Stand replacement parts for 2009 Suzuki GSX650F

OEM Parts Suzuki 2009 Suzuki GSX650F Stand

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	STAND, PROP Part #: 42310-17H00 Required per assembly: 1 Not Available
2	SPRING, INNER Part #: 09443-12048 Required per assembly: 1 $10.99 $10.96 - + Add to cart
3	SPRING, NO.2 Part #: 09443-19010 Required per assembly: 1 Note: SPRING, OUTER; $8.05 $7.25 - + Add to cart
4	BOLT Part #: 09111-10065 Required per assembly: 1 $8.57 $7.71 - + Add to cart
5	NUT Part #: 42321-03FK0 Required per assembly: 1 $6.38 $5.74 - + Add to cart
6	PEDAL, BRAKE Part #: 43111-38G00 Required per assembly: 1 $170.89 $153.80 - + Add to cart
7	WASHER Part #: 09160-18022 Required per assembly: 1 $3.53 $3.18 - + Add to cart
8	BRACKET, STOP, SWITCH Part #: 43560-32C00 Required per assembly: 1 $6.13 $5.52 - + Add to cart
9	SCREW Part #: 02112-0516B Required per assembly: 1 Note: SCREW, TRUNK BOX; $2.35 $2.12 - + Add to cart
10	SPRING Part #: 09443-13029 Required per assembly: 1 $6.53 $5.88 - + Add to cart
11	TUBE, SPRING Part #: 43261-17C00 Required per assembly: 1 Note: TUBE, SPRING GUIDE; $6.62 $5.96 - + Add to cart
