of 10 only Currently Not Available
6	CARRIER, CLUTCH Part #: 0450204 Required per assembly: 1 Currently Not Available
7	NUT Part #: 0450221 Required per assembly: 1 $6.99 $4.03 - + Add to cart
8	COVER, CLUTCH Part #: 0450223 Required per assembly: 1 Currently Not Available
9	NUT, HEX Part #: 0450224 Required per assembly: 1 Note: Nut $3.99 $2.30 - + Add to cart
10	O-RING Part #: 0450226 Required per assembly: 1 Currently Not Available
11	BEARING Part #: 0450225 Required per assembly: 1 Currently Not Available
12	RING, OIL Part #: 0450213 Required per assembly: 2 Currently Not Available
13	WHEEL, SLOT, SLIDING, SECONDARY Part #: 0450210 Required per assembly: 1 Currently Not Available
14	V-BELT Part #: 0450239 Required per assembly: 1 Currently Not Available
15	WHEEL, SLOT, FIXED, SECONDARY Part #: 0450208 Required per assembly: 1 Currently Not Available
16	PIN, GUIDE Part #: 0450215 Required per assembly: 2 Currently Not Available
17	BEARING, BALL Part #: 0451016 Required per assembly: 1 Currently Not Available
18	CIRCLIP Part #: 0451017 Required per assembly: 1 $3.99 $2.30 - + Add to cart
19	BEARING, NEEDLE Part #: 0451015 Required per assembly: 1 Currently Not Available
20	SEAL, OIL Part #: 0450200 Required per assembly: 1 Currently Not Available
21	CIRCLIP, EXTERNAL Part #: 0450198 Required per assembly: 1 Note: Circlip Sold in multiples of 10 only Currently Not Available
22	WASHER, PLAIN Part #: 0450041 Required per assembly: 1 $3.99 $2.30 - + Add to cart
23	BOLT, SOCKET, HEX Part #: 0450158 Required per assembly: 1 Note: Bolt Sold in multiples of 10 only Currently Not Available
24	BEARING Part #: 0450199 Required per assembly: 1 Currently Not Available
25	ASSEMBLY, PRIMARY, DRIVE Part #: 0450195 Required per assembly: 1 Currently Not Available
26	S-BUSHING, SLIDER, 90 Part #: 0455002 Required per assembly: 3 Currently Not Available
27	PLATE, CAM Part #: 0450232 Required per assembly: 1 Currently Not Available
28	S-ROLLER-WEIGHT 22120112-000 Part #: 0455085 Required per assembly: 6 Currently Not Available
29	WHEEL, SLOT, SLIDING, PRIMARY Part #: 0450228 Required per assembly: 1 Currently Not Available
30	BUSHING Part #: 0450236 Required per assembly: 1 Currently Not Available
31	SHEAVE, FIXED, PRIMARY Part #: 0450241 Required per assembly: 1 Currently Not Available
32	WASHER, CLAW Part #: 0450243 Required per assembly: 1 Currently Not Available
33	CLUTCH, ONE-WAY Part #: 0450245 Required per assembly: 1 Currently Not Available
34	WASHER, SPRING Part #: 0453809 Required per assembly: 1 Currently Not Available
35	NUT, FLANGE Part #: 0450249 Required per assembly: 1 Note: Nut Sold in multiples of 10 only Currently Not Available
36	ASSEMBLY, SLIDING, DRIVE Part #: 0450251 Required per assembly: 1 Note: Asm., Sliding Drive (Incl. 23,24,25,26,27,28,29) Currently Not Available
