2007 Honda TRX450ER - Balancer

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
004

BOLT, FLANGE, (6X14)

Part #: 90004-GHB-620 Required per assembly: 2
$4.75
$4.32
005

NUT, LOCK, (14MM)

Part #: 90231-KY4-900 Required per assembly: 1
$5.61
$5.10
006

WASHER (14.2X24)

Part #: 90433-MEY-670 Required per assembly: 1
$3.38
$3.07
007

PLATE

Part #: 90441-KA4-700 Required per assembly: 2
$4.68
$4.25
009

BEARING (17X42X13)

Part #: 91002-HP1-671 Required per assembly: 1
$14.34
$11.96
010

BEARING (20X32X14)

Part #: 91004-MEB-671 Required per assembly: 1
$11.85
$9.27
011

SHAFT, BALANCER

Part #: 13420-HP1-600 Required per assembly: 1
$311.62
$252.24
012

GEAR (40T)

Part #: 13422-HP1-600 Required per assembly: 1
$80.72
$65.35
