Steering Shaft replacement parts for 2009 Honda AquaTrax F-15 (ARX1500N3)

OEM Parts Honda 2009 Honda AquaTrax F 15 (ARX1500N3) Steering Shaft

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	BAND, HOSE, (140MM) Part #: 19035-HW1-670 Required per assembly: 3 ~~$19.84~~ $16.43 - + Add to cart
02	BASE, CABLE, MOUNTING Part #: 32170-HW1-670 Required per assembly: 5 ~~$1.73~~ $1.59 - + Add to cart
03	SWITCH, ASSEMBLY, LIMIT Part #: 35600-HW5-901 Required per assembly: 1 ~~$64.35~~ $52.08 - + Add to cart
04	JOINT Part #: 47412-HW5-900 Required per assembly: 2 ~~$16.42~~ $13.67 - + Add to cart
05	GROMMET, CABLE Part #: 47731-HW1-670 Required per assembly: 1 ~~$18.24~~ $16.30 - + Add to cart
06	COLLAR, CABLE, LOCK Part #: 47732-HW1-670 Required per assembly: 2 ~~$4.36~~ $3.96 - + Add to cart
07	CABLE, STEERING Part #: 47810-HW5-901 Required per assembly: 1 ~~$179.82~~ $143.95 - + Add to cart
08	BRACKET ASSEMBLY Part #: 47813-HW5-900 Required per assembly: 1 ~~$5.62~~ $5.52 - + Add to cart
09	HOLDER Part #: 47816-HW5-900 Required per assembly: 1 ~~$30.95~~ $27.56 - + Add to cart
10	SEAL Part #: 47817-HW5-900 Required per assembly: 1 ~~$2.81~~ $2.61 - + Add to cart
11	PIN, STEERING, SWITCH Part #: 53143-HW1-670 Required per assembly: 1 ~~$3.64~~ $3.31 - + Add to cart
12	SHAFT, STEERING Part #: 53310-HW1-681 Required per assembly: 1 ~~$283.00~~ $246.21 - + Add to cart
13	BUSH, FLANGE, (40X30) Part #: 53311-HW1-670 Required per assembly: 1 Not Available
14	BUSH, FLANGE, (50X30) Part #: 53312-HW1-670 Required per assembly: 1 Not Available
15	RETAINER Part #: 53315-HW1-670 Required per assembly: 1 Not Available
16	HOLDER ASSEMBLY Part #: 53320-HW5-900 Required per assembly: 1 ~~$52.23~~ $45.44 - + Add to cart
17	LEVER Part #: 53331-HW5-900 Required per assembly: 1 ~~$74.10~~ $59.09 - + Add to cart
18	HOLDER Part #: 53332-HW1-670 Required per assembly: 1 ~~$8.30~~ $7.23 - + Add to cart
19	SEAL Part #: 53333-HW5-900 Required per assembly: 1 Not Available
20	BRACKET Part #: 53335-HW5-900 Required per assembly: 1 ~~$7.60~~ $6.72 - + Add to cart
21	CAM, STEERING, SWITCH Part #: 53337-HW1-670 Required per assembly: 1 ~~$5.52~~ $4.97 - + Add to cart
22	BOLT, FLANGE, (8X35) Part #: 90114-HW1-671 Required per assembly: 4 ~~$4.64~~ $4.22 - + Add to cart
23	BOLT, FLANGE, (6X45) Part #: 90124-HW5-900 Required per assembly: 2 $4.05 - + Add to cart
24	BOLT, FLANGE, (6X56) Part #: 90210-HW1-670 Required per assembly: 1 ~~$4.36~~ $3.96 - + Add to cart
25	NUT, CABLE, LOCK Part #: 90212-HW5-900 Required per assembly: 1 Not Available
26	BOLT, FLANGE, (6X35) Part #: 90225-HW1-670 Required per assembly: 2 ~~$3.27~~ $3.04 - + Add to cart
27	NUT, HEX., (20MM) Part #: 90302-ZV5-003 Required per assembly: 1 ~~$6.90~~ $5.58 - + Add to cart
28	NUT, SELF-LOCK, (6MM) Part #: 90303-HW1-671 Required per assembly: 5 Not Available
29	NUT, SELF-LOCK, (8MM) Part #: 90305-ZV4-000 Required per assembly: 4 ~~$4.97~~ $4.88 - + Add to cart
30	WASHER, PLAIN, (6MM) Part #: 90504-HW1-670 Required per assembly: 1 ~~$2.86~~ $2.65 - + Add to cart
31	WASHER, PLAIN, (6MM) Part #: 90511-ZV4-000 Required per assembly: 2 ~~$3.44~~ $3.13 - + Add to cart
32	WASHER (6MM) Part #: 90512-921-010 Required per assembly: 9 ~~$2.19~~ $2.03 - + Add to cart
33	WASHER (8MM) Part #: 90514-921-000 Required per assembly: 8 ~~$2.11~~ $1.96 - + Add to cart
34	BAND, WIRE, HARNESS Part #: 90650-MA6-720 Required per assembly: 2 ~~$6.39~~ $6.16 - + Add to cart
35	CLIP, SPLASH, GUARD, (EACH) Part #: 90653-HC4-900 Required per assembly: 1 ~~$1.67~~ $1.52 - + Add to cart
36	NUT, HEX., (6MM) Part #: 94001-06490-0S Required per assembly: 4 ~~$3.21~~ $2.92 - + Add to cart
37	E-RING (4MM) Part #: 94540-04029 Required per assembly: 1 ~~$5.26~~ $5.19 - + Add to cart
