Rear Wheel replacement parts for 2003 Yamaha BEAR TRACKER (YFM250XR)

OEM Parts Yamaha 2003 Yamaha BEAR TRACKER (YFM250XR) Rear Wheel

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	REAR WHEEL COMP Part #: 4XE-F5390-20-00 Required per assembly: 1 Not Available
002	TIRE, (AT, 22X10-10, M-906) Part #: 94110-10800-00 Required per assembly: 1 Note: UR CHENG SHIN (USA) Not Available
002	TIRE (AT 22X10-10) Part #: 94110-102Y3-00 Required per assembly: 1 Note: UR Not Available
003	VALVE, RIM, (TR413) Part #: 93900-00812-00 Required per assembly: 1 $9.49 $7.36 - + Add to cart
003	VALVE, RIM, (TR413) Part #: 93900-00810-00 Required per assembly: 1 $2.79 $2.31 - + Add to cart
004	COLLAR, WHEEL Part #: 2HR-25383-01-00 Required per assembly: 1 $172.99 $155.39 - + Add to cart
005	BOLT, SERRATION Part #: 90114-10014-00 Required per assembly: 4 $3.54 $2.69 - + Add to cart
006	REAR WHEEL COMP Part #: 4XE-F5390-31-00 Required per assembly: 1 Note: (YMUS) Not Available
007	TIRE, (AT, 22X10-10, M-906) Part #: 94110-10800-00 Required per assembly: 1 Note: UR CHENG SHIN (USA) Not Available
007	TIRE (AT 22X10-10) Part #: 94110-102Y3-00 Required per assembly: 1 Note: UR Not Available
008	VALVE, RIM, (TR413) Part #: 93900-00812-00 Required per assembly: 1 $9.49 $7.36 - + Add to cart
008	VALVE, RIM, (TR413) Part #: 93900-00810-00 Required per assembly: 1 $2.79 $2.31 - + Add to cart
009	BEARING Part #: 93306-008Y1-00 Required per assembly: 1 $35.99 $29.67 - + Add to cart
010	OIL, SEAL, DD-TYPE Part #: 93106-47040-00 Required per assembly: 1 $20.98 $16.87 - + Add to cart
011	COVER, HUB, DUST Part #: 4SH-25367-01-00 Required per assembly: 1 $52.99 $40.96 - + Add to cart
012	OIL, SEAL, S-TYPE Part #: 93101-35097-00 Required per assembly: 1 $24.98 $17.48 - + Add to cart
013	BEARING Part #: 93306-278Y0-00 Required per assembly: 1 $53.99 $44.44 - + Add to cart
014	PLATE, BRAKE, SHOE Part #: 4XE-F5321-00-00 Required per assembly: 1 Not Available
015	SEAL, PLATE, DUST Part #: 4XE-F5129-00-00 Required per assembly: 1 Not Available
016	SEAL, DUST Part #: 4XE-F5816-00-00 Required per assembly: 1 Not Available
017	CAMSHAFT, BRAKE Part #: 4XE-F5351-00-00 Required per assembly: 1 Not Available
018	BRAKE SHOE SET Part #: 4BD-W2536-01-00 Required per assembly: 1 $43.83 $39.84 - + Add to cart
019	SPRING, RETURN Part #: 4XE-F5133-00-00 Required per assembly: 2 Not Available
020	PLATE, INDICATOR Part #: 4XE-F513A-00-00 Required per assembly: 1 Not Available
021	BOLT, FITTING Part #: 4XE-F5833-00-00 Required per assembly: 1 Not Available
022	NUT, FLANGE, (7NB) Part #: 95780-06500-00 Required per assembly: 1 $2.95 $1.87 - + Add to cart
023	LEVER, CAMSHAFT Part #: 4XE-F5355-00-00 Required per assembly: 1 Not Available
024	GASKET Part #: 4XE-F5898-00-00 Required per assembly: 1 Not Available
025	BOLT, CALIPER Part #: 4XE-F5818-00-00 Required per assembly: 1 Not Available
026	SHIM, CAMSHAFT Part #: 4XE-F5153-00-00 Required per assembly: 1 Not Available
027	SPRING, TENSION Part #: 90506-12403-00 Required per assembly: 1 $9.49 $6.55 - + Add to cart
028	RETAINER Part #: 4XE-G6513-00-00 Required per assembly: 1 $9.49 $7.88 - + Add to cart
029	BOLT, FLANGE Part #: 90105-088A4-00 Required per assembly: 4 $3.95 $3.78 - + Add to cart
030	AXLE, WHEEL Part #: 4XE-F5381-01-00 Required per assembly: 1 Not Available
031	COLLAR Part #: 90387-284T0-00 Required per assembly: 1 $18.48 $14.11 - + Add to cart
032	O-RING Part #: 93210-26662-00 Required per assembly: 1 Note: Sold in multiples of 5 only $8.49 $5.76 - + Add to cart
033	HUB ASSEMBLY Part #: 4XE-F5310-00-00 Required per assembly: 1 Not Available
034	BOLT, SERRATION Part #: 90114-10802-00 Required per assembly: 4 $3.93 $3.08 - + Add to cart
035	O-RING Part #: 93210-12131-00 Required per assembly: 4 $9.49 $6.67 - + Add to cart
036	NUT, SPEC'L, SHAPE, (ATV, LUG) Part #: 90179-10540-00 Required per assembly: 4 $4.95 $4.10 - + Add to cart
037	WASHER, PLATE Part #: 90201-16804-00 Required per assembly: 2 $11.49 $9.80 - + Add to cart
038	CAP, WHEEL Part #: 52H-2512A-00-00 Required per assembly: 1 $24.98 $19.52 - + Add to cart
039	NUT, CASTLE Part #: 90171-16001-00 Required per assembly: 1 Note: (USA) $24.98 $19.19 - + Add to cart
040	PIN, COTTER Part #: 91490-30030-00 Required per assembly: 2 Note: Sold in multiples of 5 only $8.49 $7.24 - + Add to cart
041	HOSE (L1050) Part #: 90445-07810-00 Required per assembly: 1 Not Available
042	CLIP, SCISSOR Part #: 90467-07093-00 Required per assembly: 1 $3.35 $1.74 - + Add to cart
043	CLIP Part #: 90468-15020-00 Required per assembly: 1 $8.49 $5.58 - + Add to cart
