Muffler replacement parts for 2008 Honda AquaTrax F-15X (ARX1500T3)

OEM Parts Honda 2008 Honda AquaTrax F 15X (ARX1500T3) Muffler

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	GASKET, EX., PIPE Part #: 18235-HW1-672 Required per assembly: 1 $27.74 $23.14 - + Add to cart
02	BODY, EX. Part #: 18310-HW5-900 Required per assembly: 1 $845.92 $735.95 - + Add to cart
03	PIPE, EX. Part #: 18320-HW5-900 Required per assembly: 1 Not Available
04	GASKET, EX., PIPE Part #: 18324-HW5-901 Required per assembly: 1 Not Available
05	HOSE, EX. Part #: 18325-HW1-670 Required per assembly: 1 $90.05 - + Add to cart
06	MUFFLER, WATER Part #: 18331-HW5-900 Required per assembly: 1 $899.10 $782.22 - + Add to cart
07	RUBBER, B, SHEET Part #: 18336-HW1-670 Required per assembly: 4 $6.53 $5.78 - + Add to cart
08	OUTLET, EX. Part #: 18345-HW5-900 Required per assembly: 1 Not Available
09	SEAL, EX., OUTLET Part #: 18346-HW5-900 Required per assembly: 1 $6.92 $6.11 - + Add to cart
10	HOSE, WATER, LOCK Part #: 18351-HW5-900 Required per assembly: 1 $90.58 $78.81 - + Add to cart
11	NOZZLE, EX., OUTLET Part #: 18365-HW5-900 Required per assembly: 1 $8.79 $7.84 - + Add to cart
12	JOINT, D, WATER, HOSE Part #: 19004-HW1-680 Required per assembly: 1 Not Available
13	BAND, HOSE, (140MM) Part #: 19035-HW1-670 Required per assembly: 2 $19.84 $16.43 - + Add to cart
14	HOSE, C, WATER Part #: 19063-HW5-900 Required per assembly: 1 $6.72 $5.87 - + Add to cart
15	CLAMP (6-16MM) Part #: 19080-HW5-900 Required per assembly: 2 $3.09 - + Add to cart
16	CLAMP (10-27MM) Part #: 19081-HW5-900 Required per assembly: 2 $1.99 $1.84 - + Add to cart
17	CLAMP (83-108MM) Part #: 19083-HW5-900 Required per assembly: 1 $21.09 $17.24 - + Add to cart
18	CLAMP (89-140MM) Part #: 19084-HW5-900 Required per assembly: 1 $2.87 $2.67 - + Add to cart
19	CLAMP (70-95MM) Part #: 19085-HW5-900 Required per assembly: 3 $2.44 $2.26 - + Add to cart
20	HOSE A Part #: 19511-HW5-900 Required per assembly: 1 $9.33 $7.94 - + Add to cart
21	BAND, BATTERY Part #: 31501-HW1-670 Required per assembly: 1 Not Available
22	BASE, CABLE, MOUNTING Part #: 32170-HW1-670 Required per assembly: 3 $1.73 $1.59 - + Add to cart
23	SENSOR ASSEMBLY Part #: 37750-KPH-701 Required per assembly: 1 $61.02 $48.66 - + Add to cart
24	BOLT, FLANGE, (6MM) Part #: 90008-HW1-670 Required per assembly: 2 $3.27 $2.97 - + Add to cart
25	BOLT, FLANGE, (8X55) Part #: 90229-HW5-900 Required per assembly: 5 $4.51 - + Add to cart
26	BOLT, FLANGE, (8X90) Part #: 90230-HW5-900 Required per assembly: 4 $5.48 $4.94 - + Add to cart
27	WASHER (10MM) Part #: 90406-HW1-670 Required per assembly: 1 $3.50 $3.18 - + Add to cart
28	BAND, WIRE, (95MM) Part #: 90650-KV6-003 Required per assembly: 1 $4.43 $4.03 - + Add to cart
29	NIPPLE, GREASE Part #: 90951-HW1-A20 Required per assembly: 1 $2.94 $2.73 - + Add to cart
30	JOINT, GREASE, NIPPLE Part #: 90953-HW1-670 Required per assembly: 1 $11.77 $10.04 - + Add to cart
31	O-RING (17.8X2.4) Part #: 91256-383-721 Required per assembly: 1 $3.26 $3.03 - + Add to cart
32	SCREW, TAP, (5X20) Part #: 93903-254J0 Required per assembly: 4 $2.41 $2.19 - + Add to cart
33	BULK HOSE (5.5X3000) Part #: 95005-55003-20M Required per assembly: 1 Not Available
