Front Wheel replacement parts for 2004 Honda DREAM 50R (CB50R)

OEM Parts Honda 2004 Honda DREAM 50R (CB50R) Front Wheel

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	AXLE, RR., WHEEL Part #: 42301-126-850 Required per assembly: 1 Not Available
002	RIM, WHEEL Part #: 42701-GCR-003 Required per assembly: 1 Not Available
003	TIRE (2.50-18 45L) Part #: 42711-NX1-003 Required per assembly: 1 Not Available
005	COLR, FR., WHEEL, SIDE Part #: 44311-229-000 Required per assembly: 1 $7.60 $6.91 - + Add to cart
006	COLLAR, L., FR. Part #: 44312-NX1-000 Required per assembly: 1 $38.67 $33.64 - + Add to cart
007	COLLAR, FR. Part #: 44620-400-000 Required per assembly: 1 $8.77 $7.97 - + Add to cart
008	HUB, SUB, FR., WHEEL Part #: 44635-NX1-000 Required per assembly: 1 $330.47 $287.51 - + Add to cart
009	WHEEL, SUB-ASSEMBLY, FR. Part #: 44650-NX1-000 Required per assembly: 1 $646.50 $587.46 - + Add to cart
010	TUBE, TIRE, (2.50-18) Part #: 44712-304-003 Required per assembly: 1 $35.93 - + Add to cart
011	DISK, FR., BRAKE Part #: 45251-GCR-000 Required per assembly: 1 $237.60 $206.71 - + Add to cart
012	NUT, U, (6MM) Part #: 90301-473-003 Required per assembly: 1 $5.46 $4.96 - + Add to cart
013	NUT, FLANGE, (12MM) Part #: 90306-KF0-003 Required per assembly: 5 $5.21 $4.74 - + Add to cart
014	OIL SEAL (21X37X7) Part #: 90755-229-003 Required per assembly: 1 $6.07 $5.42 - + Add to cart
015	DUST SEAL (40X50X5) Part #: 91258-410-013 Required per assembly: 1 $11.37 $9.69 - + Add to cart
016	BOLT, STUD, (6X18) Part #: 92911-06018-0E Required per assembly: 5 $1.91 $1.77 - + Add to cart
017	BEARING (6301U) Part #: 96140-63010-10 Required per assembly: 1 $17.20 $14.34 - + Add to cart
018	SPOKE SET (B9X195.5) Part #: 97168-52231-R0 Required per assembly: 18 $4.32 - + Add to cart
019	SPOKE SET (B9X195.5) Part #: 97465-52231-R0 Required per assembly: 18 $4.32 - + Add to cart
