Evap System (E33) replacement parts for 2008 Suzuki Hayabusa (GSX1300R)

OEM Parts Suzuki 2008 Suzuki Hayabusa (GSX1300R) Evap System (E33)

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	HOSE, TANK, &, VALVE Part #: 44434-15H00 Required per assembly: 1 Not Available
2	CLIP Part #: 09401-11413 Required per assembly: 7 $2.80 $2.52 - + Add to cart
3	VALVE, BREATHER Part #: 44240-17C00 Required per assembly: 1 Note: VALVE, TANK BREATHER; $73.01 $62.43 - + Add to cart
4	PLATE, BREATHER, VALVE Part #: 44890-24F00 Required per assembly: 1 Not Available
5	CUSHION Part #: 44894-24A00 Required per assembly: 1 $2.18 $1.96 - + Add to cart
6	SCREW Part #: 02142-0610B Required per assembly: 1 Note: SCREW, HOLDER; $2.27 $2.04 - + Add to cart
7	PLATE, VALVE Part #: 44892-24A00 Required per assembly: 1 Note: PLATE, BREATHER VALVE; $5.11 $4.60 - + Add to cart
8	CUSHION Part #: 44894-24A00 Required per assembly: 1 $2.18 $1.96 - + Add to cart
9	SCREW, PLATE Part #: 02142-0408B Required per assembly: 2 Note: SCREW, PLATE; $2.13 $1.92 - + Add to cart
11	VALVE, 2, WAY, &, BREATHER Part #: 44240-24F00 Required per assembly: 1 Note: VALVE, 2 WAY; $69.87 $59.74 - + Add to cart
12	WASHER Part #: 09160-06077 Required per assembly: 1 Note: WASHER, LICENSE LAMP; 6.5X20X1.2 $2.37 $2.13 - + Add to cart
13	BOLT Part #: 01550-0616B Required per assembly: 1 $2.95 $2.66 - + Add to cart
14	CANISTER Part #: 17210-15H00 Required per assembly: 1 $305.77 $275.19 - + Add to cart
15	CAP Part #: 09251-07003 Required per assembly: 1 $2.68 $2.41 - + Add to cart
16	CUSHION, CANISTER Part #: 44883-06G01 Required per assembly: 1 $16.45 $14.81 - + Add to cart
17	BRACKET, CANISTER Part #: 44880-15H00 Required per assembly: 1 Not Available
18	BOLT Part #: 01550-0612B Required per assembly: 2 Note: BOLT, BRACKET; $2.95 $2.66 - + Add to cart
19	SCREW Part #: 02142-0610B Required per assembly: 1 Note: SCREW, HOLDER; $2.27 $2.04 - + Add to cart
22	CLIP Part #: 09401-12404 Required per assembly: 2 $2.95 $2.66 - + Add to cart
