MAGNETO - W014699D Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

STATOR

Part #: 4010170 Required per assembly: 1
Currently Not Available
2

SCREW

Part #: 7517714 Required per assembly: 3 Note: Screw
Currently Not Available
3

SCREW

Part #: 7517431 Required per assembly: 1
Currently Not Available
4

CLAMP, STATOR, WIRES

Part #: 5243231 Required per assembly: 1
Currently Not Available
5

O-RING

Part #: 5411320 Required per assembly: 1
Currently Not Available
6

HOLDER, MAGNET

Part #: 5432282 Required per assembly: 1
Currently Not Available
7

ASSEMBLY, FLYWHEEL

Part #: 4010189 Required per assembly: 1
$364.99
$188.89
-
+
Add to cart
8

KIT, TIMING, SCREWS

Part #: 2201228 Required per assembly: 1
Currently Not Available
9

WASHER

Part #: 7555907 Required per assembly: 1
Currently Not Available
10

NUT

Part #: 7546909 Required per assembly: 1
Currently Not Available
11

HARNESS-9, WIRE, STATOR, 3CYL, PVL

Part #: 2460875 Required per assembly: 1
Currently Not Available
12

CONTROLLER-IGN, 3CYL, PWC, PVL, 01

Part #: 4010543 Required per assembly: 1
Currently Not Available
13

COIL, IGNITION, TRIPLE

Part #: 4010342 Required per assembly: 1
Currently Not Available
14

SWITCH, MAGNETIC

Part #: 3240204 Required per assembly: 1
Currently Not Available
15

WIRE, SPARK, PLUG, (INCL., 15)

Part #: 4010173-71 Required per assembly: 1
Currently Not Available
16

STRAP PANDUIT

Part #: 7080138 Required per assembly: 6
$1.99
$1.15
-
+
Add to cart
17

STRAP, PANDUIT, 4, IN.

Part #: 7080483 Required per assembly: 3
Currently Not Available
18

WIRE, SPARK, PLUG

Part #: 4010173-56 Required per assembly: 1
Currently Not Available
19

WIRE, SPARK, PLUG

Part #: 4010173-42 Required per assembly: 1
Currently Not Available
