Carburetor replacement parts for 2007 Kawasaki KX450F (KX450-D7F)

OEM Parts Kawasaki 2007 Kawasaki KX450F (KX450 D7F) Carburetor

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

220	SCREW-PAN-CROS, 4X8 Part #: 220AA0408 Required per assembly: 3 Note: Sold in multiples of 5 only $0.74 $0.66 - + Add to cart
220A	SCREW-PAN-CROS, 4X14 Part #: 220AA0414 Required per assembly: 4 $4.73 $3.71 - + Add to cart
11061	GASKET Part #: 11061-0077 Required per assembly: 1 $11.97 $10.16 - + Add to cart
13168	LEVER Part #: 13168-0051 Required per assembly: 1 $23.49 $19.61 - + Add to cart
13271	PLATE Part #: 13271-0241 Required per assembly: 1 $16.99 $14.22 - + Add to cart
14024	COVER Part #: 14024-1971 Required per assembly: 1 $56.33 $51.31 - + Add to cart
14091	COVER Part #: 14091-0209 Required per assembly: 1 $55.48 $50.56 - + Add to cart
14091A	COVER, TOP Part #: 14091-0587 Required per assembly: 1 $62.30 - + Add to cart
14091B	COVER Part #: 14091-0588 Required per assembly: 1 $43.68 - + Add to cart
15004	CARBURETOR, ASSEMBLY, FCR-MX40 Part #: 15004-0011 Required per assembly: 1 Not Available
16012	CAP-STARTER PLUNGER Part #: 16012-0002 Required per assembly: 1 $21.88 $18.30 - + Add to cart
16014	SCREW-PILOT AIR Part #: 16014-0004 Required per assembly: 1 $18.12 $15.14 - + Add to cart
16016	PLUNGER Part #: 16016-0009 Required per assembly: 1 $42.41 $38.95 - + Add to cart
16016A	PLUNGER Part #: 16016-0017 Required per assembly: 1 $17.12 $14.33 - + Add to cart
16021	SCREW-THROTTLE STOP Part #: 16021-0013 Required per assembly: 1 $44.84 $41.11 - + Add to cart
16025	VALVE-THROTTLE Part #: 16025-0009 Required per assembly: 1 $74.90 $69.09 - + Add to cart
16025A	VALVE-THROTTLE Part #: 16025-0013 Required per assembly: 1 $305.15 $303.21 - + Add to cart
16030	VALVE-FLOAT Part #: 16030-1057 Required per assembly: 1 $48.05 $43.95 - + Add to cart
16031	FLOAT Part #: 16031-1100 Required per assembly: 1 $59.17 $53.82 - + Add to cart
16039	WASHER Part #: 16039-0230 Required per assembly: 1 $2.20 $1.62 - + Add to cart
16041	SHAFT-CARBURETOR Part #: 16041-0004 Required per assembly: 1 $163.71 $161.12 - + Add to cart
16044	CLAMP, FLOAT, VALVE Part #: 16044-007 Required per assembly: 1 $8.15 $7.05 - + Add to cart
16049	COVER-MAIN JET Part #: 16049-1051 Required per assembly: 1 $33.92 $31.41 - + Add to cart
16157	JET-STARTER Part #: 16157-0003 Required per assembly: 1 Not Available
16159	JET-POWER Part #: 16159-0004 Required per assembly: 1 $18.46 $15.42 - + Add to cart
16170	LINK ASSEMBLY Part #: 16170-0003 Required per assembly: 1 $16.83 $14.10 - + Add to cart
16187	NEEDLE-JET, NCYP Part #: 16187-0188 Note: (OPTION) Not Available
16187A	NEEDLE-JET, NCYQ Part #: 16187-0189 Note: (OPTION) Not Available
16187B	NEEDLE-JET Part #: 16187-0190 Note: (OPTION) Not Available
16187C	NEEDLE-JET, NCYS Part #: 16187-0191 Note: (OPTION) $42.03 $38.61 - + Add to cart
16187D	NEEDLE-JET, NCYT Part #: 16187-0192 Note: (OPTION) Not Available
16187E	NEEDLE-JET, NCVP Part #: 16187-0212 Note: (OPTION) Not Available
16187F	NEEDLE-JET, NCVQ Part #: 16187-0213 Note: (OPTION) Not Available
16187G	NEEDLE-JET, NCOVER Part #: 16187-0214 Required per assembly: 1 Not Available
16187H	NEEDLE-JET, NCVS Part #: 16187-0215 Note: (OPTION) Not Available
16187I	NEEDLE-JET, NCVT Part #: 16187-0216 Note: (OPTION) Not Available
21083	ARM Part #: 21083-0035 Required per assembly: 1 $43.15 $39.60 - + Add to cart
21176	SENSOR, THROTTLE Part #: 21176-0016 Required per assembly: 1 $97.00 $88.69 - + Add to cart
43028	DIAPHRAGM Part #: 43028-0006 Required per assembly: 1 $22.48 $18.79 - + Add to cart
46102	ROD Part #: 46102-0033 Required per assembly: 1 $25.61 $21.47 - + Add to cart
49121	NOZZLE-MAIN Part #: 49121-0001 Required per assembly: 1 $38.30 $35.30 - + Add to cart
92005	FITTING Part #: 92005-0016 Required per assembly: 1 $25.38 $21.28 - + Add to cart
92009	SCREW, DRAIN, M6X0.75 Part #: 92009-1551 Required per assembly: 1 $10.18 $8.70 - + Add to cart
92009A	SCREW Part #: 92009-1876 Required per assembly: 1 $11.69 $9.93 - + Add to cart
