Carburetor replacement parts for 2008 Yamaha YFM4FGX

OEM Parts Yamaha 2008 Yamaha YFM4FGX Carburetor

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	CARBURETOR ASSEMBLY 1 Part #: 5TE-E4101-10-00 Required per assembly: 1 Not Available
002	NEEDLE SET Part #: 5ND-1490J-10-00 Required per assembly: 1 $46.99 $38.66 - + Add to cart
003	SPRING, DIAPHRAGM Part #: 5DM-14933-00-00 Required per assembly: 1 $10.99 $8.71 - + Add to cart
004	DIAPHRAGM ASSEMBLY Part #: 5GH-14940-10-00 Required per assembly: 1 $69.98 $55.60 - + Add to cart
005	VALVE, THROTTLE, 1 Part #: 5DM-14112-00-00 Required per assembly: 1 $95.98 $80.08 - + Add to cart
006	RING Part #: 5GH-14918-10-00 Required per assembly: 1 $7.49 $5.58 - + Add to cart
008	WASHER Part #: 3H1-14962-00-00 Required per assembly: 1 $8.49 $6.31 - + Add to cart
009	O-RING Part #: 3H1-14147-00-00 Required per assembly: 1 $9.49 $7.42 - + Add to cart
010	JET, MAIN, (#1325) Part #: 3G2-1423A-77-00 Required per assembly: 1 Note: U49 $14.49 $11.96 - + Add to cart
011	HOLDER Part #: 5GH-14261-00-00 Required per assembly: 1 $44.99 $35.96 - + Add to cart
012	O-RING Part #: 583-14561-00-00 Required per assembly: 1 $5.99 $4.94 - + Add to cart
013	PIN, FLOAT Part #: 127-14186-00-00 Required per assembly: 1 $6.99 $6.65 - + Add to cart
014	NEEDLE VALVE SET Part #: 5UH-14107-20-00 Required per assembly: 1 $51.99 $49.79 - + Add to cart
015	O-RING Part #: 5DM-14561-00-00 Required per assembly: 1 $17.48 $14.56 - + Add to cart
016	NOZZLE, MAIN Part #: 5DM-14141-40-00 Required per assembly: 1 $38.99 $31.65 - + Add to cart
017	SCREW Part #: 4KM-14216-00-00 Required per assembly: 2 $8.49 $6.31 - + Add to cart
018	JET, MAIN, (#, 80) Part #: 1HX-14231-16-00 Required per assembly: 1 $14.49 $9.80 - + Add to cart
019	PIPE Part #: 4KB-14193-20-00 Required per assembly: 1 $51.99 $40.28 - + Add to cart
020	SCREW, PAN, HEAD Part #: 98580-04010-00 Required per assembly: 3 $9.49 $6.05 - + Add to cart
021	STARTER SET Part #: 5ND-1410A-00-00 Required per assembly: 1 $69.98 $56.37 - + Add to cart
022	JET, POWER, (#75) Part #: 3G2-14231-15-00 Required per assembly: 1 $15.49 $10.84 - + Add to cart
023	PLUG, DRAIN Part #: 3FV-14191-00-00 Required per assembly: 1 $26.98 $21.20 - + Add to cart
024	SCREW, PAN, HEAD Part #: 9850L-04006-00 Required per assembly: 3 $1.00 $0.76 - + Add to cart
025	O-RING Part #: 5FU-E4147-00-00 Required per assembly: 1 $17.98 $14.68 - + Add to cart
026	SCREW, PAN, HEAD Part #: 98507-04014-00 Required per assembly: 4 $2.00 $1.30 - + Add to cart
027	NUT, CABLE, ADJUSTING Part #: 522-14161-00-00 Required per assembly: 1 $10.99 $8.33 - + Add to cart
028	SCREW, PAN, HEAD Part #: 98507-04008-00 Required per assembly: 1 $2.14 $1.42 - + Add to cart
029	SCREW Part #: 1FN-14565-00-00 Required per assembly: 1 $8.49 $6.31 - + Add to cart
030	FLOAT Part #: 5DM-14985-00-00 Required per assembly: 1 $80.98 $67.44 - + Add to cart
031	PIPE Part #: 5GH-14197-00-00 Required per assembly: 1 $49.99 $39.01 - + Add to cart
032	SCREW, PAN, HEAD, -, FOR, CARB, #1, 4 Part #: 98580-04014-00 Required per assembly: 2 $3.29 $2.74 - + Add to cart
034	WASHER (JF2) Part #: 92907-04600-00 Required per assembly: 2 $1.85 $1.21 - + Add to cart
035	CLIP Part #: 5GH-14937-00-00 Required per assembly: 1 $35.99 $26.37 - + Add to cart
036	JET, PILOT, (#175) Part #: 4KM-14142-17-00 Required per assembly: 1 $10.99 $8.38 - + Add to cart
037	DIAPHRAGM SET 5 Part #: 5ND-1490H-00-00 Required per assembly: 1 $46.99 $37.56 - + Add to cart
038	GUIDE, CABLE Part #: 5FU-E4155-00-00 Required per assembly: 1 $11.99 $8.75 - + Add to cart
039	THROTTLE SCREW SET Part #: 5GH-14103-01-00 Required per assembly: 1 $125.98 $105.36 - + Add to cart
040	RING Part #: 5GH-14918-00-00 Required per assembly: 1 $21.98 $16.28 - + Add to cart
041	CLIP Part #: 4XE-14937-00-00 Required per assembly: 1 $18.98 $13.44 - + Add to cart
042	WASHER Part #: 256-14956-01-00 Required per assembly: 1 $8.49 $6.35 - + Add to cart
043	SCREW Part #: 3DM-14216-00-00 Required per assembly: 1 $8.49 $6.55 - + Add to cart
