Carburetor replacement parts for 2001 Yamaha R6 (YZF-R6NC)

OEM Parts Yamaha 2001 Yamaha R6 (YZF R6NC) Carburetor

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	CARBURETOR ASSEMBLY 1 Part #: 5GV-14901-10-00 Required per assembly: 1 Note: CA Not Available
001	CARBURETOR ASSEMBLY 1 Part #: 5GV-14901-01-00 Required per assembly: 1 Note: U49 Not Available
002	CARBURETOR ASSEMBLY 2 Part #: 5GV-14902-01-00 Required per assembly: 1 Note: U49 Not Available
002	CARBURETOR ASSEMBLY 2 Part #: 5GV-14902-10-00 Required per assembly: 1 Note: CA Not Available
003	CARBURETOR ASSEMBLY 3 Part #: 5GV-14903-10-00 Required per assembly: 1 Note: CA Not Available
003	CARBURETOR ASSEMBLY 3 Part #: 5GV-14903-01-00 Required per assembly: 1 Note: U49 Not Available
004	CARBURETOR ASSEMBLY 4 Part #: 5GV-14904-01-00 Required per assembly: 1 Note: U49 Not Available
004	CARBURETOR ASSEMBLY 4 Part #: 5GV-14904-10-00 Required per assembly: 1 Note: CA Not Available
005	COVER, DIAPHRAGM Part #: 5EB-14958-00-00 Required per assembly: 1 $58.99 $52.97 - + Add to cart
006	SCREW Part #: 4JH-14216-00-00 Required per assembly: 3 Note: UR #3 $34.99 $27.59 - + Add to cart
007	SPRING, DIAPHRAGM Part #: 5EB-14933-00-00 Required per assembly: 1 $19.48 $16.03 - + Add to cart
008	DIAPHRAGM ASSEMBLY Part #: 5EB-14940-00-00 Required per assembly: 1 Note: U49 Not Available
008	DIAPHRAGM ASSEMBLY Part #: 5GV-14940-00-00 Required per assembly: 1 Note: CA Not Available
009	JET Part #: 4JH-14515-00-00 Required per assembly: 1 Not Available
010	SEAT, SPRING Part #: 5EB-14936-00-00 Required per assembly: 1 Note: U49 Not Available
010	SEAT, SPRING Part #: 5GV-14936-00-00 Required per assembly: 1 Note: CA Not Available
011	NEEDLE (N7SB) Part #: 5GV-14916-00-00 Required per assembly: 1 Note: 1,4 U49 Not Available
011	NEEDLE (N7SA) Part #: 5EB-14916-10-00 Required per assembly: 1 Note: 2,3 U49 Not Available
011	NEEDLE (N7SD) Part #: 5GV-14916-10-00 Required per assembly: 1 Note: 1,4 CA Not Available
011	NEEDLE (N7SE) Part #: 5GV-14916-20-00 Required per assembly: 1 Note: 2,3 CA Not Available
012	PIPE, MAIN, BREED Part #: 5EB-1414G-00-00 Required per assembly: 1 $45.99 $36.77 - + Add to cart
013	HOLDER, NOZZLE Part #: 5EB-14244-00-00 Required per assembly: 1 $43.99 $34.72 - + Add to cart
014	JET, MAIN, (#152) Part #: 3TJ-14943-88-00 Required per assembly: 1 Note: 1,4 U49 $16.48 $13.09 - + Add to cart
014	JET, MAIN, (#148) Part #: 3TJ-14943-87-00 Required per assembly: 1 $21.98 $17.81 - + Add to cart
015	JET (#38) Part #: 5EB-14948-02-00 Required per assembly: 1 Note: U49 $24.98 $19.23 - + Add to cart
015	JET (#35) Part #: 5EB-14948-01-00 Required per assembly: 1 Note: CA $24.98 $19.23 - + Add to cart
016	PILOT SCREW SET Part #: 5EB-14105-00-00 Required per assembly: 1 Note: U49 $38.99 $31.10 - + Add to cart
016	PILOT SCREW SET Part #: 5GV-14105-00-00 Required per assembly: 1 Note: CA $27.98 $23.06 - + Add to cart
017	FRAME, SADDLEBAG, 1 Part #: 5S6-28473-01-00 Required per assembly: 1 $313.99 $291.41 - + Add to cart
018	FLOAT Part #: 5EB-14985-00-00 Required per assembly: 1 Not Available
019	PIN, FLOAT, ARM Part #: 663-14548-00-00 Required per assembly: 1 $5.99 $5.44 - + Add to cart
020	SCREW, PAN, HEAD, (713) Part #: 98580-04008-00 Required per assembly: 5 $6.49 $4.46 - + Add to cart
