01- Cylinder Head replacement parts for 2004 Sea Doo XP DI

OEM Parts Sea Doo 2004 Sea Doo XP DI 01- Cylinder Head

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	GASKET-CYL. Part #: 420931907 Required per assembly: 1 Currently Not Available
2	CYL-RESLEEVING 947-DI Part #: 421000205 Required per assembly: 1 Currently Not Available
3	CENTER PIN 8 X 12 Part #: 420632010 Required per assembly: 2 Currently Not Available
4	SCREW-TORX M10X94 Part #: 420640293 Required per assembly: 8 Currently Not Available
5	CYLINDER HEAD GASKET 947 Part #: 420931706 Required per assembly: 1 Currently Not Available
6	CYLINDER-HEAD ASSEMBLY Part #: 420613681 Required per assembly: 1 Currently Not Available
7	SCREW-HEXALOB.FL. Part #: 420640308 Required per assembly: 12 Currently Not Available
8	VALVE-EXHAUST Part #: 420854540 Required per assembly: 2 Currently Not Available
9	O RING Part #: 420250462 Required per assembly: 2 Note: Sold in multiples of 5 only Currently Not Available
10	GASKET-RUBBER Part #: 420931670 Required per assembly: 2 Currently Not Available
11	HOUSING-RAVE Part #: 420854556 Required per assembly: 2 Currently Not Available
12	SCREW-SOCKET HD.DIN.912A2 Part #: 205062560 Required per assembly: 4 $1.40 $1.13 - + Add to cart
13	SEALING RING Part #: 420931970 Required per assembly: 2 Currently Not Available
14	PISTON-VALVE EXH. Part #: 420854560 Required per assembly: 2 Currently Not Available
15	GROOVED RING Part #: 420931950 Required per assembly: 2 $20.48 $16.59 - + Add to cart
16	RAVE SPRING Part #: 420939130 Required per assembly: 2 Currently Not Available
18	SCREW-ADJUSTER Part #: 420241222 Required per assembly: 2 Currently Not Available
19	CLIP-SPRING Part #: 420838083 Required per assembly: 2 Note: Sold in multiples of 2 only Currently Not Available
20	EXHAUST MANIFOLD GASKET Part #: 420931653 Required per assembly: 2 Currently Not Available
21	MANIFOLD-EXH. Part #: 420979607 Required per assembly: 1 Currently Not Available
22	GASKET Part #: 420931990 Required per assembly: 1 Currently Not Available
23	HELICOIDAL LOCK WASHER M10 Part #: 234101601 Required per assembly: 8 $0.92 $0.75 - + Add to cart
24	SCREW-SOCKET Part #: 420941483 Required per assembly: 4 Currently Not Available
25	SCREW-SOCKET HD.DIN.912A2 Part #: 205006060 Required per assembly: 4 Note: Sold in multiples of 5 only Currently Not Available
26	SET-GASKET Part #: 420888134 Required per assembly: 1 Currently Not Available
27	SET-GASKET CYL Part #: 420888139 Required per assembly: 1 Currently Not Available
28	LOCTITE 243, 10 ML Part #: 293800060 Currently Not Available
29	MOLYKOTE III, 5.3 OZ Part #: 413707000 Currently Not Available
	GASKET-CYL. Part #: 420931905 Required per assembly: 1 Currently Not Available
	GASKET-CYL. Part #: 420931906 Required per assembly: 1 Currently Not Available
	GASKET-CYL. Part #: 420931908 Required per assembly: 1 Currently Not Available
