Rear Shock Absorber replacement parts for 2002 Honda XR650R

OEM Parts Honda 2002 Honda XR650R Rear Shock Absorber

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	CUSHION, ASSEMBLY, RR. Part #: 52400-MBN-671 Required per assembly: 1 Not Available
002	SPRING, RR., SHOCK Part #: 52401-MBN-671 Required per assembly: 1 Not Available
003	DAMPER, RR. Part #: 52410-MBN-671 Required per assembly: 1 Not Available
004	ROD, PISTON Part #: 52421-MBN-671 Required per assembly: 1 Not Available
005	SEAT, SPRING, (UPPER) Part #: 52422-KS6-701 Required per assembly: 1 Not Available
006	NUT, ADJUSTER Part #: 52423-KS6-701 Required per assembly: 1 Not Available
007	SEAT, SPRING, (LOWER) Part #: 52424-KS6-701 Required per assembly: 1 Not Available
008	ROD Part #: 52426-MBN-671 Required per assembly: 1 $485.96 $393.37 - + Add to cart
009	RUBBER, BUMPER Part #: 52427-KZ4-901 Required per assembly: 1 $16.15 $13.46 - + Add to cart
010	CAP, CASE Part #: 52428-MBN-671 Required per assembly: 1 Not Available
011	CASE, ROD, GUIDE Part #: 52429-MBN-671 Required per assembly: 1 $23.53 $19.04 - + Add to cart
012	RING, SNAP Part #: 52435-ML3-791 Required per assembly: 1 Not Available
013	NUT, HEX., (12MM) Part #: 52438-KA3-731 Required per assembly: 1 $4.02 - + Add to cart
014	BLADDER Part #: 52451-KZ4-003 Required per assembly: 1 $32.78 $27.33 - + Add to cart
015	RING, SNAP Part #: 52452-KZ4-003 Required per assembly: 1 Not Available
016	CAP, BLADDER Part #: 52453-MBN-671 Required per assembly: 1 Not Available
017	COLLAR B Part #: 52462-MBN-670 Required per assembly: 1 Not Available
018	COLLAR, D, CUSHION Part #: 52463-KZ4-B00 Required per assembly: 1 $4.60 $4.18 - + Add to cart
019	COLLAR Part #: 52464-GBF-830 Required per assembly: 1 Not Available
020	COLLAR D Part #: 52464-KZ4-B00 Required per assembly: 2 $5.20 $4.73 - + Add to cart
021	ARM, SET, CUSHION Part #: 52465-MBN-670 Required per assembly: 1 $309.51 $246.83 - + Add to cart
022	COLLAR Part #: 52473-MBN-670 Required per assembly: 1 Not Available
023	ROD SUB-ASSEMBLY Part #: 52475-MBN-670 Required per assembly: 1 Not Available
024	COLLAR, A, CUSHION Part #: 52486-GBF-830 Required per assembly: 1 $8.69 $7.53 - + Add to cart
025	COLLAR, B, CUSHION Part #: 52487-GBF-830 Required per assembly: 1 $7.44 $6.52 - + Add to cart
026	LABEL, RR. Part #: 87516-KZ1-600 Required per assembly: 1 $6.74 $6.13 - + Add to cart
027	BOLT, SOCKET, (10X48) Part #: 90126-MBN-670 Required per assembly: 1 $2.94 $2.73 - + Add to cart
028	BOLT, FLANGE, (12X81) Part #: 90127-MBN-670 Required per assembly: 1 Not Available
029	BOLT, FLANGE, (12X99) Part #: 90128-MBN-670 Required per assembly: 1 Not Available
030	BOLT (12X104) Part #: 90129-MBN-670 Required per assembly: 1 Not Available
031	BOLT (10X43.5) Part #: 90153-KZ4-710 Required per assembly: 1 $10.87 $8.50 - + Add to cart
032	NUT, U, (10MM) Part #: 90304-GE8-003 Required per assembly: 1 Note: Sold in multiples of 5 only $4.58 - + Add to cart
033	NUT, U, (12MM) Part #: 90306-GAB-711 Required per assembly: 3 $10.54 $9.04 - + Add to cart
034	NUT, FLANGE, (12MM) Part #: 90306-KF0-003 Required per assembly: 5 $5.21 $4.74 - + Add to cart
035	NUT, U, (10MM) Part #: 90306-KZ4-711 Required per assembly: 2 $5.10 $4.64 - + Add to cart
036	WASHER, PLAIN, (12MM) Part #: 90504-SF4-000 Required per assembly: 1 $7.75 $6.76 - + Add to cart
037	BEARING (20X26X20) Part #: 91072-MY1-005 Required per assembly: 6 $21.46 $17.89 - + Add to cart
038	BEARING (19X26X15) Part #: 91074-KZ4-B01 Required per assembly: 1 $25.14 $20.95 - + Add to cart
039	BEARING (16X22X12) Part #: 91077-GS2-702 Required per assembly: 1 $21.72 $18.11 - + Add to cart
040	DUST SEAL Part #: 91254-KS6-003 Required per assembly: 6 $10.65 $9.13 - + Add to cart
041	DUST, SEAL, RR. Part #: 91351-GS2-701 Required per assembly: 2 $4.85 - + Add to cart
042	DUST SEAL (17X26X3) Part #: 91351-KZ4-B01 Required per assembly: 2 $5.57 $5.06 - + Add to cart