021	GASKET, FLOAT, CHAMBER Part #: 5EB-14984-00-00 Required per assembly: 1 $21.98 $16.36 - + Add to cart
022	PLUG, DRAIN Part #: 3TJ-14191-40-00 Required per assembly: 1 $22.98 $16.90 - + Add to cart
023	SCREW, PAN, HEAD, -, FOR, CARB, #1, 4 Part #: 98580-04014-00 Required per assembly: 4 $3.29 $2.74 - + Add to cart
024	STARTER SET Part #: 4YR-1410A-00-00 Required per assembly: 1 Not Available
025	CAP Part #: 4MM-14118-00-00 Required per assembly: 1 $3.75 $3.08 - + Add to cart
026	SPRING Part #: 5GV-14556-00-00 Required per assembly: 1 Note: CA Not Available
027	WASHER Part #: 5GV-14557-00-00 Required per assembly: 1 Note: CA Not Available
028	SCREW, THROTTLE Part #: 5EB-14922-00-00 Required per assembly: 1 Not Available
029	SPRING, THROTTLE, STOP Part #: 4JH-14934-00-00 Required per assembly: 1 Not Available
030	BOLT, HOLDING Part #: 5EB-14162-00-00 Required per assembly: 2 Not Available
031	NUT, FLANGE Part #: 95704-05500-00 Required per assembly: 1 $2.75 $2.28 - + Add to cart
032	SPRING Part #: 5EB-14935-00-00 Required per assembly: 1 Not Available
033	WASHER, PLATE Part #: 90202-06056-00 Required per assembly: 6 $8.49 $5.82 - + Add to cart
034	SCREW, GUIDE Part #: 3TJ-14245-40-00 Required per assembly: 3 $5.00 $4.14 - + Add to cart
035	SCREW Part #: 4JH-14565-00-00 Required per assembly: 1 $8.49 $6.47 - + Add to cart
036	COLLAR Part #: 4JH-14264-00-00 Required per assembly: 1 $16.48 $12.52 - + Add to cart
037	SCREW, THROTTLE, STOP Part #: 5EB-14121-00-00 Required per assembly: 3 Not Available
038	SPRING, ADJUST, SCREW Part #: 5JG-14531-00-00 Required per assembly: 3 $8.49 $6.41 - + Add to cart
039	SPRING, THROTTLE, STOP Part #: 4YR-14133-00-00 Required per assembly: 1 $7.49 $6.35 - + Add to cart
040	SPRING, THROTTLE, STOP Part #: 4JH-14133-00-00 Required per assembly: 3 $8.49 $6.43 - + Add to cart
041	SPRING Part #: 4JH-14487-00-00 Required per assembly: 2 $8.49 $6.41 - + Add to cart
042	PIPE ADAPTOR ASSEMBLY Part #: 4JH-14350-00-00 Required per assembly: 2 $157.99 $134.28 - + Add to cart
043	PIPE T Part #: 4JH-13918-00-00 Required per assembly: 1 $39.99 $34.85 - + Add to cart
044	PIPE Part #: 5EB-14298-00-00 Required per assembly: 2 Not Available
045	CLIP Part #: 4JH-14137-00-00 Required per assembly: 4 Not Available
046	PIPE Part #: 5EB-14197-01-00 Required per assembly: 2 Not Available
047	JOINT, AIR, FILTER, 1 Part #: 5EB-1440F-00-00 Required per assembly: 4 Not Available
048	SCREW Part #: 3TJ-14216-40-00 Required per assembly: 1 $3.75 $3.08 - + Add to cart
049	THROTTLE POSITION SENSOR ASSEMBLY Part #: 4TV-85885-00-00 Required per assembly: 1 $487.99 $437.23 - + Add to cart
050	O-RING Part #: 4TV-14562-00-00 Required per assembly: 1 $8.49 $6.41 - + Add to cart
051	COLLAR Part #: 4TV-14534-00-00 Required per assembly: 1 $21.98 $17.39 - + Add to cart
052	SCREW Part #: 4TV-14216-00-00 Required per assembly: 2 Not Available
053	WASHER Part #: 4TV-14557-00-00 Required per assembly: 2 $3.60 $2.98 - + Add to cart
054	JOINT Part #: 5EB-12446-00-00 Required per assembly: 2 Note: U49 $93.98 $77.81 - + Add to cart
055	HOSE 1 Part #: 5EB-12576-00-00 Required per assembly: 1 Note: U49 Not Available
056	CLIP Part #: 4TV-12486-00-00 Required per assembly: 6 Note: RK $8.49 $3.78 - + Add to cart
057	NIPPLE Part #: 5EB-14251-00-00 Required per assembly: 2 Not Available
058	JOINT Part #: 5EB-14454-00-00 Required per assembly: 2 Not Available
