Wire Harness (Engine) replacement parts for 2004 Honda AquaTrax R-12 (ARX1200N2)

OEM Parts Honda 2004 Honda AquaTrax R 12 (ARX1200N2) Wire Harness (Engine)

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	RECTIFIER, REGULATOR Part #: 31600-HW1-671 Required per assembly: 1 $106.80 $102.50 - + Add to cart
02	SUB-HARNESS Part #: 32101-HW4-680 Required per assembly: 1 $285.91 $250.34 - + Add to cart
03	HOLDER, F, ELECTRIC Part #: 32130-HW3-670 Required per assembly: 1 $3.18 - + Add to cart
04	BASE, CABLE, MOUNTING Part #: 32170-HW1-670 Required per assembly: 1 $1.73 $1.59 - + Add to cart
05	PGM-FI UNIT Part #: 38770-HW4-681 Required per assembly: 1 $1,705.26 $1,421.73 - + Add to cart
06	STAY, PGM-FI, UNIT Part #: 38771-HW3-670 Required per assembly: 1 $41.18 $35.83 - + Add to cart
07	CUSHION, PGM-FI, UNIT Part #: 38775-HW3-670 Required per assembly: 1 $14.62 $12.72 - + Add to cart
08	BOLT, FLANGE, (6X25) Part #: 90205-HW1-670 Required per assembly: 3 $3.43 $3.12 - + Add to cart
09	WASHER (6MM) Part #: 90512-921-010 Required per assembly: 3 $2.19 $2.03 - + Add to cart
10	BAND, WIRE, HARNESS Part #: 90650-MA6-720 Required per assembly: 3 $4.99 $4.89 - + Add to cart
11	CLIP, WIRE, HARNESS Part #: 91558-SD5-003 Required per assembly: 1 $9.08 $8.52 - + Add to cart
12	BOLT, FLANGE, (6X12) Part #: 95701-06012-02 Required per assembly: 1 $3.07 $2.86 - + Add to cart
13	BOLT, FLANGE, (6X25) Part #: 95701-06025-02 Required per assembly: 2 $2.45 $2.28 - + Add to cart
