Frame replacement parts for 2005 Suzuki RM-Z450

OEM Parts Suzuki 2005 Suzuki RM Z450 Frame

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1-1	FRAME Part #: 41100-35G00 Required per assembly: 1 Note: MODEL K5 Not Available
1-2	FRAME Part #: 41100-35G10 Required per assembly: 1 Note: MODEL K6 Not Available
1-3	FRAME Part #: 41100-35G20 Required per assembly: 1 Note: MODEL K7 Not Available
2-1	RAIL, SEAT Part #: 41200-35G10 Required per assembly: 1 Note: MODEL K6 Not Available
2-2	RAIL, SEAT Part #: 41200-35G10 Required per assembly: 1 Note: MODEL K6 Not Available
2-3	RAIL, SEAT Part #: 41200-35G20 Required per assembly: 1 Note: MODEL K7 Not Available
3	BOLT, UPPER Part #: 09119-08095 Required per assembly: 1 $4.31 $3.88 - + Add to cart
4	NUT Part #: 08319-3108A Required per assembly: 1 $2.79 $2.51 - + Add to cart
5	BOLT, LOWER Part #: 09104-08037 Required per assembly: 2 $4.31 $3.88 - + Add to cart
5A	CUSHION, LID Part #: 63115-35G10 Required per assembly: 3 $6.95 $6.26 - + Add to cart
6	BRACKET, CDI Part #: 41347-35G00 Required per assembly: 1 Not Available
7	BOLT Part #: 09103-06256 Required per assembly: 2 $2.56 $2.30 - + Add to cart
8	PROTECTOR, FRONT, RH Part #: 42520-35G00 Required per assembly: 1 Not Available
9	PROTECTOR, FRONT, LH Part #: 42530-35G00 Required per assembly: 1 Not Available
10-1	BOLT Part #: 09103-06234 Required per assembly: 4 Note: BOLT, CHAIN GUIDE; $2.45 $2.21 - + Add to cart
10-2	BOLT Part #: 09116-06200 Required per assembly: 4 Note: MODEL K6/K7 $3.91 $3.52 - + Add to cart
11	WASHER Part #: 09160-06052 Required per assembly: 4 Note: WASHER, CLUTCH RLSE NO.2; 6.5X16X1.2 $1.75 $1.58 - + Add to cart
12-1	PLATE, ENGINE, MOUNT, FRONT Part #: 41991-35G00 Required per assembly: 2 Note: MODEL K5 Not Available
12-2	PLATE, ENGINE, MOUNT, FRONT Part #: 41991-35G11 Required per assembly: 2 Note: MODEL K6 Not Available
12-3	PLATE, ENGINE, MOUNT, FRONT Part #: 41991-35G20 Required per assembly: 2 Note: MODEL K7 Not Available
13-1	BOLT Part #: 09103-08402 Required per assembly: 2 Note: MODEL K5 Not Available
13-2	BOLT Part #: 09103-08424 Required per assembly: 2 Note: MODEL K6/K7 Not Available
14	NUT Part #: 09159-08067 Required per assembly: 2 Note: NUT, EXH PIPE; $6.98 $6.28 - + Add to cart
15-1	PLATE, ENGINE, MOUNT, UPPER, RH Part #: 41993-35G01 Required per assembly: 1 Note: MODEL K6/K7 Not Available
15-2	PLATE, ENGINE, MOUNT, UPPER, RH Part #: 41993-35G01 Required per assembly: 1 Note: MODEL K6/K7 Not Available
16	PLATE, ENGINE, MOUNT, UPPER, LH Part #: 41994-35G00 Required per assembly: 1 Not Available
17	BOLT Part #: 09103-08404 Required per assembly: 3 $3.91 $3.52 - + Add to cart
18	BOLT Part #: 09103-08385 Required per assembly: 1 $3.88 $3.49 - + Add to cart
19	ROLLER, CHAIN, CONTROL, LOWER Part #: 43910-35G00 Required per assembly: 1 $70.41 $63.37 - + Add to cart
20	ROLLER, CHAIN, CONTROL Part #: 43910-37F00 Required per assembly: 1 $74.07 $66.66 - + Add to cart
21	WASHER (8X12X1) Part #: 09181-08111 Required per assembly: 1 Note: WASHER; $2.43 $2.19 - + Add to cart
22	WASHER Part #: 09181-08167 Required per assembly: 2 Note: WASHER (8X16X1.0); $2.39 $2.15 - + Add to cart
23	BOLT Part #: 09103-08207 Required per assembly: 1 $3.03 $2.73 - + Add to cart
24	NUT Part #: 08319-2108A Required per assembly: 1 Note: NUT, T/F SHIFT LEVER; $2.67 $2.40 - + Add to cart
