Gearcase - A01ag25ca replacement parts for 2001 Polaris Xplorer (A01AG25CA)

OEM Parts Polaris 2001 Polaris Xplorer (A01AG25CA) Gearcase - A01ag25ca

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

-	ASSEMBLY, GEARCASE Part #: 1341381 Required per assembly: 1 Note: Asm., Gearcase (Incl. 1-38)(If built after 4/01/01) (Incl. 1-38)(If built after 4/01/01) Currently Not Available
1	SCREW, CAP Part #: 3233734 Required per assembly: 1 Note: Screw Currently Not Available
2	WASHER Part #: 3233054 Required per assembly: 3 Currently Not Available
3	DAMPENER, CARB, VIBRATION Part #: 3233735 Required per assembly: 1 Note: Dampener Currently Not Available
4	PLUG Part #: 3233448 Required per assembly: 1 Currently Not Available
5	WASHER Part #: 3233035 Required per assembly: 1 Currently Not Available
6	BUSHING, PIVOT Part #: 3233527 Required per assembly: 1 Currently Not Available
7	SCREW Part #: 3233252 Required per assembly: 10 Currently Not Available
8	GEARCASE, LH, (USED, IN, 1341502) Part #: 3234036 Required per assembly: 1 Currently Not Available
9	PIPE, KNOCK Part #: 3233529 Required per assembly: 2 Note: Pipe, Knock Sold in multiples of 5 only Currently Not Available
10	BEARING Part #: 3233020 Required per assembly: 4 Currently Not Available
11	GEAR, O/P, 100T, HCR Part #: 3233360 Required per assembly: 1 Currently Not Available
12	SHAFT, OUTPUT Part #: 3233544 Required per assembly: 1 Currently Not Available
13	SPROCKET, 15/26T Part #: 3233729 Required per assembly: 1 Note: Sprocket, 15/26T Currently Not Available
14	CHAIN, ROLLER Part #: 3233546 Required per assembly: 1 Currently Not Available
15	WASHER, THRUST Part #: 3233542 Required per assembly: 1 Currently Not Available
16	BUSHING, GARLOCK Part #: 3233541 Required per assembly: 1 Currently Not Available
17	SHAFT, PINION, 13T Part #: 3233540 Required per assembly: 1 Currently Not Available
18	RING, RETAINING Part #: 3233306 Required per assembly: 1 Note: Ring, Retaining Currently Not Available
19	COVER, CTR.DRIVE, BRG. Part #: 3233263 Required per assembly: 1 Currently Not Available
20	SCREW Part #: 3233539 Required per assembly: 11 Currently Not Available
21	SPROCKET, 15/22T Part #: 3233730 Required per assembly: 1 Note: Sprocket, 15/22T Currently Not Available
22	RING, RETAINING Part #: 3233537 Required per assembly: 1 Currently Not Available
23	SHAFT-INPUT HIGH/LOW/REVERSE Part #: 3233704 Required per assembly: 1 Note: Shaft, Input Currently Not Available
24	SEAL Part #: 3233788 Required per assembly: 3 Currently Not Available
25	BEARING Part #: 3233018 Required per assembly: 3 Currently Not Available
26	WASHER Part #: 3233176 Required per assembly: 2 Currently Not Available
27	BEARING, NDL, SPLIT, CAGE Part #: 3233718 Required per assembly: 3 Note: Bearing, Needle Currently Not Available
28	ENGAGEMENT, DOG, LOW Part #: 3233732 Required per assembly: 1 Currently Not Available
29	BEARING Part #: 3233019 Required per assembly: 1 Currently Not Available
30	SPROCKET, 24T Part #: 3233719 Required per assembly: 1 Currently Not Available
31	RING, RET-RING, EXTERNAL Part #: 3233720 Required per assembly: 3 Currently Not Available
32	CHAIN, SILENT, 34P Part #: 3233036 Required per assembly: 1 Currently Not Available
33	GEAR, 30T Part #: 3233722 Required per assembly: 1 Note: Gear, 30T Currently Not Available
34	RING, RETAINING Part #: 3233177 Required per assembly: 2 $5.99 $3.51 - + Add to cart
35	SCREW, TAPPING Part #: 3233747 Required per assembly: 4 Currently Not Available
36	BRACKET, INTERLOCK Part #: 3233309 Required per assembly: 1 Note: Bracket, Interlock Currently Not Available
37	SPRING Part #: 3233032 Required per assembly: 1 Currently Not Available
38	PIN, INTERLOCK Part #: 3233308 Required per assembly: 2 Note: Pin Currently Not Available
39	DOG, ENGAGEMENT, HIGH/REV Part #: 3233721 Required per assembly: 1 Note: Dog, Engagement Currently Not Available
40	SHAFT, REVERSE, 29T Part #: 3233733 Required per assembly: 1 Note: Shaft, Reverse, 29T Currently Not Available
41	GEAR, 33T Part #: 3233731 Required per assembly: 1 Note: Gear, 33T Currently Not Available
42	SHIFT FORK-LOW Part #: 3233706 Required per assembly: 1 Note: Fork, Shift, Low Currently Not Available
43	FORK, SHIFT, HIGH/REV Part #: 3233633 Required per assembly: 1 Note: Fork, Shift, High/Reverse Currently Not Available
44	BELLCRANK Part #: 3233547 Required per assembly: 1 Currently Not Available
45	NUT, FLEXLOC Part #: 3233961 Required per assembly: 2 Currently Not Available
46	BELLCRANK Part #: 3233153 Required per assembly: 1 Currently Not Available
47	RING, RETAINING Part #: 3233045 Required per assembly: 2 Currently Not Available
48	WASHER Part #: 3233040 Required per assembly: 2 Currently Not Available
49	O-RING Part #: 3233548 Required per assembly: 2 Currently Not Available
50	SHAFT, SHIFT Part #: 3233549 Required per assembly: 2 Currently Not Available
51	SCREW Part #: 3233749 Required per assembly: 8 Note: Screw Tapping Currently Not Available
52	SWITCH, 3, POSITION Part #: 3234002 Required per assembly: 1 Currently Not Available
53	SWITCH, ITW, 2, POSITION Part #: 3234001 Required per assembly: 1 Note: Switch, 2 Position (AA)(AB) (AA)(AB) Currently Not Available
54	PLUG, OIL, FILL Part #: 3233711 Required per assembly: 1 Note: Plug Currently Not Available
55	WASHER Part #: 3233324 Required per assembly: 1 $8.92 $6.43 - + Add to cart
56	COVER, SNORKEL Part #: 3233556 Required per assembly: 1 Currently Not Available
57	O-RING Part #: 3233555 Required per assembly: 1 Currently Not Available
58	SHIM Part #: 3233554 Currently Not Available
59	SNORKEL, SUBASM, SHAFT Part #: 3233723 Required per assembly: 1 Currently Not Available
59	SHAFT-SNORKEL Part #: 3234939 Required per assembly: 1 Currently Not Available
60	GEAR, 25T Part #: 3233898 Required per assembly: 1 Currently Not Available
61	BUSHING, GARLOCK Part #: 3233552 Required per assembly: 1 Note: Bushing Currently Not Available
62	VENT Part #: 3233037 Required per assembly: 1 Currently Not Available
63	SCREW Part #: 3233026 Required per assembly: 1 Currently Not Available
64	GUIDE, CHAIN Part #: 3233897 Required per assembly: 1 Currently Not Available
65	GEARCASE, RH Part #: 3233895 Required per assembly: 1 Note: Gearcase, RH Currently Not Available
66	DEFLECTOR, OIL Part #: 3233043 Required per assembly: 1 Currently Not Available
