Frame (Model K5) replacement parts for 2005 Suzuki Bandit (GSF1200)

OEM Parts Suzuki 2005 Suzuki Bandit (GSF1200) Frame (Model K5)

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1-1	FRAME (SILVER) Part #: 41100-32F01-YD8 Required per assembly: 1 Not Available
1-3	FRAME (BLACK) Part #: 41100-32F01-019 Required per assembly: 1 Note: GSF1200SZ E3,E33 Not Available
2	CAP, FRAME, BODY Part #: 43585-03F00 Required per assembly: 2 Not Available
3	BOLT (10X37) Part #: 09106-10068 Required per assembly: 6 $3.68 $3.31 - + Add to cart
4	CAP Part #: 09250-08012 Required per assembly: 4 Note: CAP, T.D.C.PLUG; $2.27 $2.04 - + Add to cart
5	NUT Part #: 08319-3110A Required per assembly: 6 $3.38 $3.04 - + Add to cart
6	HOOK, SEAT, RAIL Part #: 46315-31F00 Required per assembly: 2 $20.25 $18.23 - + Add to cart
7	WASHER, HOOK Part #: 46317-31F00 Required per assembly: 2 $10.50 $9.45 - + Add to cart
8-1	PLATE, ENGINE, MOUNT, (SILVER) Part #: 41900-47F00-YD8 Required per assembly: 1 Not Available
8-3	PLATE, ENGINE, MOUNT, (BLACK) Part #: 41900-47F00-019 Required per assembly: 1 Note: GSF1200SZ E3,E33 Not Available
9	BOLT Part #: 07120-1030B Required per assembly: 2 $5.45 $4.91 - + Add to cart
10	NUT Part #: 08319-3110A Required per assembly: 2 $3.38 $3.04 - + Add to cart
11	BOLT Part #: 09106-08173 Required per assembly: 4 Note: BOLT (8X25); MODEL K5 Not Available
12	CAP Part #: 09250-08016 Required per assembly: 4 $2.68 $2.41 - + Add to cart
13	DAMPER, FRAME, REAR Part #: 42550-32F00 Required per assembly: 1 Not Available
14	BOLT, RR, COVER, BKT Part #: 01550-0612A Required per assembly: 2 Note: BOLT; $2.45 $2.21 - + Add to cart
15	BRACKET, MOUNT, NO.2 Part #: 41931-27E60 Required per assembly: 2 Not Available
16	BUSH Part #: 41932-27E50 Required per assembly: 2 Not Available
17	BOLT Part #: 09106-08065 Required per assembly: 4 $4.09 $3.68 - + Add to cart
18	CAP, MUF, SPRT, BOLT Part #: 09250-06016 Required per assembly: 4 $2.27 $2.04 - + Add to cart
