OEM Parts Victory 2008 Victory VISION ALL OPTIONS (V08SB36/SD36) Electrical, Ignition System - V08sb36/Sd36 All Options

2008 Victory VISION ALL OPTIONS (V08SB36/SD36) - Electrical, Ignition System - V08sb36/Sd36 All Options

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

SCR-SOCFLGHD, M6X1.0X16

Part #: 7518803 Required per assembly: 6
Currently Not Available
2

BRACKET-IGNITION COIL

Part #: 5250414 Required per assembly: 1
Currently Not Available
3

SPACER-IGNITION COIL

Part #: 5510601 Required per assembly: 1
Currently Not Available
4

KIT, IGNITION, COIL

Part #: 2876049 Required per assembly: 1 Note: Coil
Currently Not Available
5

COUNTERSHAFT DRIVE COVER BOLTS

Part #: 7517259 Required per assembly: 1 Note: For a rider adding Billet Accessories to a Victory, these beautiful Countershaft Drive Cover Bolts are a “must-have” item. They hold the Countershaft Drive Cover securely in place and complete the bike’s beautiful custom look. Bolts are sold individually.
Currently Not Available
6

LEAD-SPARK PLUG

Part #: 4012733 Required per assembly: 1 Note: (Front Cylinder)
Currently Not Available
7

LEAD-SPARK PLUG

Part #: 4012746 Required per assembly: 1 Note: (Rear Cylinder)
Currently Not Available
8

SPARK, PLUG-DCPR6E, NGK

Part #: 3070202 Required per assembly: 2
Currently Not Available
9

CLIP, SNAP-IN

Part #: 7080756 Required per assembly: 1
Currently Not Available
10

KIT-STATOR, AND, ROTOR, 2010

Part #: 2204532 Required per assembly: 1
Currently Not Available
11

CLIP-STATOR WIRE

Part #: 5251115 Required per assembly: 1
Currently Not Available
12

SCREW, SOCHD, M5X8

Part #: 7517515 Required per assembly: 2
Currently Not Available
13

SCREW, SOCHD, M6X30

Part #: 7517301 Required per assembly: 3
Currently Not Available
14

CLIP-TINNERMAN, D98640-051M

Part #: 7670136 Required per assembly: 3
Currently Not Available
15

COVER-IGNITION/COIL

Part #: 5245659 Required per assembly: 1
Currently Not Available
16

ASM-IGN, SW/LOCKS, W/TRUNK

Part #: 1015982 Required per assembly: 1
Currently Not Available
16

ASM-IGN, SW/LOCKS, NO, TRUNK

Part #: 1015274 Required per assembly: 1
Currently Not Available
17

KEY-BLANK, VISION, NO, BADGES

Part #: 4012155 Required per assembly: 1
Currently Not Available
18

SCR-HXFLGHD, M6X20, ZPC

Part #: 7518141 Required per assembly: 3
Currently Not Available
19

SCR-HXFLGHD, M6X16, 0600086

Part #: 7518591 Required per assembly: 4
Currently Not Available
