Electrical replacement parts for 2009 Suzuki RM-Z250

OEM Parts Suzuki 2009 Suzuki RM Z250 Electrical

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1-1	CDI UNIT Part #: 32900-10H00 Required per assembly: 1 Note: MODEL K7 Not Available
1-2	CDI UNIT Part #: 32900-10H11 Required per assembly: 1 Note: MODEL K8/K9 Not Available
2	CUSHION, CDI, UNIT Part #: 32980-37F00 Required per assembly: 1 $13.92 - + Add to cart
3	COIL, ASSEMBLY, IGNITION Part #: 33410-35G00 Required per assembly: 1 ~~$186.56~~ $162.97 - + Add to cart
4	HARNESS, WIRING Part #: 36610-10H00 Required per assembly: 1 Note: MODEL K7/K8 Not Available
5	HANRESS, WIRING Part #: 36610-10H20 Required per assembly: 1 Note: MODEL K9 ~~$194.57~~ $169.97 - + Add to cart
6-1	CLAMP, L:95 Part #: 09407-11401 Required per assembly: 3 Note: CLAMP, WIRING HARNESS (L:95); $3.60 - + Add to cart
6-2	CLAMP (L:165) Part #: 09407-18402 Required per assembly: 1 $15.26 - + Add to cart
7	CLAMP Part #: 09407-17403 Required per assembly: 1 $8.01 - + Add to cart
8	SWITCH, ASSEMBLY, ENGINE, STOP Part #: 37820-36E00 Required per assembly: 1 ~~$34.95~~ $30.01 - + Add to cart
9-1	CLAMP, L:95 Part #: 09407-11401 Required per assembly: 1 Note: CLAMP, WIRING HARNESS (L:95); $3.60 - + Add to cart
9-2	CLAMP (L:140) Part #: 09407-14403 Required per assembly: 1 Note: CLAMP; $3.62 - + Add to cart
