Evap System (E33) replacement parts for 2008 Suzuki V-Strom (DL1000)

OEM Parts Suzuki 2008 Suzuki V Strom (DL1000) Evap System (E33)

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1-1	HOSE, TANK, &, VALVE Part #: 44434-06G00 Required per assembly: 1 Note: MODEL K7 Not Available
1-2	HOSE, TANK, &, VALVE Part #: 44434-06G10 Required per assembly: 1 Note: MODEL K8/K9 Not Available
2	CLIP Part #: 09401-11413 Required per assembly: 2 $2.80 $2.52 - + Add to cart
3	VALVE, BREATHER Part #: 44240-17C00 Required per assembly: 1 Note: VALVE, TANK BREATHER; $69.87 $59.74 - + Add to cart
4	BRACKET, BREATHER, VALVE Part #: 44890-06G00 Required per assembly: 1 Not Available
5	CUSHION Part #: 44894-24A00 Required per assembly: 1 $2.08 $1.87 - + Add to cart
6	BOLT Part #: 01550-0612B Required per assembly: 1 Note: BOLT, BRACKET; $2.87 $2.58 - + Add to cart
7	RIVET Part #: 09229-04020 Required per assembly: 2 $3.19 $2.87 - + Add to cart
8	WASHER Part #: 08322-0104B Required per assembly: 2 Note: WASHER, HEADLAMP; $0.30 $0.27 - + Add to cart
9	PLATE, VALVE Part #: 44892-24A00 Required per assembly: 1 Note: PLATE, BREATHER VALVE; $4.89 $4.40 - + Add to cart
10	CUSHION Part #: 44894-24A00 Required per assembly: 1 $2.08 $1.87 - + Add to cart
11	SCREW, PLATE Part #: 02142-0408B Required per assembly: 2 Note: SCREW, PLATE; $2.07 $1.86 - + Add to cart
12-1	HOSE, VALVE, &, CANISTER Part #: 44435-06G00 Required per assembly: 1 Note: MODEL K7 Not Available
12-2	HOSE, VALVE, &, CANISTER Part #: 44435-06G10 Required per assembly: 1 Note: MODEL K8/K9 Not Available
13	CLIP Part #: 09401-11413 Required per assembly: 3 $2.80 $2.52 - + Add to cart
14	CANISTER Part #: 17210-26E00 Required per assembly: 1 $346.80 $296.51 - + Add to cart
15	CAP Part #: 09251-07003 Required per assembly: 1 $2.68 $2.41 - + Add to cart
16	BRACKET, CANISTER Part #: 44881-06G00 Required per assembly: 1 Not Available
17	CUSHION, CANISTER Part #: 44883-06G01 Required per assembly: 1 $16.45 $14.81 - + Add to cart
18-1	HOSE, PURGE Part #: 44436-06G00 Required per assembly: 1 Note: MODEL K7 Not Available
18-2	HOSE, PURGE Part #: 44436-06G10 Required per assembly: 1 Note: MODEL K8/K9 Not Available
19	CLIP Part #: 09401-12404 Required per assembly: 2 $2.95 $2.66 - + Add to cart
20	JOINT Part #: 09364-06009 Required per assembly: 1 Note: JOINT, PURGE HOSE; Not Available
