09- Body 3 replacement parts for 2004 Sea Doo GTX 4-TEC, Supercharged

OEM Parts Sea Doo 2004 Sea Doo GTX 4 TEC, Supercharged 09- Body 3

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	TRIM-COVER Part #: 269501031 Required per assembly: 1 Currently Not Available
2	DART, BLACK Part #: 293730006 Required per assembly: 3 Note: Sold in multiples of 5 only Currently Not Available
4	GASKET Part #: 293250171 Required per assembly: 1 Note: Sold in multiples of 2 only Currently Not Available
5	GROMMET Part #: 293720042 Required per assembly: 2 Currently Not Available
6	TIE RAP 180 MM Part #: 414115200 Required per assembly: 1 $0.60 $0.53 - + Add to cart
7	COVER TRIM Part #: 269501234 Required per assembly: 1 Currently Not Available
8	CLIP Part #: 270000141 Required per assembly: 1 Note: Sold in multiples of 5 only Currently Not Available
9	SCREW-PT.FLANGE PAN HD.K40 X 20 Part #: 241642060 Required per assembly: 1 Currently Not Available
10	PLUG-BLACK Part #: 291000279 Required per assembly: 1 Note: Sold in multiples of 4 only Currently Not Available
12	DOOR-FRONT Part #: 291002416 Required per assembly: 1 Currently Not Available
13	GASKET, NEOPRENE. Part #: 293250087 Note: 1 meter Currently Not Available
14	DOOR-REAR Part #: 291001743 Required per assembly: 1 Currently Not Available
15	GASKET, NEOPRENE. Part #: 293250087 Note: 1 meter Currently Not Available
16	STRAP Part #: 269500408 Required per assembly: 2 Currently Not Available
17	HOOK Part #: 269500521 Required per assembly: 2 Currently Not Available
18	ADVEL RIVET Part #: 293150027 Required per assembly: 2 Note: Sold in multiples of 50 only Currently Not Available
19	REMOVABLE TRAY Part #: 269501478 Required per assembly: 1 Note: (Includes 40 to 45 ) Currently Not Available
20	POCKET Part #: 269501442 Required per assembly: 1 Currently Not Available
21	STRAP Part #: 269501175 Required per assembly: 2 Currently Not Available
22	STRAP Part #: 269501174 Required per assembly: 1 Currently Not Available
23	STRAP Part #: 269501175 Required per assembly: 1 Currently Not Available
24	STRAP Part #: 269501176 Required per assembly: 1 Currently Not Available
25	CELLULAR CASE Part #: 269501476 Required per assembly: 1 Currently Not Available
26	SAFETY KIT Part #: 295100330 Required per assembly: 1 Note: (LTD ) Currently Not Available
27	INSULATED BOX Part #: 269501314 Required per assembly: 1 Currently Not Available
30	SANDBAG Part #: 269501287 Required per assembly: 1 Note: LTD Models Currently Not Available
31	CABLE Part #: 269501288 Required per assembly: 1 Note: LTD Models Currently Not Available
32	TUFLOK PLASTIC RIVET Part #: 293150230 Required per assembly: 4 $1.45 $1.19 - + Add to cart
33	BOX-GLOVES Part #: 269500968 Required per assembly: 1 Currently Not Available
34	DOOR-BOX Part #: 269501648 Required per assembly: 1 Currently Not Available
35	LATCH-BLACK Part #: 269500553 Required per assembly: 1 Currently Not Available
36	PIN Part #: 211400008 Required per assembly: 1 Currently Not Available
37	PUSH-NUT Part #: 211100002 Required per assembly: 2 Note: Sold in multiples of 5 only Currently Not Available
38	LATCH SPRING Part #: 291000922 Required per assembly: 1 $6.19 $5.01 - + Add to cart
39	GASKET Part #: 293250126 Required per assembly: 1 Note: Sold in multiples of 5 only Currently Not Available
40	GASKET Part #: 293250127 Required per assembly: 1 Currently Not Available
41	BOX-GLOVES Part #: 269501281 Required per assembly: 1 Currently Not Available
42	DOOR Part #: 269501297 Required per assembly: 1 Note: LTD Models Currently Not Available
43	LATCH-BLACK Part #: 269500553 Required per assembly: 1 Currently Not Available
44	PIN Part #: 211400008 Required per assembly: 2 Currently Not Available
45	LATCH SPRING Part #: 291000922 Required per assembly: 1 $6.19 $5.01 - + Add to cart
46	PUSH-NUT Part #: 211100002 Required per assembly: 4 Note: Sold in multiples of 5 only Currently Not Available
47	GASKET Part #: 293250146 Required per assembly: 1 Currently Not Available
48	GASKET Part #: 293250127 Required per assembly: 1 Currently Not Available
49	LATCH-BLACK Part #: 269501289 Required per assembly: 1 Note: (LTD ) Currently Not Available
50	TRAY-REAR Part #: 269501036 Required per assembly: 1 Currently Not Available
51	GASKET Part #: 293250008 Note: 1 meter Currently Not Available
52	COVER Part #: 269000788 Required per assembly: 1 Currently Not Available
53	SEAL-COVER Part #: 269000810 Required per assembly: 1 Currently Not Available
54	KIT-TOOL OWNER Part #: 294000744 Required per assembly: 1 Note: (Includes 43 to 46 ) Currently Not Available
59	DRIVER SCREW Part #: 529000004 Required per assembly: 1 Currently Not Available
