Handlebar - V01cs15da replacement parts for 2001 Victory SPORTCRUISER (V01CS15CE)

OEM Parts Victory 2001 Victory SPORTCRUISER (V01CS15CE) Handlebar - V01cs15da

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	MIRROR-RIGHT Part #: 2632261 Required per assembly: 1 Currently Not Available
2	SW, RH, HANDCONTROL, W/PT Part #: 4110241 Required per assembly: 1 Currently Not Available
3	STRAP PANDUIT Part #: 7080138 Required per assembly: 2 $1.99 $1.15 - + Add to cart
4	HANDLEBAR, '01, SC Part #: 5244682 Required per assembly: 1 Currently Not Available
5	SCREW Part #: 7517361 Required per assembly: 4 Currently Not Available
6	CAP-RISER Part #: 5333903 Required per assembly: 2 Currently Not Available
7	DART 1/2" Part #: 5433140 Required per assembly: 2 $3.99 $2.28 - + Add to cart
8	MIRROR-LEFT Part #: 2632260 Required per assembly: 1 Currently Not Available
9	SW, LH, HANDCONTROL, W/PT Part #: 4110240 Required per assembly: 1 Currently Not Available
9	SCREW, PHPNH, M5X25 Part #: 7517366 Required per assembly: 4 Note: Sold in multiples of 10 only Currently Not Available
10	CAP, LH, H'BAR, END Part #: 5432692 Required per assembly: 1 Currently Not Available
11	GRIP, LH, H'BAR Part #: 5411256 Required per assembly: 1 Currently Not Available
12	PIN, CLUTCH, LEVER, PIVOT Part #: 5020946 Required per assembly: 1 Currently Not Available
12	KIT, HARDWARE, LEVER, CLUTCH Part #: 2201229 Required per assembly: 1 Note: 14,17,18 Currently Not Available
13	BRKT, CLUTCH/MIRROR, LH Part #: 5131654 Required per assembly: 1 Currently Not Available
15	LEVER, HAND, CLUTCH, LH, MACH Part #: 5131562 Required per assembly: 1 Currently Not Available
16	KIT, HARDWARE, CLAMP Part #: 2201230 Required per assembly: 1 Note: Incl. Clamp and Screws Currently Not Available
16	CAP, CLUTCH/MIRROR, LH Part #: 5131655 Required per assembly: 1 Currently Not Available
16	SCREW, SOCHD, M6X20 Part #: 7517630 Required per assembly: 2 Currently Not Available
19	SWITCH, MICRO, CLUTCH, SAFETY Part #: 4110257 Required per assembly: 1 Currently Not Available
20	BUSHING-CLUTCH, CABLE, UPPER Part #: 5433071 Required per assembly: 1 Currently Not Available
21	CABLE, CLUTCH, 7X7, SC Part #: 7080918 Required per assembly: 1 Currently Not Available
22	CLIP, CLUTCH, FAST, IDLE, CABLES Part #: 5433070 Required per assembly: 2 Currently Not Available
23	CABLE, FAST, IDLE, SC Part #: 7080821 Required per assembly: 1 Currently Not Available
24	RISER-HANDLEBAR, MACH, SC Part #: 5333767 Required per assembly: 2 Currently Not Available
25	SCR-SOCHD, M10X60, 0600084 Part #: 7517735 Required per assembly: 2 Currently Not Available
26	RETAINER, RH, THROT.CABLE Part #: 5242448 Required per assembly: 1 Currently Not Available
27	SCREW Part #: 7517420 Required per assembly: 1 Currently Not Available
28	CLIP, THROTTLECABLES, DUAL Part #: 5433039 Required per assembly: 2 Currently Not Available
29	CABLE, THROTTLE, ASM, SC Part #: 2010185 Required per assembly: 1 Currently Not Available
30	GRIP, H'BAR, THROTTLE Part #: 5411255 Required per assembly: 1 Currently Not Available
31	CAP, RH, H'BAR, END Part #: 5432715 Required per assembly: 1 Currently Not Available
