Starting Motor replacement parts for 2009 Honda AquaTrax F-15X (ARX1500T3)

OEM Parts Honda 2009 Honda AquaTrax F 15X (ARX1500T3) Starting Motor

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	STARTER MOTOR ASSEMBLY Part #: 31200-HW5-901 Required per assembly: 1 $519.86 $472.60 - + Add to cart
02	BRUSH, SET, A, CARBON Part #: 31201-MEW-921 Required per assembly: 1 $9.34 $8.07 - + Add to cart
03	BRUSH, SET, B, CARBON Part #: 31202-MEW-921 Required per assembly: 1 $15.17 $12.64 - + Add to cart
04	HOLDER, BRUSH Part #: 31203-MEW-921 Required per assembly: 1 $9.01 $7.78 - + Add to cart
05	SPRING, CARBON, BRUSH Part #: 31204-MEW-921 Required per assembly: 4 $15.08 $12.19 - + Add to cart
06	RING Part #: 31207-KS5-901 Required per assembly: 2 $4.43 $4.03 - + Add to cart
07	INSULATOR Part #: 31208-MEW-921 Required per assembly: 1 $8.36 $7.27 - + Add to cart
08	STOPPER, TERMINAL Part #: 31209-MEW-921 Required per assembly: 1 $12.42 $10.05 - + Add to cart
09	NUT, FLANGE, (6MM) Part #: 90217-HW1-670 Required per assembly: 1 $2.78 $2.58 - + Add to cart
10	O-RING (24.4X3.1) Part #: 91312-MG7-003 Required per assembly: 1 $7.61 $6.11 - + Add to cart
11	O-RING Part #: 91320-MB0-000 Required per assembly: 3 $3.47 $3.15 - + Add to cart
12	SCREW-WASHER (5X12) Part #: 93892-05012-08 Required per assembly: 1 $2.18 $2.02 - + Add to cart
13	NUT, HEX., (6MM) Part #: 94002-06490-0S Required per assembly: 1 $3.72 $3.38 - + Add to cart
14	BOLT, FLANGE, (6X32) Part #: 95701-06032-02 Required per assembly: 2 $2.49 $2.31 - + Add to cart
15	BOLT SET Part #: 31205-HW5-901 Required per assembly: 2 Not Available
16	TERMINAL BOLT Part #: 31206-HW5-901 Required per assembly: 1 $3.90 - + Add to cart
17	WASHER (6MM) Part #: 31210-HW5-901 Required per assembly: 1 Not Available
18	WASHER, SPRING, (6MM) Part #: 31211-HW5-901 Required per assembly: 1 Not Available
