Swingarm replacement parts for 2002 Honda XR200R

OEM Parts Honda 2002 Honda XR200R Swingarm

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	CHAIN KIT (520-108L) Part #: 06406-KT0-A20 Required per assembly: 1 Not Available
002	CASE, DRIVE, CHAIN Part #: 40510-KK0-000 Required per assembly: 1 Not Available
003	CHAIN, DRIVE Part #: 40530-KCY-672 Required per assembly: 1 Not Available
003	CHAIN, DRIVE Part #: 06405-KV3-P00 Required per assembly: 1 Not Available
004	MASTER LINK Part #: 40531-KCE-672 Required per assembly: 1 Not Available
004	MASTER LINK Part #: 40531-KT0-003 Required per assembly: 1 Not Available
005	STAY, TENSIONER Part #: 50143-MA0-770 Required per assembly: 1 Not Available
006	BUSH, PIVOT, THRUST Part #: 52109-430-300 Required per assembly: 2 $18.57 $15.47 - + Add to cart
007	COLLAR, RR. Part #: 52141-KT1-770 Required per assembly: 1 Not Available
008	CAP Part #: 52144-356-005 Required per assembly: 2 $20.06 $16.73 - + Add to cart
009	GUIDE, CHAIN Part #: 52146-KT0-770 Required per assembly: 1 Not Available
010	SLIDER, CHAIN, GUIDE Part #: 52147-KF0-000 Required per assembly: 1 Not Available
011	SLIDER, CHAIN Part #: 52155-KK0-771 Required per assembly: 1 $45.21 $37.70 - + Add to cart
012	COLLAR, CHAIN, ROLLER Part #: 52159-169-000 Required per assembly: 1 Not Available
013	SLIDER, CHAIN Part #: 52170-KK0-771 Required per assembly: 1 $111.85 $108.46 - + Add to cart
014	COLLAR, CHAIN, SLIDER Part #: 52171-MC4-000 Required per assembly: 4 $6.00 $5.36 - + Add to cart
015	SLIDER, B, CHAIN Part #: 52180-KT0-670 Required per assembly: 1 Not Available
016	SWINGARM SUB ASSEMBLY * Part #: 52200-KT0-A30ZA Required per assembly: 1 Not Available
017	COLLAR Part #: 61304-397-830 Required per assembly: 2 $3.01 $2.80 - + Add to cart
018	BOLT, FLANGE, (6MM) Part #: 90111-KT1-780 Required per assembly: 4 $15.46 $14.05 - + Add to cart
019	BOLT, RR., SWINGARM Part #: 90121-KL4-000 Required per assembly: 1 $101.94 $82.52 - + Add to cart
020	NUT, U, (6MM) Part #: 90301-473-003 Required per assembly: 1 $5.46 $4.96 - + Add to cart
021	NUT, U, (14MM) Part #: 90305-GE8-003 Required per assembly: 1 $5.24 $4.76 - + Add to cart
022	NUT, FLG, (M8X1.25) Part #: 90309-428-731 Required per assembly: 1 $4.68 $4.25 - + Add to cart
023	BEARING (20X26X20) Part #: 91070-GC4-601 Required per assembly: 2 $28.66 $23.90 - + Add to cart
024	BOLT, HEX., (5X12) Part #: 92101-05012-0G Required per assembly: 1 $2.07 $1.91 - + Add to cart
025	SCREW, TAP, (6X12) Part #: 93901-26180 Required per assembly: 4 $2.01 $1.86 - + Add to cart
026	NIPPLE (B.T6S) Part #: 96201-80000 Required per assembly: 1 $3.59 $3.26 - + Add to cart
027	BOLT, FLANGE, (6X45) Part #: 96300-06045-00 Required per assembly: 3 $3.19 $2.97 - + Add to cart
