2009 Suzuki QuadSport (LT-Z400Z) - Reverse Cable

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

CABLE, SET, REVERSE

Part #: 57900-33812 Required per assembly: 1
$140.64
$122.86
2

BOLT, OIL, COOLER, BUMPER

Part #: 02162-0510B Required per assembly: 1
$3.60
3

PLATE, REVERSE, KNOB

Part #: 57941-33H00 Required per assembly: 1
$19.64
4

SCREW, KNOB

Part #: 02142-0520B Required per assembly: 2 Note: SCREW, MUDGUARD;
$2.88
5

NUT

Part #: 08316-1005B Required per assembly: 2
$51.16
$44.68
6

SCREW, RR, COMB

Part #: 03541-0512A Required per assembly: 2 Note: SCREW, REAR COMB;
$2.24
