Radiator replacement parts for 2002 Kawasaki Mule 3010 4X4 (KAF620-E2)

OEM Parts Kawasaki 2002 Kawasaki Mule 3010 4X4 (KAF620 E2) Radiator

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

130	BOLT-FLANGED, 6X10 Part #: 130BB0610 Required per assembly: 1 Note: Sold in multiples of 5 only $2.57 $1.86 - + Add to cart
130B	BOLT-FLANGED, 6X14 Part #: 130BB0614 Required per assembly: 6 $1.86 - + Add to cart
130C	BOLT-FLANGED, 8X25 Part #: 130CB0825 Required per assembly: 4 $3.02 $2.15 - + Add to cart
11009	GASKET, RESERVOIR, TANK, CAP Part #: 11009-1145 Required per assembly: 1 Note: Sold in multiples of 5 only $1.48 $1.14 - + Add to cart
11012	CAP Part #: 11012-1084 Required per assembly: 1 $1.79 $1.32 - + Add to cart
11060	GASKET, THERMOSTAT, COVER Part #: 11060-2084 Required per assembly: 1 $2.91 $2.05 - + Add to cart
14024	COVER, THERMOSTAT Part #: 14093-0061 Required per assembly: 1 $16.35 $13.67 - + Add to cart
14037	SCREEN Part #: 14037-1284 Required per assembly: 1 Not Available
27010	SWITCH, FAN Part #: 27010-1317 Required per assembly: 1 $139.11 $137.20 - + Add to cart
32153	PIPE, RH Part #: 32153-1056 Required per assembly: 1 Not Available
32153A	PIPE, RH Part #: 32153-1325 Required per assembly: 1 $105.86 - + Add to cart
32153B	PIPE, LH Part #: 32153-1326 Required per assembly: 1 $77.17 - + Add to cart
39060	RADIATOR Part #: 39060-1187 Required per assembly: 1 Not Available
39062	HOSE-COOLING Part #: 39062-1829 Required per assembly: 1 $4.83 $3.77 - + Add to cart
39062A	HOSE-COOLING Part #: 39062-1830 Required per assembly: 1 $11.62 $9.82 - + Add to cart
39062B	HOSE-COOLING Part #: 39062-1832 Required per assembly: 1 $17.27 $14.41 - + Add to cart
39062C	HOSE-COOLING Part #: 39062-1833 Required per assembly: 1 $20.21 $16.76 - + Add to cart
39062D	HOSE-COOLING, RH, PIPE-RAD. Part #: 39062-0282 Required per assembly: 1 $26.90 $22.52 - + Add to cart
39062E	HOSE-COOLING, RAD.-LH, PIPE Part #: 39062-0283 Required per assembly: 1 $24.98 $20.96 - + Add to cart
39062F	HOSE-COOLING, LH, PIPE-E/G Part #: 39062-0286 Required per assembly: 1 $17.28 $14.47 - + Add to cart
43078	RESERVOIR Part #: 43078-0062 Required per assembly: 1 $30.29 $27.59 - + Add to cart
49054	THERMOSTAT Part #: 49054-2056 Required per assembly: 1 $28.52 $23.18 - + Add to cart
49085	CAP, ASSEMBLY, PRESSURE Part #: 49085-1066 Required per assembly: 1 $38.06 $34.94 - + Add to cart
59502	FAN ASSEMBLY Part #: 59502-1137 Required per assembly: 1 $522.63 - + Add to cart
92001	BOLT, 6X16 Part #: 92001-1860 Required per assembly: 1 $4.43 $3.49 - + Add to cart
92015	NUT Part #: 92015-1487 Required per assembly: 6 $4.92 $3.83 - + Add to cart
92022	WASHER, 8.5X20X1.6, BLACK Part #: 92022-1317 Required per assembly: 4 $4.43 $3.49 - + Add to cart
92022A	WASHER, 6.2X11X1 Part #: 92022-304 Required per assembly: 2 $3.75 $2.91 - + Add to cart
92027	COLLAR, 8.8X12X10.7 Part #: 92027-102 Required per assembly: 4 Note: Sold in multiples of 5 only $1.14 $0.91 - + Add to cart
92037	CLAMP, TUBE Part #: 92037-147 Required per assembly: 3 $7.57 $6.59 - + Add to cart
92071	GROMMET Part #: 92071-1115 Required per assembly: 2 $5.61 $4.36 - + Add to cart
92075	DAMPER Part #: 92075-294 Required per assembly: 4 $4.22 $3.34 - + Add to cart
92150	BOLT, 6X12 Part #: 92150-1186 Required per assembly: 4 $3.47 $2.69 - + Add to cart
92150A	BOLT, 6X40 Part #: 92150-2230 Required per assembly: 1 Note: Sold in multiples of 5 only $1.58 $1.20 - + Add to cart
92150B	BOLT, 6X20 Part #: 92150-2231 Required per assembly: 1 $2.00 $1.46 - + Add to cart
92151	BOLT-FLANGED, 6X10 Part #: 130BB0610 Required per assembly: 1 Note: Sold in multiples of 5 only $2.57 $1.86 - + Add to cart
92170	CLAMP Part #: 92171-0179 Required per assembly: 10 $8.43 $7.23 - + Add to cart
