Frame replacement parts for 2009 Honda Ruckus (NPS50S)

OEM Parts Honda 2009 Honda Ruckus (NPS50S) Frame

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	PIPE, ENGINE, MOUNT Part #: 11105-GET-000 Required per assembly: 1 $15.53 - + Add to cart
002	RUBBER, TANK, STOPPER Part #: 17502-GAA-000 Required per assembly: 1 $5.40 - + Add to cart
003	FRAME, FR. Part #: 50110-GEE-050 Required per assembly: 1 Note: Replacement frames do not have VIN numbers. Please check with your local DMV for your state's registration requirements. ~~$355.97~~ $346.64 - + Add to cart
004	FRAME, RR., NH303M, (MAT, AXIS, GRAY, METALLIC) Part #: 50115-GGA-740ZB Required per assembly: 1 Not Available
005	CAP (33MM) NH1 (BLACK) Part #: 50169-KW3-000ZB Required per assembly: 2 $11.29 - + Add to cart
006	SEAT RAIL NH303M (MAT AXIS GRAY METALLIC) Part #: 50200-GEZ-670ZC Required per assembly: 1 Not Available
007	LINK, ENGINE, HANGER Part #: 50351-GEZ-610 Required per assembly: 1 ~~$68.60~~ $65.52 - + Add to cart
008	RUBBER, LINK, STOPPER Part #: 50352-GW0-730 Required per assembly: 1 $8.89 - + Add to cart
009	BUSH, ENG, HGR, RUB Part #: 50356-KBN-900 Required per assembly: 2 $10.06 - + Add to cart
010	HOLDER, ASSEMBLY, HELMET Part #: 50710-GEZ-003 Required per assembly: 1 ~~$37.68~~ $31.41 - + Add to cart
011	BOLT, FLG, (10X230) Part #: 90101-GET-000 Required per assembly: 1 $9.68 - + Add to cart
012	BOLT, FLANGE, (10X35) Part #: 90102-GEZ-000 Required per assembly: 1 ~~$2.63~~ $2.24 - + Add to cart
013	BOLT Part #: 90107-449-000 Required per assembly: 2 $4.94 - + Add to cart
014	NUT, U, (10MM) Part #: 90304-GE8-003 Required per assembly: 1 Note: Sold in multiples of 5 only $5.26 - + Add to cart
015	NUT, CLIP, (6MM) Part #: 90305-GEE-710 Required per assembly: 1 ~~$2.63~~ $2.24 - + Add to cart
016	BOLT-WASHER (8X16) Part #: 93401-08016-00 Required per assembly: 6 ~~$2.90~~ $2.65 - + Add to cart
017	NUT, FLANGE, (6MM) Part #: 94050-06000 Required per assembly: 2 ~~$1.73~~ $0.91 - + Add to cart
018	WASHER, PLAIN, (10MM) Part #: 94101-10800 Required per assembly: 2 ~~$2.87~~ $2.58 - + Add to cart
020	BOLT, FLANGE, (10X50) Part #: 95801-10050-00 Required per assembly: 2 $8.59 - + Add to cart
