2009 Honda ST1300A - Air Injection Control Valve

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
001

CLIP, SUB-TANK, HOSE

Part #: 17724-102-700 Required per assembly: 5
$5.41
$4.62
002

TUBE A

Part #: 18651-MCS-G00 Required per assembly: 1
$26.72
$21.63
003

TUBE B

Part #: 18652-MCS-G00 Required per assembly: 1
$27.63
$22.36
004

TUBE C

Part #: 18653-MCS-G00 Required per assembly: 1
$7.49
$6.56
005

STAY

Part #: 18654-MCS-G01 Required per assembly: 1
$5.78
$5.31
006

VALVE ASSEMBLY

Part #: 36450-MCS-000 Required per assembly: 1
$113.09
$94.29
007

BOLT, FLANGE, (6X20)

Part #: 95701-06020-08 Required per assembly: 4
$1.47
$1.35
