09 - Body (Front View) replacement parts for 2004 Can Am Outlander MAX 400 STD & XT

OEM Parts Can Am 2004 Can Am Outlander MAX 400 STD & XT 09 - Body (Front View)

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	PUSH NUT. PACKAGE PRO - XMR Part #: 732610072 Required per assembly: 2 Not Available
2	HEX. FLANGED SCREW M8 X 20 Part #: 207682044 Required per assembly: 2 Note: Sold in multiples of 10 only Currently Not Available
3	HEX. FLANGED ELASTIC NUT M8. MODEL-XT Part #: 233281414 Required per assembly: 2 Currently Not Available
4	HEX. FLANGED SCREW M10 X 30 Part #: 207603044 Required per assembly: 2 Note: Sold in multiples of 10 only Currently Not Available
5	ELASTIC FLANGED STOP NUT M10 Part #: 233201414 Required per assembly: 2 $1.25 $1.02 - + Add to cart
6	FRONT BUMPER Part #: 715900097 Required per assembly: 1 Currently Not Available
7	FENDER KIT Part #: 715002330 Required per assembly: 1 Note: Includes 7 to 14 Currently Not Available
7	FENDER KIT Part #: 715002329 Required per assembly: 1 Note: Includes 7 to 14 Currently Not Available
7	FRONT FENDER, GREEN Part #: 715000630 Required per assembly: 1 Note: Includes 7 to 14 Currently Not Available
8	WARNING LABEL. (FRONT LOAD / DO NOT SIT) Part #: 704900453 Required per assembly: 1 Currently Not Available
9	WARNING DECAL, UNDER 16 YEARS OLD. ENGLISH VERSION Part #: 704901753 Required per assembly: 1 Currently Not Available
10	WARNING DECAL, DEATH AND INJURIES. ENGLISH VERSION, NORTH AMERICA & INT. Part #: 704901749 Required per assembly: 1 Currently Not Available
12	WARNING LABEL (UNDER 16 YEARS OLD) (FRENCH) Part #: 704900436 Required per assembly: 1 Currently Not Available
15	FRONT FASCIA Part #: 705000432 Required per assembly: 1 Currently Not Available
15	FRONT FACIA. GREEN Part #: 705000734 Required per assembly: 1 Currently Not Available
15	FRONT FACIA. YELLOW Part #: 705000851 Required per assembly: 1 Currently Not Available
16	TUFLOK PLASTIC RIVET Part #: 293150230 Required per assembly: 6 $1.45 $1.19 - + Add to cart
17	FLAT WASHER 8 MM Part #: 234082410 Required per assembly: 2 $1.12 $0.91 - + Add to cart
18	DASH-BOARD, GREEN Part #: 703500672 Required per assembly: 1 Note: Includes 18 to 21 Currently Not Available
18	DASH-BOARD, YELLOW Part #: 703500670 Required per assembly: 1 Note: Includes 18 to 21 Currently Not Available
18	DASH-BOARD, RED Part #: 703500668 Required per assembly: 1 Note: Includes 18 to 21 Currently Not Available
19	CONSOLE WARNING ASSEMBLY Part #: 704900434 Required per assembly: 1 Currently Not Available
22	HEX. FLANGED SCREW M6 X 16. (RS) Part #: 210261650 Required per assembly: 2 Currently Not Available
23	FLAT WASHER Part #: 250200082 Required per assembly: 2 $1.72 $1.40 - + Add to cart
24	TUFLOK PLASTIC RIVET Part #: 293150230 Required per assembly: 2 $1.45 $1.19 - + Add to cart
25	LH FRONT LUGGAGE RACK Part #: 705000436 Required per assembly: 1 Currently Not Available
26	R.H. FRONT LUGGAGE RACK Part #: 705000437 Required per assembly: 1 Currently Not Available
27	HEX SCREW M6 X 80 Part #: 207168044 Required per assembly: 4 Currently Not Available
28	HEX SCREW M6 X 50 Part #: 207165044 Required per assembly: 4 Currently Not Available
29	FLAT WASHER Part #: 224061201 Required per assembly: 16 Currently Not Available
30	HEX. FLANGED ELASTIC NUT M6 Part #: 233261414 Required per assembly: 8 Note: Sold in multiples of 10 only Currently Not Available
31	GUARD PLATE. MODEL-STD Part #: 705003495 Required per assembly: 1 Currently Not Available
32	HEX. FLANGED SCREW M6 X 20 Part #: 207662044 Required per assembly: 4 Note: Sold in multiples of 25 only Currently Not Available
33	HEX. FLANGED ELASTIC NUT M6 Part #: 233261414 Required per assembly: 4 Note: Sold in multiples of 10 only Currently Not Available
34	HEX. FLANGED SCREW M10 X 25. MODEL-STD Part #: 207602544 Required per assembly: 2 $1.40 $1.13 - + Add to cart
35	ELASTIC FLANGED STOP NUT M10 Part #: 233201414 Required per assembly: 2 $1.25 $1.02 - + Add to cart
36	LEVER INDICATOR. MODEL-NORTH AMERICA/INTERNATIONAL Part #: 705001529 Required per assembly: 1 Currently Not Available
37	HEX. FLANGED SCREW M6 X 20 Part #: 207662044 Required per assembly: 3 Note: Sold in multiples of 25 only Currently Not Available
38	HEX. FLANGED ELASTIC NUT M6 Part #: 233261414 Required per assembly: 3 Note: Sold in multiples of 10 only Currently Not Available
39	FRONT SUPPORT Part #: 705000895 Required per assembly: 1 Currently Not Available
40	L.H. PLATE Part #: 705000692 Required per assembly: 1 Currently Not Available
41	POP RIVET 3/16" Part #: 390402000 Required per assembly: 4 Note: Sold in multiples of 50 only Currently Not Available
42	RH ANCHOR PLATE Part #: 705002997 Required per assembly: 1 Currently Not Available
43	HEX. FLANGED SCREW M8 X 45 Part #: 207684544 Required per assembly: 4 $3.08 $2.49 - + Add to cart
44	FLAT WASHER 8 MM Part #: 234082410 Required per assembly: 4 $1.12 $0.91 - + Add to cart
45	HEX FLANGED ELASTIC NUT M8 Part #: 232581414 Required per assembly: 4 $0.99 $0.85 - + Add to cart
46	LH INNER FENDER Part #: 705000652 Required per assembly: 1 Currently Not Available
47	TUFLOK PLASTIC RIVET Part #: 293150230 Required per assembly: 5 $1.45 $1.19 - + Add to cart
48	KNOB Part #: 517303439 Required per assembly: 3 $3.69 $2.99 - + Add to cart
49	HEX SCREW M5 X 12 Part #: 207151244 Required per assembly: 3 Note: Sold in multiples of 10 only Currently Not Available
50	FLAT WASHER Part #: 391301600 Required per assembly: 3 Note: Sold in multiples of 50 only Currently Not Available
51	GROMMET Part #: 709000582 Required per assembly: 3 Note: Sold in multiples of 10 only Currently Not Available
52	INNER FENDER Part #: 705002640 Required per assembly: 1 Currently Not Available
53	VALVE SUPPORT Part #: 705000654 Required per assembly: 1 Currently Not Available
54	PROTECTOR PLUG Part #: 705000655 Required per assembly: 2 Currently Not Available
55	PLUG Part #: 705001690 Required per assembly: 6 Currently Not Available