92009B	SCREW, THROTTLE, SENSOR Part #: 92009-1981 Required per assembly: 1 Note: Sold in multiples of 5 only $2.49 $1.82 - + Add to cart
92033	RING-SNAP Part #: 92033-0018 Required per assembly: 1 $3.01 $2.15 - + Add to cart
92037	CLAMP, TUBE Part #: 92037-1396 Required per assembly: 5 $5.66 $4.40 - + Add to cart
92055	RING-O, FLOAT, CHAMBER Part #: 92055-0066 Required per assembly: 1 $18.62 $15.54 - + Add to cart
92055A	RING-O Part #: 92055-0109 Required per assembly: 1 $2.23 $1.65 - + Add to cart
92055B	RING-O Part #: 92055-1004 Required per assembly: 1 $4.43 $3.49 - + Add to cart
92055C	RING-O, MAIN, JET, COVER Part #: 92055-1167 Required per assembly: 1 $9.77 $8.37 - + Add to cart
92055D	RING-O, FUEL, FITTING Part #: 92055-1223 Required per assembly: 3 $3.99 - + Add to cart
92055E	RING-O Part #: 92055-1671 Required per assembly: 1 $3.84 $2.99 - + Add to cart
92063	JET-MAIN, #165 Part #: 92063-1370 Note: (OPTION) Not Available
92063A	JET-MAIN, #168 Part #: 92063-1371 Note: (OPTION) Not Available
92063B	JET-MAIN, #170 Part #: 92063-1372 Note: (OPTION) Not Available
92063C	JET-MAIN, #172 Part #: 92063-1373 Note: (OPTION) Not Available
92063D	JET-MAIN, #175 Part #: 92063-1374 Required per assembly: 1 Note: (OPTION) Not Available
92063E	JET-MAIN, #178 Part #: 92063-1375 $16.14 $13.51 - + Add to cart
92063F	JET-MAIN, #180 Part #: 92063-1376 Note: (OPTION) $16.46 $13.79 - + Add to cart
92063G	JET-MAIN, #182 Part #: 92063-1377 Note: (OPTION) $16.46 $13.79 - + Add to cart
92063H	JET-MAIN, #185 Part #: 92063-1378 Note: (OPTION) $17.96 $15.01 - + Add to cart
92064	JET-PILOT, #38 Part #: 92064-1139 Note: (OPTION) $17.33 $14.50 - + Add to cart
92064A	JET-PILOT, #40 Part #: 92064-1140 $17.33 $14.50 - + Add to cart
92064B	JET-PILOT, #42 Part #: 92064-1141 Required per assembly: 1 Note: (OPTION) $17.33 $14.50 - + Add to cart
92064C	JET-PILOT, #45 Part #: 92064-1142 Note: (OPTION) $17.33 $14.50 - + Add to cart
92064D	JET-PILOT, #48 Part #: 92064-1143 Note: (OPTION) $17.33 $14.50 - + Add to cart
92064E	JET-PILOT, #100 Part #: 92064-1160 Required per assembly: 1 $15.29 $12.85 - + Add to cart
92081	SPRING, DIAPHRAGM Part #: 92081-1092 Required per assembly: 1 $11.91 $10.10 - + Add to cart
92081A	SPRING, THROTTLE, ADJUST, UPP Part #: 92081-1620 Required per assembly: 1 $5.10 $3.99 - + Add to cart
92093	SEAL, "U"RING Part #: 92093-1046 Required per assembly: 1 $6.67 $5.14 - + Add to cart
92145	SPRING Part #: 92145-0164 Required per assembly: 1 $17.53 $14.65 - + Add to cart
92145A	SPRING Part #: 92145-0166 Required per assembly: 1 $17.53 $14.65 - + Add to cart
92145B	SPRING Part #: 92145-0167 Required per assembly: 1 $17.53 $14.65 - + Add to cart
92150	BOLT, SOCKET, 4X12 Part #: 92150-1426 Required per assembly: 2 $6.38 $4.92 - + Add to cart
92152	COLLAR Part #: 92152-0141 Required per assembly: 1 $9.77 $8.37 - + Add to cart
92153	BOLT Part #: 92153-0639 Required per assembly: 1 $5.74 $4.46 - + Add to cart
92153A	BOLT Part #: 92153-1512 Required per assembly: 1 $13.95 $11.76 - + Add to cart
92170	CLAMP, JET, NEEDLE Part #: 92170-1204 Required per assembly: 1 $4.07 $3.23 - + Add to cart
92170A	CLAMP Part #: 92170-1582 Required per assembly: 2 $4.31 $3.40 - + Add to cart
92171	CLAMP Part #: 92171-0149 Required per assembly: 2 $3.84 $2.99 - + Add to cart
92171A	CLAMP Part #: 92171-0246 Required per assembly: 1 $6.42 $4.96 - + Add to cart
92172	SCREW Part #: 92172-0127 Required per assembly: 1 $5.74 $4.46 - + Add to cart
92172A	SCREW Part #: 92172-0128 Required per assembly: 1 $5.74 $4.46 - + Add to cart
92172B	SCREW Part #: 92172-0129 Required per assembly: 1 $5.74 $4.46 - + Add to cart
92192	TUBE Part #: 92192-0083 Required per assembly: 2 $13.01 - + Add to cart
92192A	TUBE Part #: 92192-0084 Required per assembly: 2 $13.01 - + Add to cart
92192B	TUBE Part #: 92192-0085 Required per assembly: 1 $13.01 - + Add to cart
92192C	TUBE, 7X12X270, PROTECTOR(BLACK) Part #: 92192-0219 Required per assembly: 1 $19.17 $15.99 - + Add to cart
92200	WASHER Part #: 92200-0107 Required per assembly: 1 $3.05 $2.19 - + Add to cart
92200A	WASHER, LINK, ARM, STAINLESS Part #: 92200-1434 Required per assembly: 1 $2.49 $1.82 - + Add to cart
