Radiator Hose replacement parts for 2008 Suzuki GSX650F

OEM Parts Suzuki 2008 Suzuki GSX650F Radiator Hose

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	CAP Part #: 17730-14G00 Required per assembly: 1 Note: CAP, RADIATOR (1.1); $55.29 $47.27 - + Add to cart
2	CONDUCTION Part #: 17791-18H00 Required per assembly: 1 $33.16 $29.84 - + Add to cart
3	BOLT, SHIFT, LEVER Part #: 01550-0620A Required per assembly: 2 Note: BOLT, INSPECTION CAP; $2.45 $2.21 - + Add to cart
4	HOSE, RADIATOR, INLET Part #: 17851-18H00 Required per assembly: 1 $53.16 $47.84 - + Add to cart
5	HOSE, RADIATOR, OUTLET Part #: 17852-18H00 Required per assembly: 1 $53.16 $47.84 - + Add to cart
6	PIPE, RADIATOR, OUTLET Part #: 17890-17H00 Required per assembly: 1 Not Available
7	HOSE, WATER, PUMP, INLET Part #: 17853-18H00 Required per assembly: 1 $81.23 $73.11 - + Add to cart
8	HOSE, WATER, PUMP, OUTLET Part #: 17854-18H00 Required per assembly: 1 $89.87 $76.82 - + Add to cart
9	CLAMP Part #: 09402-38512 Required per assembly: 8 $14.48 $13.03 - + Add to cart
10	CONNECTOR, CYLINDER, INLET Part #: 17861-17H00 Required per assembly: 1 Not Available
11	O RING Part #: 17863-18H00 Required per assembly: 1 $12.84 $11.56 - + Add to cart
12	BOLT, INSPECTION, CAP Part #: 01547-0620A Required per assembly: 4 $2.54 $2.29 - + Add to cart
13	HOSE, WATER, BYPASS Part #: 17856-18H00 Required per assembly: 1 Not Available
14	CLAMP Part #: 09401-12414 Required per assembly: 2 $4.02 $3.62 - + Add to cart
15	CLAMP (L:165) Part #: 09407-18402 Required per assembly: 1 $13.51 $12.16 - + Add to cart
16	PIPE, CYLINDER, OUTLET Part #: 17880-18H00 Required per assembly: 2 Not Available
17	O RING Part #: 09280-18009 Required per assembly: 2 $7.31 $6.58 - + Add to cart
18	BOLT, RR, SIDE, RR, BKT Part #: 07130-0612A Required per assembly: 2 Note: BOLT, MAG LEAD; $3.13 $2.82 - + Add to cart
19	HOSE, CYLINDER, OUTLET, RH Part #: 17857-18H00 Required per assembly: 1 $30.53 $27.48 - + Add to cart
20	HOSE, CYLINDER, OUTLET, LH Part #: 17858-18H00 Required per assembly: 1 $26.49 $23.84 - + Add to cart
21	CLAMP, JOINT Part #: 09402-28513 Required per assembly: 2 Note: CLAMP; $8.81 $7.93 - + Add to cart
22	CLAMP Part #: 09402-32512 Required per assembly: 2 $13.97 $12.57 - + Add to cart
23	PLATE, WATER, HOSE, CLAMP Part #: 17859-18H00 Required per assembly: 1 Not Available
25	CONNECTOR Part #: 17662-18H00 Required per assembly: 1 Not Available
26	BOLT, SHIFT, LEVER Part #: 01550-0620A Required per assembly: 2 Note: BOLT, INSPECTION CAP; $2.45 $2.21 - + Add to cart
27	BRACKET Part #: 17669-18H00 Required per assembly: 1 Not Available
28	BOLT, RR, COVER, BKT Part #: 01550-0612A Required per assembly: 2 Note: BOLT; $2.45 $2.21 - + Add to cart
29	THERMOSTAT, WATER Part #: 17670-76G00 Required per assembly: 1 Note: MODEL K5/K6/K7 $47.50 $40.60 - + Add to cart
30	TANK, ASSEMBLY, RESERVOIR Part #: 17910-18H00 Required per assembly: 1 Not Available
31	CAP Part #: 17931-02FA0 Required per assembly: 1 $7.18 $6.46 - + Add to cart
32	BOLT, ENGINE, PROTECTOR Part #: 09111-06085 Required per assembly: 2 Note: MODEL K6/K7 $5.77 $5.19 - + Add to cart
33	BRACKET, RESERVER, TANK Part #: 17920-18H00 Required per assembly: 1 Not Available
34	BOLT, SHIFT, LEVER Part #: 01550-0620A Required per assembly: 1 Note: BOLT, INSPECTION CAP; $2.45 $2.21 - + Add to cart
35	HOSE, OVERFLOW Part #: 17982-18H00 Required per assembly: 1 Not Available
36	HOSE, OVERFLOW, NO.2 Part #: 17983-18H00 Required per assembly: 1 Not Available
37	HOSE, OVERFLOW, NO.3 Part #: 17984-18H00 Required per assembly: 1 Not Available
38	HOSE, RESERVOIR, TANK, OVERFLOW Part #: 09359-50901-980 Required per assembly: 1 Note: HOSE, OVERFLOW NO.4; L:980->260 $24.24 $20.72 - + Add to cart
39	NIPPLE Part #: 13471-18H00 Required per assembly: 1 $11.34 $10.21 - + Add to cart
40	JOINT, OVERFLOW, HOSE, NO.2 Part #: 09367-04011 Required per assembly: 1 Not Available
41	JOINT Part #: 09367-06009 Required per assembly: 1 Not Available
42	HOSE, RESERVOIR, TANK Part #: 09352-50901-00B Required per assembly: 1 Note: HOSE, TANK OVERFLOW; L:2000->700 $34.44 $29.44 - + Add to cart
43	HOSE Part #: 09352-50901-600 Required per assembly: 1 Note: E33 L:600->225 $15.40 $13.86 - + Add to cart
44	HOSE, CANISTER, TO, CARBURETOR Part #: 09359-35751-600 Required per assembly: 1 Note: L:600 --> 400 Not Available
45	JOINT Part #: 09367-06007 Required per assembly: 1 $4.43 $3.99 - + Add to cart
46	CLIP Part #: 09401-08410 Required per assembly: 3 $2.35 $2.12 - + Add to cart
47	CLAMP Part #: 09404-08211 Required per assembly: 1 $2.35 $2.12 - + Add to cart
48	CLAMP (L:65) Part #: 09404-06039 Required per assembly: 1 Note: CLAMP (L:45); $10.57 $9.51 - + Add to cart
49	CLIP Part #: 09401-08411 Required per assembly: 2 $2.21 $1.99 - + Add to cart
50	BOLT, RR, COVER, BKT Part #: 01550-0612A Required per assembly: 1 Note: BOLT; $2.45 $2.21 - + Add to cart
51	NUT Part #: 08316-1006A Required per assembly: 1 $2.72 $2.45 - + Add to cart
