Battery replacement parts for 2007 Honda AquaTrax F-12X GPScape (ARX1200T3D)

OEM Parts Honda 2007 Honda AquaTrax F 12X GPScape (ARX1200T3D) Battery

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	BATTERY (YTX20L-BS) Part #: 31500-MCA-003AH Aftermarket alternatives available Required per assembly: 1 Note: Yuasa brand Not Available
02	BAND, BATTERY Part #: 31501-HW1-670 Required per assembly: 2 Not Available
03	TRAY, ASSEMBLY, BATTERY Part #: 31502-HW1-670 Required per assembly: 1 ~~$17.68~~ $15.38 - + Add to cart
04	SUB-HARNESS Part #: 32102-HW1-670 Required per assembly: 1 ~~$16.93~~ $16.57 - + Add to cart
05	COVER Part #: 32110-HW1-670 Required per assembly: 1 ~~$18.25~~ $17.62 - + Add to cart
06	BOX Part #: 32120-HW1-670 Required per assembly: 1 ~~$9.70~~ $8.94 - + Add to cart
07	HOLDER, CONNECTOR Part #: 32121-HW1-670 Required per assembly: 1 Not Available
08	HOLDER, A, ELECTRIC Part #: 32125-HW1-670 Required per assembly: 1 ~~$11.73~~ $10.21 - + Add to cart
09	HOLDER, ELECTRIC Part #: 32126-HW1-670 Required per assembly: 1 $4.51 - + Add to cart
10	PLATE A Part #: 32131-HW1-670 Required per assembly: 1 $4.77 - + Add to cart
11	PLATE, ELECTRIC, BOX Part #: 32132-HW1-670 Required per assembly: 1 Not Available
12	BASE Part #: 32140-HW1-670 Required per assembly: 1 ~~$8.38~~ $7.18 - + Add to cart
13	CABLE Part #: 32401-HW1-690 Required per assembly: 1 ~~$65.75~~ $59.77 - + Add to cart
14	COVER Part #: 32404-HW1-670 Required per assembly: 1 Not Available
15	COVER Part #: 32405-HW1-670 Required per assembly: 1 Not Available
16	CABLE, STARTER, MOTOR Part #: 32411-HW1-691 Required per assembly: 1 Not Available
17	COVER Part #: 32411-230-000 Required per assembly: 1 ~~$7.60~~ $6.72 - + Add to cart
18	CABLE Part #: 32601-HW1-670 Required per assembly: 1 Not Available
19	SW, STARTER, MAGNETIC Part #: 35850-HW1-671 Required per assembly: 1 ~~$108.03~~ $90.07 - + Add to cart
20	RUBBER, SHOCK Part #: 35856-HW1-671 Required per assembly: 1 Not Available
21	WASHER, SPRING, (6MM) Part #: 90052-ZA0-800 Required per assembly: 2 ~~$2.11~~ $1.96 - + Add to cart
22	WASHER, PLAIN, (5MM) Part #: 90452-GK4-600 Required per assembly: 7 ~~$2.41~~ $2.23 - + Add to cart
23	WASHER, PLAIN, (6MM) Part #: 90504-921-010 Required per assembly: 2 ~~$2.40~~ $2.22 - + Add to cart
24	RIVET (4.8X17.2) Part #: 90852-HW1-670 Required per assembly: 7 ~~$3.91~~ $3.55 - + Add to cart
25	O-RING Part #: 91308-HW1-670 Required per assembly: 1 ~~$10.33~~ $8.87 - + Add to cart
26	SCREW, TAP, (4X16) Part #: 93903-244J0 Required per assembly: 2 ~~$2.57~~ $2.39 - + Add to cart
27	SCREW, TAP, (5X25) Part #: 93903-255J0 Required per assembly: 6 ~~$2.76~~ $2.57 - + Add to cart
28	SCREW, TAP, (4X12) Part #: 93913-242J0 Required per assembly: 5 ~~$3.89~~ $3.54 - + Add to cart
29	NUT, HEX., (6MM) Part #: 94002-06490-0S Required per assembly: 2 ~~$3.72~~ $3.38 - + Add to cart
