Frame replacement parts for 2007 Honda CRF250R

OEM Parts Honda 2007 Honda CRF250R Frame

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	FRAME SET Part #: 50010-KRN-A00 Required per assembly: 1 Not Available
003	STAY, CONNECTOR Part #: 50126-KRN-000 Required per assembly: 1 $6.84 $6.18 - + Add to cart
004	GUIDE, HARNESS Part #: 50128-KRN-000 Required per assembly: 1 Not Available
005	CLIP, FUEL, TUBE Part #: 50197-KRN-000 Required per assembly: 1 $5.83 $5.23 - + Add to cart
007	GUARD, L., ENGINE Part #: 50360-KRN-000 Required per assembly: 1 $15.58 $12.99 - + Add to cart
008	BRAKET, R., HEAD, HANGER Part #: 50407-KRN-850 Required per assembly: 1 Not Available
009	BRAKET, L., HEAD, HANGER Part #: 50408-KRN-851 Required per assembly: 1 Not Available
010	COLLAR (6X4) Part #: 52156-353-300 Required per assembly: 4 $7.60 $6.65 - + Add to cart
011	BOLT, FLG, (10X117) Part #: 90101-KZ3-J20 Required per assembly: 1 Not Available
012	BOLT, FLANGE, (8X125) Part #: 90105-KRN-000 Required per assembly: 1 $6.03 $5.39 - + Add to cart
013	BOLT, FLANGE, (5X12) Part #: 90106-KRN-000 Required per assembly: 1 $2.44 $2.26 - + Add to cart
014	BOLT, FLANGE, (8X55) Part #: 90107-KRN-000 Required per assembly: 2 $3.50 $3.18 - + Add to cart
015	BOLT, FLANGE, (10X58) Part #: 90109-KRN-000 Required per assembly: 1 $3.15 - + Add to cart
016	BOLT, FLG, (10X138) Part #: 90116-KW3-000 Required per assembly: 1 $15.04 $12.17 - + Add to cart
017	BOLT, FLANGE, (10X26) Part #: 90122-KRN-000 Required per assembly: 2 $3.50 $3.18 - + Add to cart
018	NUT, FLANGE, (10MM) Part #: 90302-KZ3-J40 Required per assembly: 3 $3.75 $3.41 - + Add to cart
019	WASHER (10MM) Part #: 90410-HC4-000 Required per assembly: 4 $5.18 $4.71 - + Add to cart
020	WASHER Part #: 90511-KRN-000 Required per assembly: 1 $5.74 $5.15 - + Add to cart
021	BAND, WIRE, (165MM) Part #: 90651-KV6-003 Required per assembly: 5 $4.50 $4.09 - + Add to cart
022	BAND, WIRE Part #: 90652-KT1-771 Required per assembly: 1 $5.39 $4.85 - + Add to cart
023	CLIP (2X70) Part #: 91404-KRN-000 Required per assembly: 1 $3.52 - + Add to cart
024	BOLT-WASHER (6X14) Part #: 93404-06014-00 Required per assembly: 4 $1.98 $1.83 - + Add to cart
025	NUT, FLANGE, (8MM) Part #: 94050-08000 Required per assembly: 1 Note: Sold in multiples of 5 only $2.01 $1.96 - + Add to cart
026	BOLT, FLANGE, (6X12) Part #: 96001-06012-00 Required per assembly: 1 $2.79 $2.60 - + Add to cart
027	RUBBER, TANK, GUARD Part #: 50283-MEN-A00 Required per assembly: 2 Not Available
028	FRAME, RR. Part #: 50200-KRN-850 Required per assembly: 1 Not Available
029	BRACKET Part #: 50124-KRN-A00 Required per assembly: 1 $6.66 $5.82 - + Add to cart
